Product comparison · 2 raid controllers

Acer TC.32300.034 RAID controller PCI Express x8 2.0 6 Gbit/s vs Acer TC.32300.042 RAID controller PCI Express x8 2.0 6 Gbit/s

10specifications compared
2differ
8identical
1known for one product only

Key differences

Internal SATA ports quantity
- TC.32300.034 RAID controller PCI Express x8 2.0 6 Gbit/s:8
- TC.32300.042 RAID controller PCI Express x8 2.0 6 Gbit/s:16
PCI Card form factor
- TC.32300.034 RAID controller PCI Express x8 2.0 6 Gbit/s:Half-height (low-profile)
- TC.32300.042 RAID controller PCI Express x8 2.0 6 Gbit/s:Full-height

Side by side

Differences highlightedShow differences only

Comparison of TC.32300.034, TC.32300.042
11 specifications	A Acer TC.32300.034 RAID controller PCI Express x8 2.0 6 Gbit/s Model TC.32300.034 View product	B Acer TC.32300.042 RAID controller PCI Express x8 2.0 6 Gbit/s Model TC.32300.042 View product
Ports & interfaces1 differ
Supported storage drive interfaces	SAS, Serial ATA	SAS, Serial ATA
Host interface	PCI Express x8	PCI Express x8
PCI Express slots version	2.0	2.0
Internal SATA ports quantityDiffers	8	16
Performanceidentical
RAID levels	0, 1, 5, 6, 10, 50, 60	0, 1, 5, 6, 10, 50, 60
Data transfer rate	6 Gbit/s	6 Gbit/s
SSD supportKnown for one	Unknown — not stated by the source	No
Internal memory	512 MB	512 MB
Internal memory type	DDR2	DDR2
Memory clock speed	800 MHz	800 MHz
Other features1 differ
PCI Card form factorDiffers	Half-height (low-profile)	Full-height

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
