Product comparison · 2 power supply units

Aerocool LUXPRORGB1000M power supply unit vs Aerocool LUXPRORGB650M power supply unit

40specifications compared
14differ
26identical
0known for one product only

Key differences

Total power
- LUXPRORGB1000M power supply unit:1000 W
- LUXPRORGB650M power supply unit:650 W
AC input voltage
- LUXPRORGB1000M power supply unit:100 - 240 V
- LUXPRORGB650M power supply unit:200 - 240 V
Input current
- LUXPRORGB1000M power supply unit:13 - 6.5 A
- LUXPRORGB650M power supply unit:5 A
Combined power (+3.3V)
- LUXPRORGB1000M power supply unit:130 W
- LUXPRORGB650M power supply unit:120 W
Combined power (+12V)
- LUXPRORGB1000M power supply unit:996 W
- LUXPRORGB650M power supply unit:612 W
Combined power (+5V)
- LUXPRORGB1000M power supply unit:130 W
- LUXPRORGB650M power supply unit:120 W
Combined power (+5Vsb)
- LUXPRORGB1000M power supply unit:15 W
- LUXPRORGB650M power supply unit:12.5 W
Max output current (+12V)
- LUXPRORGB1000M power supply unit:83 A
- LUXPRORGB650M power supply unit:51 A

Side by side

Differences highlightedShow differences only

Comparison of LUXPRORGB1000M, LUXPRORGB650M
40 specifications	A Aerocool LUXPRORGB1000M power supply unit Model LUXPRORGB1000M View product	B Aerocool LUXPRORGB650M power supply unit Model LUXPRORGB650M View product
Power10 differ
Total powerDiffers	1000 W	650 W
AC input voltageDiffers	100 - 240 V	200 - 240 V
AC input frequency	47 - 63 Hz	47 - 63 Hz
Input currentDiffers	13 - 6.5 A	5 A
Power factor	0.9	0.9
Power Factor Correction (PFC) type	Active	Active
Combined power (+3.3V)Differs	130 W	120 W
Combined power (+12V)Differs	996 W	612 W
Combined power (+5V)Differs	130 W	120 W
Combined power (-12V)	3.6 W	3.6 W
Combined power (+5Vsb)Differs	15 W	12.5 W
Max output current (+3.3V)	20 A	20 A
Max output current (+12V)Differs	83 A	51 A
Max output current (+5V)	20 A	20 A
Max output current (-12V)	0.3 A	0.3 A
Max output current (+5Vsb)Differs	3 A	2.5 A
EfficiencyDiffers	90%	88%
Ports & interfaces1 differ
Motherboard power connector	20+4 pin ATX	20+4 pin ATX
Motherboard power cable length	55 cm	55 cm
Number of PATA power connectors	3	3
Number of SATA power connectors	6	6
SATA power cable lengthDiffers	850,550,700 mm	550,700,850 mm
PCI Express power connectors (6+2 pin)	2	2
PCI Express power cable length	70 cm	70 cm
CPU power connector (4+4 pin)	Yes	Yes
CPU power cable length	60 cm	60 cm
PCI Express connector	Yes	Yes
Cabling type	Fully-Modular	Fully-Modular
Performance2 differ
Purpose	PC	PC
Power supply unit (PSU) form factor	ATX	ATX
80 PLUS certificationDiffers	80 PLUS Gold	80 PLUS Bronze
ATX versionDiffers	3.0	2.52
Bearing technology	FDB	FDB
Designidentical
Product colour	Black	Black
Cooling type	Active	Active
Fan diameter	14 cm	14 cm
Number of fans	1 fan(s)	1 fan(s)
Illumination	Yes	Yes
On/off switch	Yes	Yes
Certificates1 differ
Compliance certificatesDiffers	EAC, TÜV mark, UKCA, Federal Communications Commission (FCC), RoHS, CB, CE	CB, CE, EAC, Federal Communications Commission (FCC), RoHS, TÜV mark, UKCA

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
