Product comparison · 2 wired routers

Intellinet 4-Port Broadband Router vs Intellinet High Speed Broadband Router

20specifications compared
2differ
18identical
24known for one product only

Key differences

Cables included
- 4-Port Broadband Router:UTP
- High Speed Broadband Router:LAN (RJ-45)
LED indicators
- 4-Port Broadband Router:Link, Status, Yes
- High Speed Broadband Router:LAN, Link, Power, Yes

Side by side

Differences highlightedShow differences only

Comparison of 4-Port Broadband Router, High Speed Broadband Router
44 specifications	A Intellinet 4-Port Broadband Router View product	B Intellinet High Speed Broadband Router View product
WAN connectionidentical
Ethernet WAN	Yes	Yes
Networkidentical
Networking standards	IEEE 802.3, IEEE 802.3u	IEEE 802.3, IEEE 802.3u
Ethernet interface type	Fast Ethernet	Fast Ethernet
Ethernet LAN	Yes	Yes
Cabling technology	10/100Base-T(X)	10/100Base-T(X)
Ethernet LAN data rates	10,100 Mbit/s	10,100 Mbit/s
Number of usersKnown for one	253 user(s)	Unknown — not stated by the source
Management featuresidentical
Web-based management	Yes	Yes
Quality of Service (QoS) supportKnown for one	Unknown — not stated by the source	Yes
Universal Plug and Play (UPnP)Known for one	Unknown — not stated by the source	Yes
Reset button	Yes	Yes
Firmware upgradeableKnown for one	Yes	Unknown — not stated by the source
Ports & interfacesidentical
Ethernet LAN (RJ-45) ports	4	4
Protocolsidentical
DHCP client	Yes	Yes
DHCP server	Yes	Yes
DMZ support	Yes	Yes
Supported network protocolsKnown for one	Unknown — not stated by the source	CSMA/CA, CSMA/CD, TCP/IP, UDP, ICMP, PPPoE, NTP, DNS
Securityidentical
Firewall security	Network address translation (NAT) firewall	Network address translation (NAT) firewall
MAC address filtering	Yes	Yes
System event logKnown for one	Yes	Unknown — not stated by the source
Packaging content1 differ
Cables includedDiffers	UTP	LAN (RJ-45)
Manual	Yes	Yes
AC adapter includedKnown for one	Yes	Unknown — not stated by the source
Featuresidentical
Built-in processorKnown for one	Unknown — not stated by the source	Yes
Processor architectureKnown for one	Unknown — not stated by the source	ARM9
Flash memoryKnown for one	Unknown — not stated by the source	2 MB
Internal memoryKnown for one	Unknown — not stated by the source	16 MB
CertificationKnown for one	Unknown — not stated by the source	FCC, CE, RoHS
Minimum system requirementsKnown for one	NIC IE 4.0+	Unknown — not stated by the source
Design1 differ
Product colour	Black	Black
LED indicatorsDiffers	Link, Status, Yes	LAN, Link, Power, Yes
Poweridentical
Input currentKnown for one	Unknown — not stated by the source	1 A
Operational conditionsidentical
Operating temperature (T-T)Known for one	Unknown — not stated by the source	32 - 122 °F
Storage temperature (T-T)Known for one	Unknown — not stated by the source	0 - 60 °C
Operating relative humidity (H-H)Known for one	Unknown — not stated by the source	10 - 95%
Weight & dimensionsidentical
WeightKnown for one	Unknown — not stated by the source	1 kg
Other featuresidentical
Cable lengthKnown for one	Unknown — not stated by the source	1.5 m
Connectivity technology	Wired	Wired
Dimensions (WxDxH)Known for one	Unknown — not stated by the source	164 x 108 x 30 mm
Input voltageKnown for one	Unknown — not stated by the source	5 V
Networking features	Fast Ethernet	Fast Ethernet
Power LEDKnown for one	Unknown — not stated by the source	Yes
ThroughputKnown for one	20 Mb/s	Unknown — not stated by the source
DSL featuresidentical
ADSLKnown for one	Yes	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
