Product comparison · 2 wireless access points

Zebra AP 6511 vs Zebra AP 6521

14specifications compared
7differ
7identical
20known for one product only

Key differences

Ethernet LAN data rates
- AP 6511:10,100 Mbit/s
- AP 6521:10,100,1000 Mbit/s
Internal
- AP 6511:No
- AP 6521:Yes
Dimensions (WxDxH)
- AP 6511:124 x 70 x 29 mm
- AP 6521:189.16 x 241.3 x 43.6 mm
Weight
- AP 6511:340 g
- AP 6521:910 g
Operating relative humidity (H-H)
- AP 6511:5 - 90%
- AP 6521:5 - 95%

Side by side

Differences highlightedShow differences only

Comparison of AP 6511, AP 6521
34 specifications	A Zebra AP 6511 View product	B Zebra AP 6521 View product
Features2 differ
2.4 GHz	Yes	Yes
5 GHz	Yes	Yes
Maximum data transfer rate	300 Mbit/s	300 Mbit/s
Ethernet LAN data ratesDiffers	10,100 Mbit/s	10,100,1000 Mbit/s
Frequency band	2.4, 5 GHz	2.4, 5 GHz
Networking standardsDiffers	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af	IEEE 802.3, IEEE 802.3af
MIMOKnown for one	Yes	Unknown — not stated by the source
VLAN supportKnown for one	Yes	Unknown — not stated by the source
Quality of Service (QoS) support	Yes	Yes
ModulationKnown for one	Unknown — not stated by the source	DSSS, OFDM
Securityidentical
Security algorithmsKnown for one	128-bit AES, 128-bit WEP, EAP, WPA-TKIP, WPA2	Unknown — not stated by the source
Protocolsidentical
DHCP serverKnown for one	Yes	Unknown — not stated by the source
DHCP clientKnown for one	Yes	Unknown — not stated by the source
Management protocolsKnown for one	SSH, HTTPS, SNMP v3	Unknown — not stated by the source
Ports & interfacesidentical
Ethernet LAN (RJ-45) portsKnown for one	2	Unknown — not stated by the source
Poweridentical
Power consumption (typical)Known for one	12.95 W	Unknown — not stated by the source
Power requirementsKnown for one	36 VDC / 57 VDC	Unknown — not stated by the source
Power over Ethernet (PoE)Known for one	Unknown — not stated by the source	Yes
Design1 differ
LED indicatorsKnown for one	Yes	Unknown — not stated by the source
InternalDiffers	No	Yes
Antennaidentical
Antennas quantity	2	2
Antenna gain level (max)Known for one	4.5 dBi	Unknown — not stated by the source
Certificates1 differ
CertificationDiffers	FCC 15.247, 15.407 / EN300 328, EN 301 893; UL EU EN 60950-1 2nd Ed., ANZ C-Tick, UL 2043; FCC Part 15 Subpart B, EN 55022: 2006 + A1: 2007, ICES – 003 (Class B) EN 55024: 1998 + A1: 2001 + A2: 2003; EU RoHS Directive 2002/95/EC; CE, IC, FCC	UL 60950, cUL, EU EN 60950, TUV, FCC, CE
Weight & dimensions2 differ
Dimensions (WxDxH)Differs	124 x 70 x 29 mm	189.16 x 241.3 x 43.6 mm
WeightDiffers	340 g	910 g
Other featuresidentical
Supported data transfer ratesKnown for one	1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48, 54, 300 Mbps	Unknown — not stated by the source
Power LEDKnown for one	Yes	Unknown — not stated by the source
SafetyKnown for one	RoHS	Unknown — not stated by the source
Transmit power rangeKnown for one	6 - 24 dBmW	Unknown — not stated by the source
Operational conditions1 differ
Operating relative humidity (H-H)Differs	5 - 90%	5 - 95%
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Operating altitudeKnown for one	0 - 2438 m	Unknown — not stated by the source
Storage relative humidity (H-H)Known for one	-40 - 70%	Unknown — not stated by the source
Storage temperature (T-T)Known for one	Unknown — not stated by the source	-40 - 70 °C

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
