Product comparison · 2 wireless access points

NETGEAR WA510 1300 Mbit/s White Power over Ethernet (PoE) vs NETGEAR WAX610 1800 Mbit/s White Power over Ethernet (PoE)

26specifications compared
11differ
15identical
19known for one product only

Key differences

The NETGEAR WAX610 1800 Mbit/s White Power over Ethernet (PoE) has 500 Mbit/s more maximum data transfer rate than the NETGEAR WA510 1300 Mbit/s White Power over Ethernet (PoE) (1800 Mbit/s vs 1300 Mbit/s). The NETGEAR WA510 1300 Mbit/s White Power over Ethernet (PoE) has 1 more Ethernet LAN (RJ-45) ports than the NETGEAR WAX610 1800 Mbit/s White Power over Ethernet (PoE) (2 vs 1). The NETGEAR WA510 1300 Mbit/s White Power over Ethernet (PoE) has 36.4 mm more width than the NETGEAR WAX610 1800 Mbit/s White Power over Ethernet (PoE) (197.3 mm vs 160.9 mm). Ethernet LAN data rates: 10,100,1000 Mbit/s on the NETGEAR WA510 1300 Mbit/s White Power over Ethernet (PoE), 10,100,1000,2500 Mbit/s on the NETGEAR WAX610 1800 Mbit/s White Power over Ethernet (PoE). LED indicators: Yes on the NETGEAR WA510 1300 Mbit/s White Power over Ethernet (PoE), LAN, Power, Status on the NETGEAR WAX610 1800 Mbit/s White Power over Ethernet (PoE).

Maximum data transfer rate
- WA510 1300 Mbit/s White Power over Ethernet (PoE):1300 Mbit/s
- WAX610 1800 Mbit/s White Power over Ethernet (PoE):1800 Mbit/s
Ethernet LAN data rates
- WA510 1300 Mbit/s White Power over Ethernet (PoE):10,100,1000 Mbit/s
- WAX610 1800 Mbit/s White Power over Ethernet (PoE):10,100,1000,2500 Mbit/s
Ethernet LAN (RJ-45) ports
- WA510 1300 Mbit/s White Power over Ethernet (PoE):2
- WAX610 1800 Mbit/s White Power over Ethernet (PoE):1
LED indicators
- WA510 1300 Mbit/s White Power over Ethernet (PoE):Yes
- WAX610 1800 Mbit/s White Power over Ethernet (PoE):LAN, Power, Status
Width
- WA510 1300 Mbit/s White Power over Ethernet (PoE):197.3 mm
- WAX610 1800 Mbit/s White Power over Ethernet (PoE):160.9 mm
Depth
- WA510 1300 Mbit/s White Power over Ethernet (PoE):197.3 mm
- WAX610 1800 Mbit/s White Power over Ethernet (PoE):160.9 mm
Height
- WA510 1300 Mbit/s White Power over Ethernet (PoE):37 mm
- WAX610 1800 Mbit/s White Power over Ethernet (PoE):33.2 mm
Weight
- WA510 1300 Mbit/s White Power over Ethernet (PoE):555.5 g
- WAX610 1800 Mbit/s White Power over Ethernet (PoE):412 g

Side by side

Differences highlightedShow differences only

Comparison of WA510, WAX610
45 specifications	A NETGEAR WA510 1300 Mbit/s White Power over Ethernet (PoE) Model WA510 View product	B NETGEAR WAX610 1800 Mbit/s White Power over Ethernet (PoE) Model WAX610 View product
Features3 differ
Maximum data transfer rateDiffers	1300 Mbit/s	1800 Mbit/s
Maximum data transfer rate (2.4 GHz)Known for one	Unknown — not stated by the source	600 Mbit/s
Maximum data transfer rate (5 GHz)Known for one	Unknown — not stated by the source	1200 Mbit/s
Ethernet LAN data ratesDiffers	10,100,1000 Mbit/s	10,100,1000,2500 Mbit/s
Networking standardsDiffers	IEEE 802.11ac, IEEE 802.3af	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Number of usersKnown for one	Unknown — not stated by the source	250 user(s)
Auto MDI/MDI-XKnown for one	Unknown — not stated by the source	Yes
MIMOKnown for one	Unknown — not stated by the source	Yes
MIMO typeKnown for one	Unknown — not stated by the source	Multi User MIMO
Spread spectrum methodKnown for one	Unknown — not stated by the source	OFDM, OFDMA
Wi-Fi Multimedia (WMM)/(WME)Known for one	Unknown — not stated by the source	Yes
Security1 differ
Security algorithmsDiffers	SSH, SSL/TLS, WPA2	EAP-PEAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, WPA, WPA2, WPA2-Enterprise, WPA3
Service Set Identifier (SSID) featuresKnown for one	Unknown — not stated by the source	Multiple SSIDs, SSID broadcast, SSID broadcast on/off
Number of SSID supportedKnown for one	Unknown — not stated by the source	8
Remote Authentication Dial-In User Service (RADIUS)Known for one	Unknown — not stated by the source	Yes
Access Control List (ACL)Known for one	Yes	Unknown — not stated by the source
Ports & interfaces1 differ
Ethernet LAN (RJ-45) portsDiffers	2	1
Design1 differ
Reset buttonKnown for one	Unknown — not stated by the source	Yes
LED indicatorsDiffers	Yes	LAN, Power, Status
Antennaidentical
Antenna gain level (max)Known for one	Unknown — not stated by the source	4.5 dBi
Weight & dimensions4 differ
WidthDiffers	197.3 mm	160.9 mm
DepthDiffers	197.3 mm	160.9 mm
HeightDiffers	37 mm	33.2 mm
WeightDiffers	555.5 g	412 g
Packaging dataidentical
Package widthKnown for one	Unknown — not stated by the source	220 mm
Package depthKnown for one	Unknown — not stated by the source	455 mm
Package heightKnown for one	Unknown — not stated by the source	235 mm
Package weightKnown for one	Unknown — not stated by the source	3.98 kg
Packaging content1 differ
Quantity per packDiffers	8 pc(s)	1 pc(s)
Mounting kitKnown for one	Unknown — not stated by the source	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
