Product comparison · 2 solar panels

LG340N1K-V5 solar panel vs LG NeON R

15specifications compared
8differ
7identical
25known for one product only

Key differences

Rated power
- LG340N1K-V5 solar panel:340 W
- NeON R:400 W
Housing material
- LG340N1K-V5 solar panel:Aluminium
- NeON R:Tempered glass
Operating temperature (T-T)
- LG340N1K-V5 solar panel:-40 - 90 °C
- NeON R:-40 - 85 °C
Package depth
- LG340N1K-V5 solar panel:1750 mm
- NeON R:1790 mm
Package height
- LG340N1K-V5 solar panel:1221 mm
- NeON R:1227 mm
Width
- LG340N1K-V5 solar panel:1016 mm
- NeON R:1042 mm
Depth
- LG340N1K-V5 solar panel:1686 mm
- NeON R:1740 mm
Weight
- LG340N1K-V5 solar panel:17.1 kg
- NeON R:18.5 kg

Side by side

Differences highlightedShow differences only

Comparison of LG340N1K-V5, NeON R
40 specifications	A LG LG340N1K-V5 solar panel Model LG340N1K-V5 View product	B LG NeON R View product
Power1 differ
Rated powerDiffers	340 W	400 W
Maximum system voltageKnown for one	Unknown — not stated by the source	1000 V
MPP Current (NMOT)Known for one	Unknown — not stated by the source	8.62 A
MPP Voltage (NMOT)Known for one	Unknown — not stated by the source	35.2 V
Maximum Power (STC)Known for one	Unknown — not stated by the source	400 W
MPP Current (STC)Known for one	Unknown — not stated by the source	10.76 A
Short-circuit current (Isc) (STC)Known for one	Unknown — not stated by the source	11.32 A
Power tolerance (STC)Known for one	Unknown — not stated by the source	3%
MPP Voltage (STC)Known for one	Unknown — not stated by the source	37.2 V
Open-circuit voltage (STC)Known for one	Unknown — not stated by the source	43.8 V
Features1 differ
Solar cell type	Monocrystalline silicon	Monocrystalline silicon
Connector type	MC4	MC4
Product colour	Black	Black
Housing materialDiffers	Aluminium	Tempered glass
Housing thicknessKnown for one	Unknown — not stated by the source	2.8 mm
FrameKnown for one	Unknown — not stated by the source	Yes
Frame materialKnown for one	Unknown — not stated by the source	Anodized aluminium
International Protection (IP) code	IP68	IP68
Fire-resistance ratingKnown for one	Unknown — not stated by the source	Class C (UL 790)
Fire-resistantKnown for one	Unknown — not stated by the source	Yes
Mechanical test load (Front) (Pa/psf)Known for one	Unknown — not stated by the source	5400/113
Mechanical test load (Rear) (Pa/psf)Known for one	Unknown — not stated by the source	4000/83.5
Module fire performanceKnown for one	Unknown — not stated by the source	Type 1
Cell efficiency (STC)Known for one	Unknown — not stated by the source	22.1%
Cable lengthKnown for one	Unknown — not stated by the source	1.25 m
Number of bypass diodesKnown for one	Unknown — not stated by the source	3
Number of cells	60	60
CertificationKnown for one	CertificationsIEC 61215-1/-1-1/2:2016, IEC 61730- 1/2:2016, UL 1703, ISO 9001, ISO 14001, ISO 50001, OHSAS 18001	Unknown — not stated by the source
Operational conditions1 differ
Operating temperature (T-T)Differs	-40 - 90 °C	-40 - 85 °C
Packaging contentidentical
ManualKnown for one	Unknown — not stated by the source	Yes
Technical detailsidentical
Temperature coefficient of the open-circuit voltage (Voc)Known for one	Unknown — not stated by the source	-0.24 %/°C
Temperature coefficient of the short-circuit current (Isc)Known for one	Unknown — not stated by the source	0.04 %/°C
Warranty periodKnown for one	Unknown — not stated by the source	25 year(s)
Packaging data2 differ
Package width	1120 mm	1120 mm
Package depthDiffers	1750 mm	1790 mm
Package heightDiffers	1221 mm	1227 mm
Weight & dimensions3 differ
WidthDiffers	1016 mm	1042 mm
DepthDiffers	1686 mm	1740 mm
Height	40 mm	40 mm
WeightDiffers	17.1 kg	18.5 kg

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
