Product comparison · 2 uninterruptible power supplies (upss)

AEG Protect B.750 PRO vs AEG Protect D. 2000

16specifications compared
11differ
5identical
49known for one product only

Key differences

Output power capacity
- Protect B.750 PRO:0.75 kVA
- Protect D. 2000:2 kVA
Output power
- Protect B.750 PRO:675 W
- Protect D. 2000:1800 W
Noise level
- Protect B.750 PRO:45 dB
- Protect D. 2000:52 dB
Battery recharge time
- Protect B.750 PRO:6 h
- Protect D. 2000:3 h
LED indicators
- Protect B.750 PRO:Yes
- Protect D. 2000:Battery replacement
Operating relative humidity (H-H)
- Protect B.750 PRO:20 - 50%
- Protect D. 2000:0 - 95%
Width
- Protect B.750 PRO:88 mm
- Protect D. 2000:482.6 mm
Depth
- Protect B.750 PRO:420 mm
- Protect D. 2000:600 mm

Side by side

Differences highlightedShow differences only

Comparison of Protect B.750 PRO, Protect D. 2000
65 specifications	A AEG Protect B.750 PRO View product	B AEG Protect D. 2000 View product
Features3 differ
UPS topologyKnown for one	Unknown — not stated by the source	Double-conversion (Online)
Output power capacityDiffers	0.75 kVA	2 kVA
Output powerDiffers	675 W	1800 W
WaveformKnown for one	Unknown — not stated by the source	Sine
Input operation voltage (min)Known for one	Unknown — not stated by the source	140 V
Input operation voltage (max)Known for one	Unknown — not stated by the source	276 V
Input frequency	50/60 Hz	50/60 Hz
Output operation voltage (min)Known for one	Unknown — not stated by the source	200 V
Output operation voltage (max)Known for one	Unknown — not stated by the source	240 V
Output frequencyKnown for one	Unknown — not stated by the source	50/60 Hz
Number of input phasesKnown for one	Unknown — not stated by the source	1
Number of output phasesKnown for one	Unknown — not stated by the source	1
EfficiencyKnown for one	Unknown — not stated by the source	98%
Input power factorKnown for one	Unknown — not stated by the source	0.99
Output power factorKnown for one	Unknown — not stated by the source	0.9
Crest factorKnown for one	Unknown — not stated by the source	3:1
Output voltage Total Harmonic Distortion (THD)Known for one	Unknown — not stated by the source	3%
Input current Total Harmonic Distortion (THD)Known for one	Unknown — not stated by the source	8%
Noise levelDiffers	45 dB	52 dB
Power protection featuresKnown for one	Unknown — not stated by the source	Short circuit
Audible alarm(s)	Yes	Yes
Audible alarm modesKnown for one	Unknown — not stated by the source	Fault, Low battery alarm, Overload alarm, Battery replacement
Maximum currentKnown for one	3.6 A	Unknown — not stated by the source
Response timeKnown for one	500 ms	Unknown — not stated by the source
Power factorKnown for one	0.9	Unknown — not stated by the source
Ports & interfacesidentical
AC outlet typesKnown for one	Unknown — not stated by the source	C13 coupler
AC outlets quantityKnown for one	Unknown — not stated by the source	8 AC outlet(s)
USB portKnown for one	Unknown — not stated by the source	Yes
RS-232 portsKnown for one	Unknown — not stated by the source	1
Number of output IEC jumpersKnown for one	8	Unknown — not stated by the source
USB 2.0 ports quantityKnown for one	1	Unknown — not stated by the source
Serial ports quantityKnown for one	1	Unknown — not stated by the source
Modem (RJ-11) portsKnown for one	1	Unknown — not stated by the source
Ethernet LAN (RJ-45) portsKnown for one	1	Unknown — not stated by the source
Battery1 differ
Battery technology	Sealed Lead Acid (VRLA)	Sealed Lead Acid (VRLA)
Battery recharge timeDiffers	6 h	3 h
Typical backup time at full loadKnown for one	4.5 min	Unknown — not stated by the source
Typical backup time at half loadKnown for one	10.5 min	Unknown — not stated by the source
Design1 differ
Form factorKnown for one	Unknown — not stated by the source	Rackmount
Product colourKnown for one	Unknown — not stated by the source	Black
Housing materialKnown for one	Unknown — not stated by the source	Aluminium, Metal
Rack capacityKnown for one	Unknown — not stated by the source	2U
Display type	LCD	LCD
LED indicatorsDiffers	Yes	Battery replacement
Operational conditions1 differ
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Operating relative humidity (H-H)Differs	20 - 50%	0 - 95%
Operating altitudeKnown for one	Unknown — not stated by the source	0 - 3000 m
Packaging contentidentical
Rack mount kitKnown for one	Unknown — not stated by the source	Yes
Cables includedKnown for one	Unknown — not stated by the source	RS-232, USB cable
Quick installation guideKnown for one	Unknown — not stated by the source	Yes
Certificates1 differ
CertificationDiffers	CE, EN 62040-1, EN 62040-2, EN 61000-3-2, EN 61000-3-3	EN 62040-2 Class C1, EN 61000-3-2, EN 61000-3-3 62040-1
Weight & dimensions4 differ
WidthDiffers	88 mm	482.6 mm
DepthDiffers	420 mm	600 mm
HeightDiffers	440 mm	88 mm
WeightDiffers	14.6 kg	19 kg
Packaging dataidentical
Resource CDKnown for one	Unknown — not stated by the source	Yes
Bundled softwareKnown for one	Unknown — not stated by the source	CompuWatch
Other featuresidentical
InterfaceKnown for one	RS-232, USB	Unknown — not stated by the source
Output connectionsKnown for one	IEC320 C13	Unknown — not stated by the source
Compatible operating systemsKnown for one	Windows Linux Mac OS	Unknown — not stated by the source
Mac compatibilityKnown for one	Yes	Unknown — not stated by the source
Networking featuresKnown for one	Fast Ethernet	Unknown — not stated by the source
Output voltage noteKnown for one	220 - 240V +/-3%	Unknown — not stated by the source
Overload protectionKnown for one	Yes	Unknown — not stated by the source
Relative humidityKnown for one	0 - 90%	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
