AEG HB3313MI10 cooking appliance set Zone…: Full Specifications

Overview

Brand: AEG
Category: Cooking Appliance Set
Model: HB3313MI10
Part number: 801409789
EAN / UPC: 7332543898114
Also known as: AEG HB3313MI10 cooking appliance set Zone induction hob Electric

77 specifications in 3 groups

Specification	Value
Hob type	Zone induction hob
Number of cooking zones	4 zone(s)
Top surface type	Glass-ceramic
Hob colour	Black
Number of electric cooking zones	4 zone(s)
Cooking zone 1 type	Simmer
Cooking zone 1 shape	Round
Cooking zone 1 diameter	145 mm
Cooking zone 1 power	1400 W
Cooking zone 2 type	Regular
Cooking zone 2 shape	Round
Cooking zone 2 diameter	180 mm
Cooking zone 2 power	1800 W
Cooking zone 3 type	Large
Cooking zone 3 shape	Round
Cooking zone 3 diameter	210 mm
Cooking zone 3 power	2300 W
Hob display	Yes
Hob control type	Touch
Hob control position	Front
Hob auto power off	Yes
Pan detection	Yes
Boost function	Yes
Frame form	Full trim
Frame colour	Grey
Hob connected load (electric)	7400 W
Hob input voltage	220 - 240 V
Hob width	57.6 cm
Hob depth	51.6 cm
Hob height	5 cm
Hob installation compartment width	56 cm
Hob installation compartment depth	49 cm
Hob installation compartment height	5 cm
Large cooking zone shape	Round
Regular cooking zone shape	Round
Simmer cooking zone shape	Round

Specification	Value
Oven type	Electric
Oven net capacity	71 L
Oven colour	Stainless steel
Oven control type	Rotary
Oven display	Yes
Integrated clock	Yes
Clock type	Electronic
Oven auto power off	Yes
Timer	Yes
Timer type	Digital
Self-cleaning	Yes
Cleaning type	Pyrolytic
Temperature (min)	30 °C
Temperature (max)	300 °C
Door hinge	Down
Interior light	Yes
Lamp type	Halogen
Bulb power	40 W
Child lock	Yes
Energy efficiency class (oven)	A
Energy consumption (forced convection)	0.69 kWh
Energy consumption (conventional)	1.09 kWh
Connected load	11300 W
Oven input voltage	230 V
Oven current	16 A
Grill	Yes
Grill power	2300 W
Convection cooking	Yes
Conventional cooking	Yes
Oven width	59.5 cm
Oven depth	56.7 cm
Oven height	59.4 cm
Oven weight	35 kg
Oven installation compartment width	56 cm
Oven installation compartment depth	55 cm
Oven installation compartment height	60 cm
Oven package weight	36 kg
