Product comparison · 2 wired routers

Allied Telesis AT-AR440S wired router vs Allied Telesis AT-AR750S wired router

22specifications compared
10differ
12identical
16known for one product only

Key differences

Data transfer rate
- AT-AR440S wired router:8 Mbit/s
- AT-AR750S wired router:10 Mbit/s
Supports ISDN connection
- AT-AR440S wired router:No
- AT-AR750S wired router:Yes
Management protocols
- AT-AR440S wired router:CLI, SNMP
- AT-AR750S wired router:SNMPv3
Operating temperature (T-T)
- AT-AR440S wired router:0 - 50 °C
- AT-AR750S wired router:0 - 40 °C
Weight
- AT-AR440S wired router:1.96 kg
- AT-AR750S wired router:1.94 kg
Power requirements
- AT-AR440S wired router:100-240V@50-60Hz
- AT-AR750S wired router:100-240 VAC, 50-60 Hz
Dimensions (WxDxH)
- AT-AR440S wired router:335 x 180 x 44 mm
- AT-AR750S wired router:305 x 190 x 44 mm
Maximum data transfer rate
- AT-AR440S wired router:0.008 Gbit/s
- AT-AR750S wired router:0.1 Gbit/s

Side by side

Differences highlightedShow differences only

Comparison of AT-AR440S, AT-AR750S
38 specifications	A Allied Telesis AT-AR440S wired router Model AT-AR440S View product	B Allied Telesis AT-AR750S wired router Model AT-AR750S View product
Network2 differ
Data transfer rateDiffers	8 Mbit/s	10 Mbit/s
Supports ISDN connectionDiffers	No	Yes
Networking standardsKnown for one	Unknown — not stated by the source	IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ac, IEEE 802.3u, IEEE 802.3x
DSL featuresidentical
ADSL	Yes	Yes
Upstream data rateKnown for one	0.832 Mbit/s	Unknown — not stated by the source
Downstream data rateKnown for one	8 Mbit/s	Unknown — not stated by the source
DSL specificationKnown for one	Annex A G992.1 G.DMT	Unknown — not stated by the source
Management featuresidentical
Quality of Service (QoS) support	Yes	Yes
Ports & interfaces1 differ
I/O portsDiffers	1x ADSL 5x 10/100BASE-T 1x PIC	2 x 10/100 WAN, 2 x PICs
Ethernet LAN (RJ-45) portsKnown for one	Unknown — not stated by the source	5
Protocols1 differ
DHCP client	Yes	Yes
DHCP server	Yes	Yes
Management protocolsDiffers	CLI, SNMP	SNMPv3
Securityidentical
Security algorithmsKnown for one	3DES, DES, SSH	Unknown — not stated by the source
Authentication method	RADIUS, TACACS, MD5, PAP, CHAP	RADIUS, TACACS, MD5, PAP, CHAP
IP address filteringKnown for one	Yes	Unknown — not stated by the source
VPN supportKnown for one	L2TP NAT-T	Unknown — not stated by the source
MAC address filteringKnown for one	Unknown — not stated by the source	Yes
VPN tunnels quantityKnown for one	Unknown — not stated by the source	5000
Features1 differ
Built-in processorKnown for one	Yes	Unknown — not stated by the source
Processor frequencyKnown for one	300 MHz	Unknown — not stated by the source
Flash memory	16 MB	16 MB
Internal memory	64 MB	64 MB
Mean time between failures (MTBF)	120000 h	120000 h
CertificationDiffers	UL TUV UL60950 EN60950 EN55022 class A EN55024 FCC class A VCCI class A AS/NZS CISPR22 class A CE	UL, TUV, UL60950, EN60950, EN55022 A, EN55024, FCC A, VCCI A, AS/NZS CISPR22 A, CE
Poweridentical
Power consumption (typical)	40 W	40 W
Operational conditions1 differ
Operating temperature (T-T)Differs	0 - 50 °C	0 - 40 °C
Storage temperature (T-T)	-25 - 70 °C	-25 - 70 °C
Operating relative humidity (H-H)	5 - 80%	5 - 80%
Operating altitudeKnown for one	Unknown — not stated by the source	0 - 3048 m
Weight & dimensions1 differ
WeightDiffers	1.96 kg	1.94 kg
Other features3 differ
Power requirementsDiffers	100-240V@50-60Hz	100-240 VAC, 50-60 Hz
Connectivity technology	Wired	Wired
Dimensions (WxDxH)Differs	335 x 180 x 44 mm	305 x 190 x 44 mm
Maximum data transfer rateDiffers	0.008 Gbit/s	0.1 Gbit/s
Power supply typeKnown for one	AC	Unknown — not stated by the source
Connectivity LEDsKnown for one	Unknown — not stated by the source	Yes
Designidentical
LED indicatorsKnown for one	Unknown — not stated by the source	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
