Product comparison · 2 rack cabinets

Equip Dynamic Flex 19' Cabinet, 26U vs Equip Dynamic Flex 19' Cabinet, 42U

70specifications compared
12differ
58identical
0known for one product only

Key differences

Rack capacity
- Dynamic Flex 19' Cabinet, 26U:26U
- Dynamic Flex 19' Cabinet, 42U:42U
Width
- Dynamic Flex 19' Cabinet, 26U:800 mm
- Dynamic Flex 19' Cabinet, 42U:600 mm
Height
- Dynamic Flex 19' Cabinet, 26U:1342 mm
- Dynamic Flex 19' Cabinet, 42U:2053 mm
Inner width
- Dynamic Flex 19' Cabinet, 26U:79 cm
- Dynamic Flex 19' Cabinet, 42U:59 cm
Inner height
- Dynamic Flex 19' Cabinet, 26U:97.8 cm
- Dynamic Flex 19' Cabinet, 42U:186.7 cm
Weight
- Dynamic Flex 19' Cabinet, 26U:86 kg
- Dynamic Flex 19' Cabinet, 42U:83.7 kg
Package width
- Dynamic Flex 19' Cabinet, 26U:880 mm
- Dynamic Flex 19' Cabinet, 42U:680 mm
Package height
- Dynamic Flex 19' Cabinet, 26U:1482 mm
- Dynamic Flex 19' Cabinet, 42U:2193 mm

Side by side

Differences highlightedShow differences only

Comparison of EDF-26-8080-G-HJAA, EDF-42-6080-G-BIAA
70 specifications	A Equip Dynamic Flex 19' Cabinet, 26U Model EDF-26-8080-G-HJAA View product	B Equip Dynamic Flex 19' Cabinet, 42U Model EDF-42-6080-G-BIAA View product
Features1 differ
Rack capacityDiffers	26U	42U
Type	Freestanding rack	Freestanding rack
Maximum weight capacity	600 kg	600 kg
Maximum weight capacity (rolling)	600 kg	600 kg
Product colour	Light grey	Light grey
Material	Steel	Steel
Frame type	Closed	Closed
Product design	4-post	4-post
Back door construction	Steel	Steel
Front door construction	Tempered glass	Tempered glass
Side panel construction	Steel	Steel
Removable back door	Yes	Yes
Removable front door	Yes	Yes
Removable side panels	Yes	Yes
Side panels included	Yes	Yes
Key lock	Yes	Yes
Back door key lock	No	No
Front door key lock	Yes	Yes
Side panel key lock	Yes	Yes
Rack rail thickness	1.5 mm	1.5 mm
Rack rails	Yes	Yes
Adjustable depth	No	No
Adjustable stand	No	No
Adjustable feet	Yes	Yes
Feet adjustment	3 cm	3 cm
Cooling type	Passive	Passive
Soundproof	No	No
Main PDU	No	No
Monitoring	No	No
Cable management	No	No
Stabilising foot screw	Yes	Yes
Number of stabilising foot screws	4 pc(s)	4 pc(s)
Castor wheels	No	No
Door opening angle	120°	120°
Assembly required	No	No
Preassembled	Yes	Yes
Built-in UPS	No	No
Weight & dimensions5 differ
Size (imperial)	56.9 cm (22.4")	56.9 cm (22.4")
WidthDiffers	800 mm	600 mm
Depth	800 mm	800 mm
HeightDiffers	1342 mm	2053 mm
Inner widthDiffers	79 cm	59 cm
Inner depth	79 cm	79 cm
Inner heightDiffers	97.8 cm	186.7 cm
WeightDiffers	86 kg	83.7 kg
Mounting depth (min)	56 cm	56 cm
Mounting depth (max)	74 cm	74 cm
Packaging data2 differ
Nuts included	Yes	Yes
Number of nuts	28	28
Number of screws	28	28
Screws included	Yes	Yes
Plinth panel	No	No
Temperature sensor	No	No
Grounding kit	Yes	Yes
Mounting kit	No	No
Wall mounting kit	No	No
Quick installation guide	No	No
Manual	Yes	Yes
Package widthDiffers	880 mm	680 mm
Package depth	880 mm	880 mm
Package heightDiffers	1482 mm	2193 mm
Technical details4 differ
Pallet gross weightDiffers	103.6 kg	95.7 kg
Pallet net height	15 cm	15 cm
Pallet net length	88 cm	88 cm
Pallet net weightDiffers	13.5 kg	8 kg
Pallet net widthDiffers	88 cm	68 cm
Total carbon footprint (kg of CO2e)Differs	14.706	14.3127
Logistics dataidentical
Country of origin	Turkey	Turkey
Harmonized System (HS) code	853710980019	853710980019
Products per master (outer) case	1 pc(s)	1 pc(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
