Product comparison · 2 power supply units

Aerocool KCAS PLUS GOLD 850W vs Aerocool LUX RGB 1000M

27specifications compared
9differ
18identical
7known for one product only

Key differences

Total power
- KCAS PLUS GOLD 850W:850 W
- LUX RGB 1000M:1000 W
AC input voltage
- KCAS PLUS GOLD 850W:100 - 240 V
- LUX RGB 1000M:220 - 240 V
Input current
- KCAS PLUS GOLD 850W:11 - 5.5 A
- LUX RGB 1000M:6.5 A
Combined power (+12V)
- KCAS PLUS GOLD 850W:840 W
- LUX RGB 1000M:984 W
Max output current (+12V)
- KCAS PLUS GOLD 850W:70 A
- LUX RGB 1000M:82 A
Efficiency
- KCAS PLUS GOLD 850W:92%
- LUX RGB 1000M:90%
PCI Express power connectors (6+2 pin)
- KCAS PLUS GOLD 850W:3
- LUX RGB 1000M:4
Cabling type
- KCAS PLUS GOLD 850W:Non-Modular
- LUX RGB 1000M:Semi-Modular

Side by side

Differences highlightedShow differences only

Comparison of KCAS PLUS GOLD 850W, LUX RGB 1000M
34 specifications	A Aerocool KCAS PLUS GOLD 850W View product	B Aerocool LUX RGB 1000M View product
Power6 differ
Total powerDiffers	850 W	1000 W
AC input voltageDiffers	100 - 240 V	220 - 240 V
AC input frequency	47 - 63 Hz	47 - 63 Hz
Input currentDiffers	11 - 5.5 A	6.5 A
Combined power (+3.3V)	130 W	130 W
Combined power (+12V)Differs	840 W	984 W
Combined power (+5V)	130 W	130 W
Combined power (-12V)	3.6 W	3.6 W
Combined power (+5Vsb)	12.5 W	12.5 W
Max output current (+3.3V)	20 A	20 A
Max output current (+12V)Differs	70 A	82 A
Max output current (+5V)	20 A	20 A
Max output current (-12V)	0.3 A	0.3 A
Max output current (+5Vsb)	2.5 A	2.5 A
EfficiencyDiffers	92%	90%
Power protection featuresKnown for one	Unknown — not stated by the source	Over power, Over voltage, Short circuit, Under voltage
Ports & interfaces2 differ
Motherboard power connector	20+4 pin ATX	20+4 pin ATX
Number of PATA power connectors	4	4
Number of SATA power connectors	8	8
PCI Express power connectors (6+2 pin)Differs	3	4
Cabling typeDiffers	Non-Modular	Semi-Modular
CPU power connector (4+4 pin)Known for one	Yes	Unknown — not stated by the source
Performance1 differ
Purpose	PC	PC
80 PLUS certification	80 PLUS Gold	80 PLUS Gold
ATX versionDiffers	2.52	2.4
Designidentical
Product colour	Black	Black
Fan diameter	12 cm	12 cm
Number of fans	1 fan(s)	1 fan(s)
Illumination	Yes	Yes
Packaging dataidentical
Package widthKnown for one	Unknown — not stated by the source	195 mm
Package depthKnown for one	Unknown — not stated by the source	230 mm
Package heightKnown for one	Unknown — not stated by the source	95 mm
Package typeKnown for one	Unknown — not stated by the source	Box
Certificatesidentical
CertificationKnown for one	ROHS	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
