PE2200U-_ Intel Core Ultra 7 HDD+SSD
Model PE2200U-_Part no. 90AE01U1-M00050EAN 197105682399
41 specifications
- ProcessorIntel Core Ultra 7
- Weight1.93 kg
- Processor manufacturerIntel
- Memory slots2x SO-DIMM
- Storage mediaHDD+SSD
- On-board graphics cardYes
Overview
- Processor
- Intel Core Ultra 7
- Weight
- 1.93 kg
- Processor manufacturer
- Intel
- Memory slots
- 2x SO-DIMM
- Storage media
- HDD+SSD
- On-board graphics card
- Yes
- Brand
- ASUS
- Category
- Embedded Computer
- Model
- PE2200U-_
- Part number
- 90AE01U1-M00050
- EAN / UPC
- 197105682399, 4711387682395
- Also known as
- ASUS PE2200U-_ Intel Core Ultra 7 HDD+SSD
Specifications
41 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 7 |
| Processor model | 165U |
| Processor cores | 12 |
| Processor boost frequency | 4.9 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
Memory
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 5600 MHz |
| Supported memory types | DDR5-SDRAM |
Storage
| Specification | Value |
|---|---|
| Storage media | HDD+SSD |
| Number of storage drives supported | 2 |
| HDD interface | SATA III |
| SSD interface | M.2 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Intel® Graphics |
| Discrete graphics card | No |
Network
| Specification | Value |
|---|---|
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Line-out | Yes |
| Microphone in | Yes |
| RS‐232/422 port | Yes |
Power
| Specification | Value |
|---|---|
| DC input voltage | 9 - 36 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 60 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 95% |
Certificates
| Specification | Value |
|---|---|
| Certification | EMC: CE, FCC, IC, BSMI; Safety: CE-LVD, UKCA, CB, BSMI, CCC |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 254 mm |
| Depth | 147 mm |
| Height | 57 mm |
| Weight | 1.93 kg |
