Product comparison · 2 solar inverters

Salicru EQX2 4002-HSX vs Salicru EQX2 4002-HT

Add a product
  • 47specifications compared
  • 11differ
  • 36identical
  • 3known for one product only

Key differences

  • MPP voltage range
    • 100 - 550 V
    • 100 - 850 V
  • Maximum input power (DC)
    • 6720 W
    • 6400 W
  • Maximum power
    • 4200 W
    • 4000 W
  • DC input voltage
    • 600 V
    • 1000 V
  • Network voltage
    • 230 V
    • 400 V
  • Output current
    • 18.3 A
    • 5.8 A
  • Short-circuit current per MPPT (max)
    • 20 A
    • 18 A
  • Starting voltage
    • 80 V
    • 150 V

Side by side

Differences highlightedShow differences only
50 specifications
A

Salicru

EQX2 4002-HSXView product
B

Salicru

EQX2 4002-HTView product
Features11 differ
Product typeOn-grid inverterOn-grid inverter
Output power capacity (max)4.62 kVA4.62 kVA
Output operation voltage (min)195 V195 V
Output operation voltage (max)253 V253 V
Output frequency50/60 Hz50/60 Hz
MPP voltage rangeDiffers100 - 550 V100 - 850 V
Maximum input power (DC)Differs6720 W6400 W
Maximum powerDiffers4200 W4000 W
DC disconnectorYesYes
DC input voltageDiffers600 V1000 V
Isolation typeTransformerlessTransformerless
Network voltageDiffers230 V400 V
Number of power levels77
Output currentDiffers18.3 A5.8 A
Pollution degree2/32/3
Power consumption (idle)1 W1 W
Short-circuit current per MPPT (max)Differs20 A18 A
Starting voltageDiffers80 V150 V
Number of maximum power point tracking (MPPT)22
Number of strings per MPPT11
Maximum input current per MPPTDiffers15 A13 A
Total Harmonic Distortion (THD)3%3%
Power factor0.80.8
Noise level25 dB25 dB
EfficiencyDiffers97.6%98.1%
Efficiency (EU)Differs97%97.3%
Photovoltaic (PV) charging supportedYesYes
CertificationKnown for oneEN 61000-6-2/3, IEC 62109-1/2 / EN 61000-6-2/3, IEC EN UNE 61683, IEC EN UNE 60068-1/2/14/30,UNE EN 62116:2014, IEC 61727:2004, UNE 217002:2020, UNE 217001:2020, ISO 9001, ISO 14001, ISO 45001
CompatibilityKnown for oneEN 61000-6-2/3, IEC 62109-1/2 / EN 61000-6-2/3, IEC EN UNE 61683, IEC EN UNE 60068-1/2/14/30, UNE EN 62116:2014, IEC 61727:2004, UNE 217002:2020, UNE 217001:2020, ISO 9001, ISO 14001, ISO 45001
Designidentical
Product colourBlack, WhiteBlack, White
Cooling typePassivePassive
International Protection (IP) codeIP65IP65
Power protection featuresOver voltageOver voltage
Wall mountableYesYes
Easy to installYesYes
Suitable for indoor useYesYes
Suitable for outdoor useYesYes
Displayidentical
Built-in displayYesYes
Display technologyOLEDOLED
Operational conditionsidentical
Operating temperature (T-T)30 - 60 °C30 - 60 °C
Operating relative humidity (H-H)0 - 100%0 - 100%
Operating altitude0 - 4000 m0 - 4000 m
Weight & dimensionsidentical
Width550 mm550 mm
Depth175 mm175 mm
Height410 mm410 mm
Weight26 kg26 kg
Chargeridentical
Charger typeMPPTMPPT
Ports & interfacesidentical
Interface typeMC4MC4
RS-485 ports11
Networkidentical
Wi-FiKnown for oneYes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
