Product comparison · 2 wireless access points

Dell H510 1000 Mbit/s Power over Ethernet (PoE) vs Dell ZoneFlex T710

13specifications compared
10differ
3identical
28known for one product only

Key differences

Number of users
- H510 1000 Mbit/s Power over Ethernet (PoE):100 user(s)
- ZoneFlex T710:512 user(s)
Ethernet LAN (RJ-45) ports
- H510 1000 Mbit/s Power over Ethernet (PoE):5
- ZoneFlex T710:2
Power consumption (max)
- H510 1000 Mbit/s Power over Ethernet (PoE):9.2 W
- ZoneFlex T710:25 W
Width
- H510 1000 Mbit/s Power over Ethernet (PoE):90 mm
- ZoneFlex T710:317 mm
Depth
- H510 1000 Mbit/s Power over Ethernet (PoE):145 mm
- ZoneFlex T710:241 mm
Height
- H510 1000 Mbit/s Power over Ethernet (PoE):29 mm
- ZoneFlex T710:95 mm
Weight
- H510 1000 Mbit/s Power over Ethernet (PoE):230 g
- ZoneFlex T710:2.95 kg
Operating temperature (T-T)
- H510 1000 Mbit/s Power over Ethernet (PoE):0 - 40 °C
- ZoneFlex T710:-20 - 65 °C

Side by side

Differences highlightedShow differences only

Comparison of H510, ZoneFlex T710
41 specifications	A Dell H510 1000 Mbit/s Power over Ethernet (PoE) Model H510 View product	B Dell ZoneFlex T710 View product
Features2 differ
2.4 GHz	Yes	Yes
5 GHz	Yes	Yes
Ethernet LAN data ratesKnown for one	Unknown — not stated by the source	10,100,1000 Mbit/s
Frequency bandKnown for one	Unknown — not stated by the source	2.4 - 2.472, 5.15 - 5.25, 5.25 - 5.35, 5.37 - 5.47, 5.47 - 5.725, 5.725 - 5.8725, 5.85 - 5.925 GHz
Networking standardsDiffers	IEEE 802.11ac, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u	IEEE 802.3at
Number of usersDiffers	100 user(s)	512 user(s)
MIMOKnown for one	Unknown — not stated by the source	Yes
Quality of Service (QoS) supportKnown for one	Unknown — not stated by the source	Yes
Maximum data transfer rateKnown for one	1000 Mbit/s	Unknown — not stated by the source
VLAN supportKnown for one	Yes	Unknown — not stated by the source
Transmitting powerKnown for one	10 dBmW	Unknown — not stated by the source
Receiver sensitivityKnown for one	Up to -99dBm	Unknown — not stated by the source
Security1 differ
Security algorithmsDiffers	802.1x RADIUS, AES, WPA-PSK, WPA-TKIP, WPA2	WPA-PSK, WPA-TKIP, WPA2-AES
Remote Authentication Dial-In User Service (RADIUS)Known for one	Unknown — not stated by the source	Yes
DHCP snoopingKnown for one	Yes	Unknown — not stated by the source
Management featuresidentical
Management platformKnown for one	Unknown — not stated by the source	Cloudpath
Ports & interfaces1 differ
Ethernet LAN (RJ-45) portsDiffers	5	2
USB 2.0 ports quantity	1	1
Internal RJ-45 ports quantityKnown for one	4	Unknown — not stated by the source
WAN connectionKnown for one	Ethernet (RJ-45)	Unknown — not stated by the source
Power1 differ
Power consumption (max)Differs	9.2 W	25 W
Power over Ethernet (PoE)Known for one	Yes	Unknown — not stated by the source
AC input voltageKnown for one	48 V	Unknown — not stated by the source
Power consumption (typical)Known for one	7.3 W	Unknown — not stated by the source
Designidentical
PlacementKnown for one	Unknown — not stated by the source	Pole, Wall
Product colourKnown for one	Unknown — not stated by the source	White
International Protection (IP) codeKnown for one	Unknown — not stated by the source	IP67
On/off switchKnown for one	Unknown — not stated by the source	Yes
LED indicatorsKnown for one	Unknown — not stated by the source	Yes
Dell E-Value CodeKnown for one	Unknown — not stated by the source	DNRUT710
InternalKnown for one	Unknown — not stated by the source	No
Antennaidentical
Antenna typeKnown for one	Unknown — not stated by the source	Internal
Antenna featuresKnown for one	Unknown — not stated by the source	Integrated antenna
Antenna gain level (max)Known for one	4 dBi	Unknown — not stated by the source
Certificatesidentical
CertificationKnown for one	Unknown — not stated by the source	EN 60950-1 Safety EN 60601-1-2 Medical EN 61000-4-2/3/5 Immunity EN 50121-1 Railway EMC EN 50121-4 Railway Immunity IEC 61373 Railway Shock & Vibration UL 2043 Plenum EN 62311 Human Safety/RF Exposure WEEE & RoHS ISTA 2A Transportation
Weight & dimensions4 differ
WidthDiffers	90 mm	317 mm
DepthDiffers	145 mm	241 mm
HeightDiffers	29 mm	95 mm
WeightDiffers	230 g	2.95 kg
Operational conditions1 differ
Operating temperature (T-T)Differs	0 - 40 °C	-20 - 65 °C
Operating relative humidity (H-H)Known for one	15 - 95%	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
