Product comparison · 2 server barebones

ISY Server-I RP-S1200v3RPM vs ISY Server-I RP-S1200v3RPO

57specifications compared
4differ
53identical
0known for one product only

Key differences

Motherboard chipset
- Server-I RP-S1200v3RPM:Intel® C226
- Server-I RP-S1200v3RPO:Intel® C224
Number of storage drives supported
- Server-I RP-S1200v3RPM:4
- Server-I RP-S1200v3RPO:8
Storage drive sizes supported
- Server-I RP-S1200v3RPM:2.5,3.5"
- Server-I RP-S1200v3RPO:2.5"
Ethernet LAN data rates
- Server-I RP-S1200v3RPM:100,1000 Mbit/s
- Server-I RP-S1200v3RPO:10,100,1000 Mbit/s

Side by side

Differences highlightedShow differences only

Comparison of Server-I RP-S1200v3RPM, Server-I RP-S1200v3RPO
57 specifications	A ISY Server-I RP-S1200v3RPM View product	B ISY Server-I RP-S1200v3RPO View product
Processor1 differ
Motherboard chipsetDiffers	Intel® C226	Intel® C224
Processor socket	LGA 1150 (Socket H3)	LGA 1150 (Socket H3)
Processor family	Intel	Intel
Number of processors supported	1	1
Compatible processor series	Intel® Xeon®	Intel® Xeon®
Intel Xeon series	E3-1200	E3-1200
Memoryidentical
Number of DIMM slots	4	4
Supported memory types	DDR3-SDRAM	DDR3-SDRAM
Maximum internal memory	32 GB	32 GB
Maximum UDIMM memory	32 GB	32 GB
Supported UDIMM clock speeds	1333,1600 MHz	1333,1600 MHz
Memory form factor	240-pin DIMM	240-pin DIMM
ECC	Yes	Yes
Storage2 differ
Number of storage drives supportedDiffers	4	8
Hot-swap HDD bays	Yes	Yes
Storage drive sizes supportedDiffers	2.5,3.5"	2.5"
Supported storage drive interfaces	Serial ATA	Serial ATA
RAID levels	1, 5, 10	1, 5, 10
Embedded USB (eUSB) SSD option	Yes	Yes
Network1 differ
Ethernet LAN	Yes	Yes
Ethernet interface type	Fast Ethernet, Gigabit Ethernet	Fast Ethernet, Gigabit Ethernet
Ethernet LAN data ratesDiffers	100,1000 Mbit/s	10,100,1000 Mbit/s
Ports & interfacesidentical
USB 2.0 ports quantity	6	6
Ethernet LAN (RJ-45) ports	2	2
VGA (D-Sub) ports quantity	1	1
Serial ports quantity	1	1
Number of SATA connectors	6	6
Expansion slotsidentical
PCI Express slots version	3.0	3.0
PCI Express x8 slots	1	1
Featuresidentical
Integrated BMC with IPMI	Yes	Yes
Trusted Platform Module (TPM)	Yes	Yes
Trusted Platform Module (TPM) version	1.2	1.2
Backplanes support	Yes	Yes
Processor special featuresidentical
Intel® Virtualization Technology (Intel® VT)	VT-d	VT-d
Intel Rapid Storage Technology	No	No
Intel Advanced Management Technology	Yes	Yes
Intel Rapid Storage Technology enterprise	Yes	Yes
Intel Build Assurance Technology	Yes	Yes
Intelligent Platform Management Interface (IPMI) support	Yes	Yes
Intel Quiet Thermal Technology	No	No
Intel Remote Management Module Support	Yes	Yes
Intel Efficient Power Technology	No	No
Intel On-Demand Power Redundancy Technology	Yes	Yes
Intel Intelligent Power Node Manager	Yes	Yes
Intel Server Customization Technology	Yes	Yes
Intel® Matrix Storage Technology (Intel® MST)	No	No
Designidentical
Chassis type	Rack (1U)	Rack (1U)
Product colour	Black, Silver	Black, Silver
Rack-Friendly board	Yes	Yes
Heat sink	1	1
Heat sink included	Yes	Yes
Number of fans	3 fan(s)	3 fan(s)
Redundant fans support	No	No
Poweridentical
Power supply type	AC	AC
Power supply	450 W	450 W
Number of main power supplies	2	2
Redundant power supply (RPS) support	Yes	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
