Product comparison · 2 power adapters & inverters

LevelOne Industrial Power Supply, 48VDC vs LevelOne Industrial Power Supply, 55VDC

Key differences

Input voltage
- Industrial Power Supply, 48VDC:88-264 V
- Industrial Power Supply, 55VDC:12-36 V
Output power
- Industrial Power Supply, 48VDC:39.8 W
- Industrial Power Supply, 55VDC:85 W
Output voltage
- Industrial Power Supply, 48VDC:48 V
- Industrial Power Supply, 55VDC:55 V
Output current
- Industrial Power Supply, 48VDC:0.83 A
- Industrial Power Supply, 55VDC:1.55 A
Mean time between failures (MTBF)
- Industrial Power Supply, 48VDC:300760 h
- Industrial Power Supply, 55VDC:998640 h
Product colour
- Industrial Power Supply, 48VDC:Blue, White
- Industrial Power Supply, 55VDC:Green, Grey
Operating relative humidity (H-H)
- Industrial Power Supply, 48VDC:20 - 90%
- Industrial Power Supply, 55VDC:0 - 95%
Width
- Industrial Power Supply, 48VDC:90 mm
- Industrial Power Supply, 55VDC:135 mm

Differences highlightedShow differences only

Comparison of POW-4810, POW-5510
21 specifications	A LevelOne Industrial Power Supply, 48VDC Model POW-4810 View product	B LevelOne Industrial Power Supply, 55VDC Model POW-5510 View product
Features4 differ
PurposeKnown for one	Network switch	Unknown — not stated by the source
Input voltageDiffers	88-264 V	12-36 V
Output powerDiffers	39.8 W	85 W
Output voltageDiffers	48 V	55 V
Output currentDiffers	0.83 A	1.55 A
Power protection features	Over voltage, Overload, Short circuit	Over voltage, Overload, Short circuit
Adjustable output voltageKnown for one	Unknown — not stated by the source	No
Performance1 differ
Mean time between failures (MTBF)Differs	300760 h	998640 h
Design1 differ
Product colourDiffers	Blue, White	Green, Grey
Operational conditions1 differ
Operating temperature (T-T)	-10 - 60 °C	-10 - 60 °C
Operating relative humidity (H-H)Differs	20 - 90%	0 - 95%
Certificatesidentical
Certification	IEC60068, EN60950-1, UL60950-1, EN55011, EN55022 (CISPR22) Class B, EN61000-3-2, EN61000-3-3, EN61000-4-2/3/4/5/6/8/11, EN61000-6-2, EN61204, EN55024	IEC60068, EN60950-1, UL60950-1, EN55011, EN55022 (CISPR22) Class B, EN61000-3-2, EN61000-3-3, EN61000-4-2/3/4/5/6/8/11, EN61000-6-2, EN61204, EN55024
Weight & dimensions4 differ
WidthDiffers	90 mm	135 mm
DepthDiffers	40 mm	50 mm
HeightDiffers	100 mm	165 mm
WeightDiffers	300 g	1.2 kg
Packaging data3 differ
Package widthDiffers	90 mm	238 mm
Package depth	100 mm	100 mm
Package heightDiffers	40 mm	296 mm
Package weightDiffers	350 g	1.1 kg
Logistics dataidentical
Products per pallet	1 pc(s)	1 pc(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
