Product comparison · 2 power supply units

Hiditec BZX650 V2 80PLUS BRONZE vs Hiditec GDX1050 v2

31specifications compared
6differ
25identical
19known for one product only

Key differences

Total power
- BZX650 V2 80PLUS BRONZE:650 W
- GDX1050 v2:1050 W
Max output current (+12V)
- BZX650 V2 80PLUS BRONZE:54 A
- GDX1050 v2:88 A
Peripheral (Molex) power connectors (4-pin)
- BZX650 V2 80PLUS BRONZE:2
- GDX1050 v2:3
PCI Express power connectors (6+2 pin)
- BZX650 V2 80PLUS BRONZE:4
- GDX1050 v2:6
80 PLUS certification
- BZX650 V2 80PLUS BRONZE:80 PLUS Bronze
- GDX1050 v2:80 PLUS Gold

Side by side

Differences highlightedShow differences only

Comparison of BZX650, GDX1050 v2
50 specifications	A Hiditec BZX650 V2 80PLUS BRONZE Model BZX650 View product	B Hiditec GDX1050 v2 View product
Power3 differ
Total powerDiffers	650 W	1050 W
AC input voltage	100 - 240 V	100 - 240 V
AC input frequencyKnown for one	50/60 Hz	Unknown — not stated by the source
Power Factor Correction (PFC) typeKnown for one	Active	Unknown — not stated by the source
Combined power (+3.3V)Known for one	100 W	Unknown — not stated by the source
Combined power (+12V)Known for one	648 W	Unknown — not stated by the source
Combined power (+5V)Known for one	100 W	Unknown — not stated by the source
Combined power (-12V)Known for one	3.6 W	Unknown — not stated by the source
Combined power (+5Vsb)Known for one	12.5 W	Unknown — not stated by the source
Max output current (+3.3V)	20 A	20 A
Max output current (+12V)Differs	54 A	88 A
Max output current (+5V)	20 A	20 A
Max output current (-12V)	0.5 A	0.5 A
Max output current (+5Vsb)	3 A	3 A
EfficiencyKnown for one	87%	Unknown — not stated by the source
Power protection featuresDiffers	Over power, Over voltage, Short circuit, Under voltage	Over power, Over voltage, Short circuit, Surge & inrush protection (SIP), Under voltage
Ports & interfaces2 differ
Motherboard power connector	20+4 pin ATX	20+4 pin ATX
Motherboard power cable lengthKnown for one	60 cm	Unknown — not stated by the source
Number of SATA power connectorsKnown for one	5	Unknown — not stated by the source
SATA power cable lengthKnown for one	550 mm	Unknown — not stated by the source
Peripheral (Molex) power connectors (4-pin)Differs	2	3
Peripheral (Molex) power cable lengthKnown for one	550 mm	Unknown — not stated by the source
EPS power connector (4+4 pin)	Yes	Yes
PCI Express power connectors (6+2 pin)Differs	4	6
PCI Express power cable lengthKnown for one	55 cm	Unknown — not stated by the source
ATX power connector (20+4 pin)Known for one	Yes	Unknown — not stated by the source
Floppy drive power connectorKnown for one	1	Unknown — not stated by the source
Number of EPS connectorsKnown for one	2	Unknown — not stated by the source
PCI Express connector	Yes	Yes
Cabling type	Fully-Modular	Fully-Modular
Performance1 differ
Purpose	PC	PC
Power supply unit (PSU) form factor	ATX	ATX
80 PLUS certificationDiffers	80 PLUS Bronze	80 PLUS Gold
Bearing technology	FDB	FDB
Mean time between failures (MTBF)	100000 h	100000 h
ATX versionKnown for one	Unknown — not stated by the source	3.0
Designidentical
Product colour	Black	Black
Cooling type	Active	Active
Fan diameter	14 cm	14 cm
Number of fans	1 fan(s)	1 fan(s)
Fan locationKnown for one	Front	Unknown — not stated by the source
On/off switch	Yes	Yes
Certificatesidentical
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS	CE, Federal Communications Commission (FCC), RoHS
CertificationKnown for one	CE , FCC , RoHs	Unknown — not stated by the source
Weight & dimensionsidentical
Width	150 mm	150 mm
Depth	86 mm	86 mm
Height	160 mm	160 mm
Weight	2.2 kg	2.2 kg
Technical detailsidentical
Sustainability compliance	Yes	Yes
Logistics dataidentical
Warranty period	5 year(s)	5 year(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
