HMC5100X-H-708C2-W10A-BW
4.5 GHz Intel® Core™ i7 256 GB SSD 16 GB
Model HMC5100X-H-708C2-W10A-BWPart no. DHI-HMC5100X-H-708C2-W10A-BW
57 specifications
- ProcessorIntel® Core™ i7
- Memory16 GB
- Storage256 GB
- OSWindows 10
- Weight1.3 kg
- ColourBlack
Overview
- Processor
- Intel® Core™ i7
- Memory
- 16 GB
- Storage
- 256 GB
- OS
- Windows 10
- Weight
- 1.3 kg
- Colour
- Black
- Brand
- Dahua Technology
- Category
- Embedded Computer
- Model
- HMC5100X-H-708C2-W10A-BW
- Part number
- DHI-HMC5100X-H-708C2-W10A-BW
- Also known as
- Dahua Technology HMC5100X-H-708C2-W10A-BW 4.5 GHz Intel® Core™ i7 256 GB SSD 16 GB
Specifications
57 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 4.5 GHz |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Processor cores | 8 |
| Processor codename | Comet Lake |
| Thermal Design Power (TDP) | 35 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 16 GB |
| Memory layout (slots x size) | 2 x 8 GB |
| Memory slots | 2x SO-DIMM |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 256 GB |
| Storage media | SSD |
| NVMe | Yes |
| SSD interface | M.2 |
| SSD capacity | 256 GB |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Intel® UHD Graphics 630 |
| On-board graphics card family | Intel® UHD Graphics |
| Discrete graphics card | No |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Line-out | Yes |
| Microphone in | Yes |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| Built-in display | No |
| Touchscreen | No |
| Product colour | Black |
| Number of antenna connectors | 2 |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 |
Power
| Specification | Value |
|---|---|
| Power supply | 90 W |
| DC input voltage | 12/19 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 180 mm |
| Depth | 195 mm |
| Height | 30 mm |
| Weight | 1.3 kg |
| Package width | 308 mm |
| Package depth | 123 mm |
| Package height | 293 mm |
| Package weight | 1.7 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
