Product comparison · 2 tv set-top boxes

Philips DCR2022 Digital Cable Receiver vs Philips DSR5020/19 TV set-top box

7specifications compared
6differ
1identical
50known for one product only

Key differences

Processor frequency
- DCR2022 Digital Cable Receiver:60 MHz
- DSR5020/19 TV set-top box:400 MHz
Power consumption (standby)
- DCR2022 Digital Cable Receiver:7 W
- DSR5020/19 TV set-top box:0.5 W
Width
- DCR2022 Digital Cable Receiver:238 mm
- DSR5020/19 TV set-top box:247 mm
Depth
- DCR2022 Digital Cable Receiver:145 mm
- DSR5020/19 TV set-top box:176 mm
Height
- DCR2022 Digital Cable Receiver:42 mm
- DSR5020/19 TV set-top box:39 mm
Dimensions (WxDxH)
- DCR2022 Digital Cable Receiver:238 x 145 x 42 mm
- DSR5020/19 TV set-top box:247 x 176 x 39 mm

Side by side

Differences highlightedShow differences only

Comparison of DCR2022/03, DSR5020/19
57 specifications	A Philips DCR2022 Digital Cable Receiver Model DCR2022/03 View product	B Philips DSR5020/19 TV set-top box Model DSR5020/19 View product
Videoidentical
Signal sourceKnown for one	Cable	Unknown — not stated by the source
Digital signal format systemKnown for one	DVB	Unknown — not stated by the source
Video resolutionsKnown for one	720 x 576 pixels	Unknown — not stated by the source
3DKnown for one	No	Unknown — not stated by the source
Aspect ratioKnown for one	4:3, 16:9	Unknown — not stated by the source
File formatsidentical
Audio formats supportedKnown for one	AC3	Unknown — not stated by the source
Networkidentical
Ethernet LANKnown for one	No	Unknown — not stated by the source
Wi-FiKnown for one	No	Unknown — not stated by the source
Ports & interfacesidentical
USB 2.0 ports quantityKnown for one	0	Unknown — not stated by the source
HDMI ports quantityKnown for one	0	Unknown — not stated by the source
Composite video outKnown for one	0	Unknown — not stated by the source
SCART ports quantityKnown for one	2	Unknown — not stated by the source
Component video (YPbPr/YCbCr) outKnown for one	0	Unknown — not stated by the source
Digital audio coaxial outKnown for one	1	Unknown — not stated by the source
Audio (L/R) outKnown for one	1	Unknown — not stated by the source
RF ports quantityKnown for one	2	Unknown — not stated by the source
DC-in jackKnown for one	Yes	Unknown — not stated by the source
Storageidentical
Built-in HDDKnown for one	No	Unknown — not stated by the source
Card reader integratedKnown for one	Yes	Unknown — not stated by the source
Compatible memory cardsKnown for one	SmartMedia	Unknown — not stated by the source
Memoryidentical
Flash memoryKnown for one	2 MB	Unknown — not stated by the source
Featuresidentical
Product colourKnown for one	Black	Unknown — not stated by the source
Tuner typeKnown for one	Digital	Unknown — not stated by the source
Number of tunersKnown for one	1 tuner(s)	Unknown — not stated by the source
Electronic Programme Guide (EPG)Known for one	Yes	Unknown — not stated by the source
Audio output channelsKnown for one	5.1 channels	Unknown — not stated by the source
Audio decodersKnown for one	Dolby Digital	Unknown — not stated by the source
Child lockKnown for one	Yes	Unknown — not stated by the source
Parental controlKnown for one	Yes	Unknown — not stated by the source
Events timer/reminderKnown for one	Yes	Unknown — not stated by the source
Favorite list TV programsKnown for one	3	Unknown — not stated by the source
Favorite list radio programsKnown for one	3	Unknown — not stated by the source
On Screen Display (OSD)Known for one	Yes	Unknown — not stated by the source
Signal strength indication	Yes	Yes
Processor1 differ
Processor frequencyDiffers	60 MHz	400 MHz
Power1 differ
AC input voltageKnown for one	220-240 V	Unknown — not stated by the source
Power consumption (typical)Known for one	10 W	Unknown — not stated by the source
Power consumption (standby)Differs	7 W	0.5 W
PowerKnown for one	Unknown — not stated by the source	12 W
Weight & dimensions3 differ
WidthDiffers	238 mm	247 mm
DepthDiffers	145 mm	176 mm
HeightDiffers	42 mm	39 mm
WeightKnown for one	980 g	Unknown — not stated by the source
Packaging dataidentical
Package widthKnown for one	320 mm	Unknown — not stated by the source
Package depthKnown for one	85 mm	Unknown — not stated by the source
Package heightKnown for one	295 mm	Unknown — not stated by the source
Package dimensions (WxDxH)Known for one	320 x 85 x 295 mm	Unknown — not stated by the source
Package weightKnown for one	1.78 kg	Unknown — not stated by the source
Packaging contentidentical
Remote control includedKnown for one	Yes	Unknown — not stated by the source
Batteries includedKnown for one	Yes	Unknown — not stated by the source
Cables includedKnown for one	AC, SCART	Unknown — not stated by the source
ManualKnown for one	Yes	Unknown — not stated by the source
Operational conditionsidentical
Operating temperature (T-T)Known for one	0 - 40 °C	Unknown — not stated by the source
Storage temperature (T-T)Known for one	-20 - 60 °C	Unknown — not stated by the source
Other features1 differ
Dimensions (WxDxH)Differs	238 x 145 x 42 mm	247 x 176 x 39 mm
Displayidentical
Display resolutionKnown for one	Unknown — not stated by the source	1920 x 1080 pixels
Technical detailsidentical
Larger master carton dimensions (WxDxH)Known for one	Unknown — not stated by the source	285 x 257 x 95

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
