DHI-HMC5100X-H-506C2-W10A-BW embedded computer
3.6 GHz Intel® Core™ i5 256 GB SSD 16 GB
Model DHI-HMC5100X-H-506C2-W10A-BWEAN 6923169731346
52 specifications
- ProcessorIntel® Core™ i5
- Memory16 GB
- Storage256 GB
- OSWindows 10
- Weight1.3 kg
- ColourBlack
Overview
- Processor
- Intel® Core™ i5
- Memory
- 16 GB
- Storage
- 256 GB
- OS
- Windows 10
- Weight
- 1.3 kg
- Colour
- Black
- Brand
- Dahua Technology
- Category
- Embedded Computer
- Model
- DHI-HMC5100X-H-506C2-W10A-BW
- Part number
- DHI-HMC5100X-H-506C2-W10A-BW
- EAN / UPC
- 6923169731346
- Also known as
- Dahua Technology DHI-HMC5100X-H-506C2-W10A-BW embedded computer 3.6 GHz Intel® Core™ i5 256 GB SSD 16 GB
Specifications
52 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 3.6 GHz |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i5 |
| Processor model | i5-10400T |
| Configurable TDP-down frequency | 1.3 GHz |
| Configurable TDP-down | 25 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 32 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 256 GB |
| Storage media | SSD |
| NVMe | Yes |
| SSD interface | M.2 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Intel® UHD Graphics 630 |
| Discrete graphics card | No |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI ports quantity | 2 |
| HDMI version | 1.4/2.0 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Line-out | Yes |
| Microphone in | Yes |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| Built-in display | No |
| Touchscreen | No |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Embedded options available | No |
| Intel 64 | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| UART | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Clear Video Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Power
| Specification | Value |
|---|---|
| Power supply | 90 W |
| DC input voltage | 12/19 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.3 kg |
