Product comparison · 2 security cameras

Intellinet 551021 security camera vs Intellinet NBC30-IR 640 x 480 pixels

18specifications compared
9differ
9identical
19known for one product only

Key differences

Certification
- 551021 security camera:FCC, RoHS, CE
- NBC30-IR 640 x 480 pixels:FCC Class B, RoHS, CE
Optical sensor size
- 551021 security camera:25.4 / 3 mm (1 / 3")
- NBC30-IR 640 x 480 pixels:25.4 / 4 mm (1 / 4")
Maximum resolution
- 551021 security camera:1280 x 1024 pixels
- NBC30-IR 640 x 480 pixels:640 x 480 pixels
Operating temperature (T-T)
- 551021 security camera:0 - 50 °C
- NBC30-IR 640 x 480 pixels:-30 - 50 °C
Minimum RAM
- 551021 security camera:128 MB
- NBC30-IR 640 x 480 pixels:64 MB
Minimum processor
- 551021 security camera:Pentium IV, 2.8GHz
- NBC30-IR 640 x 480 pixels:Pentium 4 1.8 GHz
Weight
- 551021 security camera:900 g
- NBC30-IR 640 x 480 pixels:3.6 kg

Side by side

Differences highlightedShow differences only

Comparison of 551021, NBC30-IR
37 specifications	A Intellinet 551021 security camera Model 551021 View product	B Intellinet NBC30-IR 640 x 480 pixels Model NBC30-IR View product
Performance1 differ
CertificationDiffers	FCC, RoHS, CE	FCC Class B, RoHS, CE
Cameraidentical
Lens viewing angle, horizontalKnown for one	46°	Unknown — not stated by the source
Image sensor1 differ
Sensor type	CMOS	CMOS
Optical sensor sizeDiffers	25.4 / 3 mm (1 / 3")	25.4 / 4 mm (1 / 4")
Video1 differ
Maximum resolutionDiffers	1280 x 1024 pixels	640 x 480 pixels
Video formats supportedKnown for one	MPEG4	Unknown — not stated by the source
Frame rate	30 fps	30 fps
Audioidentical
Signal-to-Noise Ratio (SNR)Known for one	44 dB	Unknown — not stated by the source
Built-in microphoneKnown for one	Yes	Unknown — not stated by the source
Network1 differ
Supported network protocolsDiffers	TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DNS, NTP, UPnP, RTSP, RTP, HTTP, TCP, UDP, 3GPP/ISMA/RTSP	TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DNS, NTP, UPnP, RTSP, RTP, HTTP, TCP, UDP, 3GPP / ISMA / RTSP, Bonjour
Storageidentical
Flash memory	8 MB	8 MB
Internal memoryKnown for one	Unknown — not stated by the source	64 MB
Ports & interfacesidentical
Microphone in	Yes	Yes
DC-in jackKnown for one	Yes	Unknown — not stated by the source
Ethernet LAN (RJ-45) portsKnown for one	Unknown — not stated by the source	1
Securityidentical
Active tampering alarmKnown for one	Yes	Unknown — not stated by the source
IP address filteringKnown for one	Yes	Unknown — not stated by the source
Security algorithmsKnown for one	HTTPS	Unknown — not stated by the source
Management featuresidentical
Firmware upgradeableKnown for one	Yes	Unknown — not stated by the source
Poweridentical
Power source type	PoE	PoE
Power consumption (typical)	5 W	5 W
Power over Ethernet (PoE)	Yes	Yes
Operational conditions1 differ
Operating temperature (T-T)Differs	0 - 50 °C	-30 - 50 °C
Storage temperature (T-T)Known for one	0 - 60 °C	Unknown — not stated by the source
Operating relative humidity (H-H)	20 - 80%	20 - 80%
System requirements2 differ
Minimum RAMDiffers	128 MB	64 MB
Minimum processorDiffers	Pentium IV, 2.8GHz	Pentium 4 1.8 GHz
Weight & dimensions1 differ
WeightDiffers	900 g	3.6 kg
Other features1 differ
Compatible operating systemsDiffers	Windows 2000/XP/Vista/7 Linux Mac OS X Leopard 10.5	Windows 2000, XP, Vista, 7, Linux, Mac OS X
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3af	IEEE 802.3, IEEE 802.3u, IEEE 802.3af
Data transfer rateKnown for one	10 Mbit/s	Unknown — not stated by the source
Dimensions (WxDxH)Known for one	71 x 128 x 42 mm	Unknown — not stated by the source
F-number (relative aperture)Known for one	1.8	Unknown — not stated by the source
Networking featuresKnown for one	Fast Ethernet	Unknown — not stated by the source
Power requirementsKnown for one	12V, 1A	Unknown — not stated by the source
I/O portsKnown for one	1x RJ-45	Unknown — not stated by the source
Resolution descriptionKnown for one	1280 x 1024 (SXGA 5:4), 1280 x 720 (720p HDTV), 640 x 480 (VGA), 320 x 240 (QVGA)	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
