Product comparison · 2 uninterruptible power supplies (upss)

AEG Protect D. 10000 vs AEG Protect D. 6000

40specifications compared
10differ
30identical
1known for one product only

Key differences

Output power capacity
- Protect D. 10000:10 kVA
- Protect D. 6000:6 kVA
Output power
- Protect D. 10000:9000 W
- Protect D. 6000:5400 W
Maximum current
- Protect D. 10000:47 A
- Protect D. 6000:29 A
Efficiency
- Protect D. 10000:97%
- Protect D. 6000:96%
AC outlets quantity
- Protect D. 10000:4 AC outlet(s)
- Protect D. 6000:3 AC outlet(s)
Battery voltage
- Protect D. 10000:240 V
- Protect D. 6000:180 V
Rack capacity
- Protect D. 10000:5U
- Protect D. 6000:3U
Height
- Protect D. 10000:220 mm
- Protect D. 6000:132 mm

Side by side

Differences highlightedShow differences only

Comparison of Protect D. 10000, Protect D. 6000
41 specifications	A AEG Protect D. 10000 View product	B AEG Protect D. 6000 View product
Features4 differ
Output power capacityDiffers	10 kVA	6 kVA
Output powerDiffers	9000 W	5400 W
Waveform	Sine	Sine
Input operation voltage (min)	176 V	176 V
Input operation voltage (max)	276 V	276 V
Input frequency	50/60 Hz	50/60 Hz
Output operation voltage (min)	200 V	200 V
Output operation voltage (max)	240 V	240 V
Maximum currentDiffers	47 A	29 A
EfficiencyDiffers	97%	96%
Crest factor	3:1	3:1
Emergency Power Off (EPO)	Yes	Yes
Output voltage Total Harmonic Distortion (THD)	2%	2%
Noise level	55 dB	55 dB
Power protection features	Overload, Short circuit	Overload, Short circuit
Audible alarm(s)	Yes	Yes
Ports & interfaces2 differ
AC outlet typesDiffers	C19 coupler, Terminal	C13 coupler, C19 coupler, Terminal
Power plug	Terminal	Terminal
AC outlets quantityDiffers	4 AC outlet(s)	3 AC outlet(s)
USB 2.0 ports quantity	1	1
RS-232 ports	1	1
Battery1 differ
Battery technology	Sealed Lead Acid (VRLA)	Sealed Lead Acid (VRLA)
Battery voltageDiffers	240 V	180 V
Battery recharge time	3 h	3 h
Hot-swap battery	Yes	Yes
Automatic battery test	Yes	Yes
Design1 differ
Form factor	Rackmount	Rackmount
Product colour	Grey	Grey
Housing material	Metal	Metal
Rack capacityDiffers	5U	3U
Display type	LCD	LCD
LED indicators	Yes	Yes
Operational conditionsidentical
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Operating relative humidity (H-H)	0 - 95%	0 - 95%
Operating altitude	0 - 1000 m	0 - 1000 m
Certificatesidentical
Certification	EN62010-2 EN62040-1	EN62010-2 EN62040-1
Weight & dimensions2 differ
Width	486 mm	486 mm
Depth	715 mm	715 mm
HeightDiffers	220 mm	132 mm
WeightDiffers	82.5 kg	46 kg
Other featuresidentical
Output connection typeKnown for one	Unknown — not stated by the source	2 x C13, 1 x C19, 1 x Terminal

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
