Product comparison · 2 security cameras

Canon VB-R13 Dome IP security camera Indoor vs Canon VB-R13VE Dome IP security camera Indoor

Add a product
  • 72specifications compared
  • 8differ
  • 64identical
  • 4known for one product only

Key differences

  • Mounting type
    • Ceiling
    • Ceiling/wall
  • Power consumption (max)
    • 11.3 W
    • 34.8 W
  • Power consumption (Power over Ethernet (PoE))
    • 10.7 W
    • 22.4 W
  • Operating temperature (T-T)
    • -10 - 50 °C
    • -10 - 55 °C
  • Height
    • 199 mm
    • 324 mm
  • Diameter
    • 19.9 cm
    • 22.9 cm
  • Weight
    • 1.99 kg
    • 3.53 kg

Side by side

Differences highlightedShow differences only
76 specifications
A

Canon

VB-R13 Dome IP security camera Indoor

Model VB-R13

View product
B

Canon

VB-R13VE Dome IP security camera Indoor

Model VB-R13VE

View product
Performance1 differ
TypeIP security cameraIP security camera
Placement supportedIndoorIndoor
Connectivity technologyWiredWired
PTZ controlKnown for oneYes
Preset pointsYesYes
Day/night modeYesYes
Languages supportSimplified Chinese, German, English, Spanish, French, Italian, Japanese, Russian, Thai, TurkishSimplified Chinese, German, English, Spanish, French, Italian, Japanese, Russian, Thai, Turkish
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AEAperture priority AE, Auto, Manual, Shutter priority AE
Number of languages1010
CertificationDiffersEN55032 B, FCC 15 B B, ICES-3/NMB-3 B, VCCI Class B, C-tick AS/NZS EN55032 B, CNS13438 B, KN32 B, EN55024, KN35, EN50581, IEC/UL/EN 60950-1, EN50130-4EN55032 A, FCC B A, ICES-3/NMB-3 A, VCCI A, C-tick AS/NZS EN55032 A, CNS13438 A, KN32 A, EN55024, KN35, EN50581, IEC/UL/EN 60950-1, IEC/UL/EN 60950-1/-22, EN50130-4, IEC/UL/EN 60529 IP66, IEC/UL/EN 62262 IK10, NEMA 250 4X
Design1 differ
Form factorDomeDome
Mounting typeDiffersCeilingCeiling/wall
Product colourBlack, WhiteBlack, White
Protection featuresKnown for oneDust resistant, Water resistant
International Protection (IP) codeKnown for oneIP66
Cameraidentical
Minimum illumination0.05 lx0.05 lx
Tilt angle range0 - 180°0 - 180°
Tilt speed450 °/sec450 °/sec
Pan range0 - 360°0 - 360°
Pan speed450 °/sec450 °/sec
White balanceAuto, Daylight, Fluorescent, Halogen, Manual, Mercury lamp, Sodium lampAuto, Daylight, Fluorescent, Halogen, Manual, Mercury lamp, Sodium lamp
Camera shutter speed1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000, 1/16000 s1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000, 1/16000 s
Image sensoridentical
Sensor typeCMOSCMOS
Optical sensor size25.4 / 3 mm (1 / 3")25.4 / 3 mm (1 / 3")
Progressive scanYesYes
Lens systemidentical
Zoom capabilityYesYes
Optical zoom30x30x
Digital zoom20x20x
Focal length range4.4 - 132 mm4.4 - 132 mm
Auto focusYesYes
Maximum aperture number4.64.6
Night visionidentical
Night visionYesYes
Videoidentical
Maximum resolution1920 x 1080 pixels1920 x 1080 pixels
Total megapixels2.1 MP2.1 MP
Video compression formatsH.264H.264
Supported graphics resolutions320 x 180, 320 x 240, 480 x 270, 640 x 360, 640 x 480 (VGA), 960 x 540, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)320 x 180, 320 x 240, 480 x 270, 640 x 360, 640 x 480 (VGA), 960 x 540, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
Frame rateKnown for one30 fps
Noise reductionYesYes
Image stabilizerYesYes
Automatic gain controlYesYes
Full HDYesYes
Privacy maskingYesYes
Audioidentical
Audio system full duplexYesYes
Voice codecsG.711G.711
Networkidentical
Ethernet LANYesYes
Wi-FiNoNo
Ethernet interface typeFast EthernetFast Ethernet
Networking standardsIEEE 802.1xIEEE 802.1x
Supported network protocolsIPv4, IPv6, TCP/IP, UDP, HTTP, FTP, SNMPv1/v2c/v3 (MIB2), DHCP, DNS, AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS, IPsec, ONVIF, WV-HTTPIPv4, IPv6, TCP/IP, UDP, HTTP, FTP, SNMPv1/v2c/v3 (MIB2), DHCP, DNS, AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS, IPsec, ONVIF, WV-HTTP
Cabling technology10/100Base-T(X)10/100Base-T(X)
Storageidentical
Built-in HDDNoNo
Card reader integratedYesYes
Compatible memory cardsSD, SDHC, SDXCSD, SDHC, SDXC
Ports & interfacesidentical
Microphone inYesYes
Headphone outputs11
InterfaceRJ-45RJ-45
Securityidentical
Password protection typeUserUser
Alert notification typeE-mailE-mail
Security algorithmsEAP-MD5, EAP-PEAP, EAP-TLS, EAP-TTLS, SSL/TLSEAP-MD5, EAP-PEAP, EAP-TLS, EAP-TTLS, SSL/TLS
Video motion detectionYesYes
Management featuresidentical
Web-based managementYesYes
Power2 differ
Power source typePoEPoE
AC input voltage100-240 V100-240 V
Power consumption (max)Differs11.3 W34.8 W
Power consumption (Power over Ethernet (PoE))Differs10.7 W22.4 W
Power over Ethernet (PoE)YesYes
Operational conditions1 differ
Operating temperature (T-T)Differs-10 - 50 °C-10 - 55 °C
Operating relative humidity (H-H)5 - 85%5 - 85%
System requirementsidentical
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, WindWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Wind
Mobile operating systems supportedAndroid, iOSAndroid, iOS
Minimum RAM2000 MB2000 MB
Weight & dimensions3 differ
HeightDiffers199 mm324 mm
DiameterDiffers19.9 cm22.9 cm
WeightDiffers1.99 kg3.53 kg
Packaging contentidentical
Number of cameras11
Other featuresidentical
Noise detectionYesYes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
