Product comparison · 2 power supply units

Hiditec BZX650 V2 80PLUS BRONZE vs Hiditec RL550 power supply unit

39specifications compared
19differ
20identical
14known for one product only

Key differences

Total power
- BZX650 V2 80PLUS BRONZE:650 W
- RL550 power supply unit:550 W
AC input voltage
- BZX650 V2 80PLUS BRONZE:100 - 240 V
- RL550 power supply unit:200 - 240 V
Combined power (+12V)
- BZX650 V2 80PLUS BRONZE:648 W
- RL550 power supply unit:540 W
Max output current (+12V)
- BZX650 V2 80PLUS BRONZE:54 A
- RL550 power supply unit:45 A
Max output current (-12V)
- BZX650 V2 80PLUS BRONZE:0.5 A
- RL550 power supply unit:0.3 A
Max output current (+5Vsb)
- BZX650 V2 80PLUS BRONZE:3 A
- RL550 power supply unit:2.5 A
Motherboard power cable length
- BZX650 V2 80PLUS BRONZE:60 cm
- RL550 power supply unit:50 cm
Number of SATA power connectors
- BZX650 V2 80PLUS BRONZE:5
- RL550 power supply unit:4

Side by side

Differences highlightedShow differences only

Comparison of BZX650, RL550
53 specifications	A Hiditec BZX650 V2 80PLUS BRONZE Model BZX650 View product	B Hiditec RL550 power supply unit Model RL550 View product
Power7 differ
Total powerDiffers	650 W	550 W
AC input voltageDiffers	100 - 240 V	200 - 240 V
AC input frequency	50/60 Hz	50/60 Hz
Power Factor Correction (PFC) type	Active	Active
Combined power (+3.3V)	100 W	100 W
Combined power (+12V)Differs	648 W	540 W
Combined power (+5V)	100 W	100 W
Combined power (-12V)	3.6 W	3.6 W
Combined power (+5Vsb)	12.5 W	12.5 W
Max output current (+3.3V)	20 A	20 A
Max output current (+12V)Differs	54 A	45 A
Max output current (+5V)	20 A	20 A
Max output current (-12V)Differs	0.5 A	0.3 A
Max output current (+5Vsb)Differs	3 A	2.5 A
Efficiency	87%	87%
Power protection featuresDiffers	Over power, Over voltage, Short circuit, Under voltage	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Ports & interfaces7 differ
Motherboard power connector	20+4 pin ATX	20+4 pin ATX
Motherboard power cable lengthDiffers	60 cm	50 cm
Number of SATA power connectorsDiffers	5	4
SATA power cable lengthDiffers	550 mm	130,300 mm
Peripheral (Molex) power connectors (4-pin)Differs	2	3
Peripheral (Molex) power cable lengthDiffers	550 mm	130,300 mm
EPS power connector (4+4 pin)	Yes	Yes
PCI Express power connectors (6+2 pin)Differs	4	1
PCI Express power cable lengthKnown for one	55 cm	Unknown — not stated by the source
ATX power connector (20+4 pin)Known for one	Yes	Unknown — not stated by the source
Floppy drive power connectorKnown for one	1	Unknown — not stated by the source
Number of EPS connectorsKnown for one	2	Unknown — not stated by the source
PCI Express connectorKnown for one	Yes	Unknown — not stated by the source
Cabling typeDiffers	Fully-Modular	Non-Modular
Floppy disk drive cable lengthKnown for one	Unknown — not stated by the source	65 cm
Floppy disk drive connectorKnown for one	Unknown — not stated by the source	Yes
Performanceidentical
Purpose	PC	PC
Power supply unit (PSU) form factor	ATX	ATX
80 PLUS certification	80 PLUS Bronze	80 PLUS Bronze
Bearing technologyKnown for one	FDB	Unknown — not stated by the source
Mean time between failures (MTBF)	100000 h	100000 h
Design2 differ
Product colour	Black	Black
Cooling type	Active	Active
Fan diameterDiffers	14 cm	12 cm
Number of fans	1 fan(s)	1 fan(s)
Fan locationDiffers	Front	Top
On/off switch	Yes	Yes
IlluminationKnown for one	Unknown — not stated by the source	No
Certificatesidentical
Compliance certificatesKnown for one	CE, Federal Communications Commission (FCC), RoHS	Unknown — not stated by the source
CertificationKnown for one	CE , FCC , RoHs	Unknown — not stated by the source
Weight & dimensions3 differ
Width	150 mm	150 mm
DepthDiffers	86 mm	85 mm
HeightDiffers	160 mm	140 mm
WeightDiffers	2.2 kg	1.75 kg
Technical detailsidentical
Sustainability complianceKnown for one	Yes	Unknown — not stated by the source
Logistics dataidentical
Warranty periodKnown for one	5 year(s)	Unknown — not stated by the source
Packaging dataidentical
Package typeKnown for one	Unknown — not stated by the source	Box

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
