Product comparison · 2 raid controllers

Dell 405-AAMY RAID controller PCI Express 3.0 12 Gbit/s vs Dell PERC H730P

13specifications compared
3differ
10identical
13known for one product only

Key differences

Supported storage drive interfaces
- 405-AAMY RAID controller PCI Express 3.0 12 Gbit/s:SAS, Serial ATA III
- PERC H730P:SAS-3, Serial ATA III
Host interface
- 405-AAMY RAID controller PCI Express 3.0 12 Gbit/s:PCI Express
- PERC H730P:PCI Express x8

Side by side

Differences highlightedShow differences only

Comparison of 405-AAMY, PERC H730P
26 specifications	A Dell 405-AAMY RAID controller PCI Express 3.0 12 Gbit/s Model 405-AAMY View product	B Dell PERC H730P View product
Ports & interfaces2 differ
Supported storage drive interfacesDiffers	SAS, Serial ATA III	SAS-3, Serial ATA III
Host interfaceDiffers	PCI Express	PCI Express x8
PCI Express slots version	3.0	3.0
Internal mini-SAS portsKnown for one	2	Unknown — not stated by the source
Performance1 differ
RAID Level MigrationKnown for one	Yes	Unknown — not stated by the source
RAID levels	0, 1, 5, 6, 10, 50, 60	0, 1, 5, 6, 10, 50, 60
Data transfer rate	12 Gbit/s	12 Gbit/s
SSD support	Yes	Yes
Internal memory	2048 MB	2048 MB
Internal memory type	DDR3	DDR3
Memory clock speedKnown for one	1866 MHz	Unknown — not stated by the source
Number of devices supportedKnown for one	255	Unknown — not stated by the source
Online Capacity ExpansionKnown for one	Yes	Unknown — not stated by the source
S.M.A.R.T. supportKnown for one	Yes	Unknown — not stated by the source
Compatible productsDiffers	- PowerEdge R440 - PowerEdge R540 - PowerEdge R940xa - PowerEdge R940 - PowerEdge T140 - PowerEdge R840 - PowerEdge R340 - PowerEdge R7425 - PowerEdge R740 - PowerEdge R740XD - PowerEdge T640 - PowerEdge R240 - PowerEdge R640 - PowerEdge T440 - PowerEdge T340	- PowerEdge R740xd2 - PowerEdge XR2 - PowerEdge C6420
Processoridentical
Built-in processor	Yes	Yes
Processor familyKnown for one	Unknown — not stated by the source	LSI
Processor modelKnown for one	Unknown — not stated by the source	LSISAS3108
Poweridentical
Voltage	3.3 V	3.3 V
Technical detailsidentical
Product nameKnown for one	PERC H730	Unknown — not stated by the source
System requirementsidentical
Windows operating systems supportedKnown for one	Yes	Unknown — not stated by the source
Mac operating systems supportedKnown for one	Yes	Unknown — not stated by the source
Compatible operating systemsKnown for one	Unknown — not stated by the source	- Microsoft Windows Server 2008 R2 SP1 - Microsoft Windows Server 2012 - Microsoft Windows Server 2012 R1 & R2 - Red Hat Enterprise Linux 5.8 - Red Hat Enterprise Linux 6.5 - SUSE Linux Enterprise Server 10 SP4 - SUSE Linux Enterprise Server 11 SP3 - VMware ESXi 5.1 - VMware 6.0
Operational conditionsidentical
Operating temperature (T-T)Known for one	0 - 60 °C	Unknown — not stated by the source
Weight & dimensionsidentical
Width	167.6 mm	167.6 mm
Height	64.4 mm	64.4 mm

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
