Product comparison · 2 raid controllers

Dell 405-AAJW RAID controller PCI Express 3.0 1200 Gbit/s vs Dell 470-12373 + 405-11540

4specifications compared
4differ
0identical
13known for one product only

Key differences

Supported storage drive interfaces
- 405-AAJW RAID controller PCI Express 3.0 1200 Gbit/s:SAS
- 470-12373 + 405-11540:SAS-2
Host interface
- 405-AAJW RAID controller PCI Express 3.0 1200 Gbit/s:PCI Express
- 470-12373 + 405-11540:PCI Express x8
PCI Express slots version
- 405-AAJW RAID controller PCI Express 3.0 1200 Gbit/s:3.0
- 470-12373 + 405-11540:2.0

Side by side

Differences highlightedShow differences only

Comparison of 405-AAJW, 470-12373 + 405-11540
17 specifications	A Dell 405-AAJW RAID controller PCI Express 3.0 1200 Gbit/s Model 405-AAJW View product	B Dell 470-12373 + 405-11540 View product
Ports & interfaces3 differ
Supported storage drive interfacesDiffers	SAS	SAS-2
Host interfaceDiffers	PCI Express	PCI Express x8
PCI Express slots versionDiffers	3.0	2.0
Performance1 differ
Data transfer rateKnown for one	1200 Gbit/s	Unknown — not stated by the source
LED indicatorsKnown for one	Yes	Unknown — not stated by the source
Number of devices supportedKnown for one	8	Unknown — not stated by the source
S.M.A.R.T. supportKnown for one	Yes	Unknown — not stated by the source
Compatible productsDiffers	- PowerEdge R630 - PowerEdge R6415 - PowerEdge R740XD - PowerEdge R940 - PowerEdge R730 - Poweredge R830 - PowerEdge R640 - PowerEdge R740 - PowerEdge R730XD - PowerEdge R430 - PowerEdge R530 - PowerEdge R730xd XL - PowerEdge R7415	DELL PowerEdge R210, R210 II, T110, T110 II
RAID levelsKnown for one	Unknown — not stated by the source	0, 1, 10
Processoridentical
Built-in processorKnown for one	Yes	Unknown — not stated by the source
Processor familyKnown for one	LSI	Unknown — not stated by the source
Processor modelKnown for one	LSISAS3008	Unknown — not stated by the source
System requirementsidentical
Linux operating systems supportedKnown for one	Yes	Unknown — not stated by the source
Server operating systems supportedKnown for one	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2	Unknown — not stated by the source
Logistics dataidentical
Harmonized System (HS) codeKnown for one	84733080	Unknown — not stated by the source
Other featuresidentical
Other operating systems supportedKnown for one	VMware vSphere ESXi	Unknown — not stated by the source
Technical detailsidentical
Data transfer rateKnown for one	Unknown — not stated by the source	600 Mbit/s

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
