Product comparison · 2 power supply units

MSI MAG A600DN vs XPG CYBERCOREII1000P-BKCAU power supply unit

21specifications compared
11differ
10identical
41known for one product only

Key differences

Total power
- MAG A600DN:650 W
- CYBERCOREII1000P-BKCAU power supply unit:1000 W
AC input voltage
- MAG A600DN:100 - 240 V
- CYBERCOREII1000P-BKCAU power supply unit:110 - 240 V
Number of SATA power connectors
- MAG A600DN:5
- CYBERCOREII1000P-BKCAU power supply unit:8
Peripheral (Molex) power connectors (4-pin)
- MAG A600DN:2
- CYBERCOREII1000P-BKCAU power supply unit:4
PCI Express power connectors (6+2 pin)
- MAG A600DN:2
- CYBERCOREII1000P-BKCAU power supply unit:6
Floppy disk drive connector
- MAG A600DN:No
- CYBERCOREII1000P-BKCAU power supply unit:Yes
Cabling type
- MAG A600DN:Non-Modular
- CYBERCOREII1000P-BKCAU power supply unit:Fully-Modular
80 PLUS certification
- MAG A600DN:80 PLUS Bronze
- CYBERCOREII1000P-BKCAU power supply unit:80 PLUS Platinum

Side by side

Differences highlightedShow differences only

Comparison of MAG A600DN, CYBERCOREII1000P-BKCAU
62 specifications	A MSI MAG A600DN View product	B XPG CYBERCOREII1000P-BKCAU power supply unit Model CYBERCOREII1000P-BKCAU View product
Power3 differ
Total powerDiffers	650 W	1000 W
AC input voltageDiffers	100 - 240 V	110 - 240 V
AC input frequencyKnown for one	Unknown — not stated by the source	50/60 Hz
Input currentKnown for one	Unknown — not stated by the source	13 A
Power factorKnown for one	Unknown — not stated by the source	0.99
Power protection featuresDiffers	Over current, Over power, Over voltage, Short circuit	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Maximum input current (@110V)Known for one	10 A	Unknown — not stated by the source
Maximum input current (@220V)Known for one	5 A	Unknown — not stated by the source
Power Factor Correction (PFC) typeKnown for one	Active	Unknown — not stated by the source
Combined power (+3.3V)Known for one	105 W	Unknown — not stated by the source
Combined power (+12V)Known for one	576 W	Unknown — not stated by the source
Combined power (+5V)Known for one	105 W	Unknown — not stated by the source
Combined power (-12V)Known for one	3.6 W	Unknown — not stated by the source
Combined power (+5Vsb)Known for one	12.5 W	Unknown — not stated by the source
Max output current (+3.3V)Known for one	14 A	Unknown — not stated by the source
Max output current (+12V)Known for one	25 A	Unknown — not stated by the source
Max output current (+5V)Known for one	25 A	Unknown — not stated by the source
Max output current (-12V)Known for one	0.3 A	Unknown — not stated by the source
Max output current (+5Vsb)Known for one	2.5 A	Unknown — not stated by the source
EfficiencyKnown for one	85%	Unknown — not stated by the source
Ports & interfaces5 differ
Motherboard power connector	20+4 pin ATX	20+4 pin ATX
Motherboard power cable lengthKnown for one	Unknown — not stated by the source	75 cm
Number of SATA power connectorsDiffers	5	8
SATA power cable lengthKnown for one	Unknown — not stated by the source	150,600 mm
Peripheral (Molex) power connectors (4-pin)Differs	2	4
Peripheral (Molex) power cable lengthKnown for one	Unknown — not stated by the source	150,600 mm
PCI Express power connectors (6+2 pin)Differs	2	6
PCI Express power connectors (12+4 pin)Known for one	Unknown — not stated by the source	1
PCI Express power connectors (12+4 pin) cable lengthKnown for one	Unknown — not stated by the source	650 mm
PCI Express power cable lengthKnown for one	Unknown — not stated by the source	75 cm
CPU power connector (4+4 pin)	Yes	Yes
CPU power cable lengthKnown for one	Unknown — not stated by the source	75 cm
Floppy disk drive cable lengthKnown for one	Unknown — not stated by the source	15 cm
Floppy disk drive connectorDiffers	No	Yes
Floppy drive power connectorKnown for one	Unknown — not stated by the source	1
Cabling typeDiffers	Non-Modular	Fully-Modular
EPS power connector (4+4 pin)Known for one	Yes	Unknown — not stated by the source
ATX Power connector (24-pin)Known for one	No	Unknown — not stated by the source
ATX power connector (20+4 pin)Known for one	Yes	Unknown — not stated by the source
Performance1 differ
Purpose	PC	PC
Power supply unit (PSU) form factor	ATX	ATX
80 PLUS certificationDiffers	80 PLUS Bronze	80 PLUS Platinum
ATX versionKnown for one	Unknown — not stated by the source	3.0
Bearing technologyKnown for one	Unknown — not stated by the source	DBB
Designidentical
Product colour	Black	Black
Cooling type	Active	Active
Fan diameter	12 cm	12 cm
Number of fans	1 fan(s)	1 fan(s)
Fan locationKnown for one	Unknown — not stated by the source	Top
On/off switch	Yes	Yes
Packaging contentidentical
Cables includedKnown for one	Unknown — not stated by the source	AC
Cable tie(s) includedKnown for one	Unknown — not stated by the source	Yes
Certificatesidentical
Compliance certificatesKnown for one	Unknown — not stated by the source	BSMI, CB, CE, Federal Communications Commission (FCC), cTUVus, UKCA
CertificationKnown for one	Unknown — not stated by the source	CQC, NOM
Weight & dimensions2 differ
WidthDiffers	150 mm	160 mm
DepthDiffers	140 mm	150 mm
Height	86 mm	86 mm
Packaging dataidentical
Package typeKnown for one	Unknown — not stated by the source	Box
Technical detailsidentical
Sustainability complianceKnown for one	Unknown — not stated by the source	Yes
Logistics dataidentical
Country of originKnown for one	Unknown — not stated by the source	China
Warranty periodKnown for one	Unknown — not stated by the source	10 year(s)
Harmonized System (HS) codeKnown for one	84733020	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
