Product comparison · 2 raid controllers

Dell 405-AAJW RAID controller PCI Express 3.0 1200 Gbit/s vs Dell H730 RAID controller PCI Express x8 3.0 12 Gbit/s

9specifications compared
5differ
4identical
19known for one product only

Key differences

Supported storage drive interfaces
- 405-AAJW RAID controller PCI Express 3.0 1200 Gbit/s:SAS
- H730 RAID controller PCI Express x8 3.0 12 Gbit/s:SAS, Serial ATA III
Host interface
- 405-AAJW RAID controller PCI Express 3.0 1200 Gbit/s:PCI Express
- H730 RAID controller PCI Express x8 3.0 12 Gbit/s:PCI Express x8
Data transfer rate
- 405-AAJW RAID controller PCI Express 3.0 1200 Gbit/s:1200 Gbit/s
- H730 RAID controller PCI Express x8 3.0 12 Gbit/s:12 Gbit/s
Number of devices supported
- 405-AAJW RAID controller PCI Express 3.0 1200 Gbit/s:8
- H730 RAID controller PCI Express x8 3.0 12 Gbit/s:255

Side by side

Differences highlightedShow differences only

Comparison of 405-AAJW, H730
28 specifications	A Dell 405-AAJW RAID controller PCI Express 3.0 1200 Gbit/s Model 405-AAJW View product	B Dell H730 RAID controller PCI Express x8 3.0 12 Gbit/s Model H730 View product
Ports & interfaces2 differ
Supported storage drive interfacesDiffers	SAS	SAS, Serial ATA III
Host interfaceDiffers	PCI Express	PCI Express x8
PCI Express slots version	3.0	3.0
Internal mini-SAS portsKnown for one	Unknown — not stated by the source	2
Performance3 differ
RAID Level MigrationKnown for one	Unknown — not stated by the source	Yes
RAID levelsKnown for one	Unknown — not stated by the source	0, 1, 5, 6, 10, 50, 60
Data transfer rateDiffers	1200 Gbit/s	12 Gbit/s
SSD supportKnown for one	Unknown — not stated by the source	Yes
Internal memoryKnown for one	Unknown — not stated by the source	1024 MB
Internal memory typeKnown for one	Unknown — not stated by the source	DDR3
Memory clock speedKnown for one	Unknown — not stated by the source	1333 MHz
Number of devices supportedDiffers	8	255
Online Capacity ExpansionKnown for one	Unknown — not stated by the source	Yes
S.M.A.R.T. support	Yes	Yes
Compatible productsDiffers	- PowerEdge R630 - PowerEdge R6415 - PowerEdge R740XD - PowerEdge R940 - PowerEdge R730 - Poweredge R830 - PowerEdge R640 - PowerEdge R740 - PowerEdge R730XD - PowerEdge R430 - PowerEdge R530 - PowerEdge R730xd XL - PowerEdge R7415	PowerEdge VRTX
LED indicatorsKnown for one	Yes	Unknown — not stated by the source
Processoridentical
Built-in processor	Yes	Yes
Processor familyKnown for one	LSI	Unknown — not stated by the source
Processor modelKnown for one	LSISAS3008	Unknown — not stated by the source
Poweridentical
VoltageKnown for one	Unknown — not stated by the source	3.3 V
System requirementsidentical
Linux operating systems supported	Yes	Yes
Compatible operating systemsKnown for one	Unknown — not stated by the source	Microsoft Windows Server 2008 R2 SP1 Microsoft Windows Server 2012 Microsoft Windows Server 2012 R1 & R2 Red Hat Enterprise Linux 5.8 Red Hat Enterprise Linux 6.5 SUSE Linux Enterprise Server 10 SP4 SUSE Linux Enterprise Server 11 SP3 VMware ESXi 5.1 VMware 6.0
Server operating systems supportedKnown for one	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2	Unknown — not stated by the source
Operational conditionsidentical
Operating temperature (T-T)Known for one	Unknown — not stated by the source	0 - 60 °C
Weight & dimensionsidentical
WidthKnown for one	Unknown — not stated by the source	64.4 mm
DepthKnown for one	Unknown — not stated by the source	167.6 mm
Logistics dataidentical
Harmonized System (HS) codeKnown for one	84733080	Unknown — not stated by the source
Other featuresidentical
Other operating systems supportedKnown for one	VMware vSphere ESXi	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
