Product comparison · 2 power supply units

itek ITPSTFX130 power supply unit vs itek WN600 power supply unit

14specifications compared
9differ
5identical
10known for one product only

Key differences

Total power
- ITPSTFX130 power supply unit:130 W
- WN600 power supply unit:600 W
AC input voltage
- ITPSTFX130 power supply unit:220 V
- WN600 power supply unit:100 - 240 V
Motherboard power connector
- ITPSTFX130 power supply unit:20+4 pin ATX
- WN600 power supply unit:24-pin ATX
Number of SATA power connectors
- ITPSTFX130 power supply unit:2
- WN600 power supply unit:7
Peripheral (Molex) power connectors (4-pin)
- ITPSTFX130 power supply unit:1
- WN600 power supply unit:3
Fan diameter
- ITPSTFX130 power supply unit:4 cm
- WN600 power supply unit:12 cm
Width
- ITPSTFX130 power supply unit:48 mm
- WN600 power supply unit:157.5 mm
Depth
- ITPSTFX130 power supply unit:170 mm
- WN600 power supply unit:150 mm

Side by side

Differences highlightedShow differences only

Comparison of ITPSTFX130, WN600
24 specifications	A itek ITPSTFX130 power supply unit Model ITPSTFX130 View product	B itek WN600 power supply unit Model WN600 View product
Power2 differ
Total powerDiffers	130 W	600 W
AC input voltageDiffers	220 V	100 - 240 V
Power Factor Correction (PFC) typeKnown for one	Unknown — not stated by the source	Active
Power protection featuresKnown for one	Unknown — not stated by the source	Over current, Over power, Over voltage, Short circuit, Under voltage
Ports & interfaces3 differ
Motherboard power connectorDiffers	20+4 pin ATX	24-pin ATX
Number of SATA power connectorsDiffers	2	7
Peripheral (Molex) power connectors (4-pin)Differs	1	3
PCI Express power connectors (6+2 pin)Known for one	Unknown — not stated by the source	2
Cabling type	Non-Modular	Non-Modular
Performanceidentical
Purpose	PC	PC
Power supply unit (PSU) form factor	ATX	ATX
80 PLUS certificationKnown for one	Unknown — not stated by the source	80 PLUS White
ATX versionKnown for one	Unknown — not stated by the source	2.31
Mean time between failures (MTBF)	100000 h	100000 h
Design1 differ
Product colour	Black	Black
Cooling typeKnown for one	Unknown — not stated by the source	Active
Fan diameterDiffers	4 cm	12 cm
Number of fansKnown for one	Unknown — not stated by the source	1 fan(s)
On/off switchKnown for one	Unknown — not stated by the source	Yes
Weight & dimensions3 differ
WidthDiffers	48 mm	157.5 mm
DepthDiffers	170 mm	150 mm
HeightDiffers	55 mm	86 mm
Packaging dataidentical
Package weightKnown for one	Unknown — not stated by the source	2.01 kg
Package typeKnown for one	Unknown — not stated by the source	Box

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
