PE100A-AAA_ 1.3 GHz ARM 32 GB eMMC 4 GB
Model PE100A-AAA_Part no. 90AE0021-M00040EAN 4711081726784
32 specifications
- ProcessorARM
- Memory4 GB
- Storage32 GB
- Weight775 g
- Processor frequency1.3 GHz
- On-board graphics cardYes
Overview
- Processor
- ARM
- Memory
- 4 GB
- Storage
- 32 GB
- Weight
- 775 g
- Processor frequency
- 1.3 GHz
- On-board graphics card
- Yes
- Brand
- ASUS
- Category
- Embedded Computer
- Model
- PE100A-AAA_
- Part number
- 90AE0021-M00040
- EAN / UPC
- 4711081726784
- Also known as
- ASUS PE100A-AAA_ 1.3 GHz ARM 32 GB eMMC 4 GB
Specifications
32 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 1.3 GHz |
| Processor manufacturer | NXP |
| Processor family | ARM |
| Processor model | i.MX 8M |
| Processor cores | 4 |
| Processor cache | 10 MB |
| Processor cache type | L2 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | LPDDR4 |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 32 GB |
| Storage media | eMMC |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Vivante GC7000 Lite |
| Discrete graphics card | No |
Network
| Specification | Value |
|---|---|
| Wi-Fi | No |
| Ethernet LAN | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Ethernet LAN (RJ-45) ports | 2 |
| RS‐232/422 port | Yes |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Linux Yocto OS; Ubuntu server |
Power
| Specification | Value |
|---|---|
| DC input voltage | 12 - 24 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 60 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 95% |
Certificates
| Specification | Value |
|---|---|
| Certification | EMC: CE(ITE), FCC, VCCI, RCM, BSMI, CCC; Safety: UL,CB, CCC, BSMI, CE |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 145 mm |
| Depth | 78 mm |
| Height | 55.5 mm |
| Weight | 775 g |
