PE2100S Intel Atom® UFS
Model PE2100SPart no. 90AE0261-M00070EAN 4711387805343
27 specifications
- ProcessorIntel Atom®
- Weight2.45 kg
- ColourBlack
- Processor manufacturerIntel
- Internal memory typeDDR5-SDRAM
- Storage mediaUFS
Overview
- Processor
- Intel Atom®
- Weight
- 2.45 kg
- Colour
- Black
- Processor manufacturer
- Intel
- Internal memory type
- DDR5-SDRAM
- Storage media
- UFS
- Brand
- ASUS
- Category
- Embedded Computer
- Model
- PE2100S
- Part number
- 90AE0261-M00070
- EAN / UPC
- 4711387805343
- Also known as
- ASUS PE2100S Intel Atom® UFS
Specifications
27 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Atom® |
Memory
| Specification | Value |
|---|---|
| Internal memory type | DDR5-SDRAM |
| Maximum internal memory | 16 GB |
| Memory slots | 1x SO-DIMM |
| Memory clock speed | 4800 MHz |
Storage
| Specification | Value |
|---|---|
| Storage media | UFS |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Line-out | Yes |
| Microphone in | Yes |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC ISED CE UKCA RCM BSMI CB |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 254 mm |
| Depth | 147 mm |
| Height | 57 mm |
| Weight | 2.45 kg |
