Product comparison · 2 poe adapters

StarTech.com 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af vs StarTech.com Industrial 2 Port Gigabit PoE+ Power over Ethernet Injector

13specifications compared
11differ
2identical
21known for one product only

Key differences

LED indicators
- 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af:Power
- Industrial 2 Port Gigabit PoE+ Power over Ethernet Injector:Yes
Ethernet LAN (RJ-45) ports
- 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af:2
- Industrial 2 Port Gigabit PoE+ Power over Ethernet Injector:4
Power over Ethernet (PoE) voltage
- 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af:48 V
- Industrial 2 Port Gigabit PoE+ Power over Ethernet Injector:50 V
Certification
- 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af:RoHS, CE, FCC
- Industrial 2 Port Gigabit PoE+ Power over Ethernet Injector:CE, FCC, RoHS
Operating temperature (T-T)
- 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af:0 - 45 °C
- Industrial 2 Port Gigabit PoE+ Power over Ethernet Injector:-40 - 70 °C
Storage temperature (T-T)
- 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af:-40 - 85 °C
- Industrial 2 Port Gigabit PoE+ Power over Ethernet Injector:-40 - 80 °C
Weight
- 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af:52 g
- Industrial 2 Port Gigabit PoE+ Power over Ethernet Injector:212 g
Dimensions (WxDxH)
- 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af:63 x 70 x 25 mm
- Industrial 2 Port Gigabit PoE+ Power over Ethernet Injector:70 x 95 x 26 mm

Side by side

Differences highlightedShow differences only

Comparison of POEINJ1G, POEINJ2GI
34 specifications	A StarTech.com 1-Port Gigabit Midspan - PoE+ Injector - 802.3at and 802.3af Model POEINJ1G View product	B StarTech.com Industrial 2 Port Gigabit PoE+ Power over Ethernet Injector Model POEINJ2GI View product
Network1 differ
Ethernet interface typeDiffers	Fast Ethernet, Gigabit Ethernet	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Cabling technologyKnown for one	10Base-T, 100Base-TX, 1000Base-T	Unknown — not stated by the source
Power over Ethernet (PoE)	Yes	Yes
Cable types supportedKnown for one	Cat5	Unknown — not stated by the source
Duplex systemKnown for one	Full	Unknown — not stated by the source
Networking standardsKnown for one	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u	Unknown — not stated by the source
Features1 differ
Product colourKnown for one	Black	Unknown — not stated by the source
Plug and PlayKnown for one	Yes	Unknown — not stated by the source
Maximum operating distanceKnown for one	100 m	Unknown — not stated by the source
LED indicatorsDiffers	Power	Yes
Ports & interfaces1 differ
Ethernet LAN (RJ-45) portsDiffers	2	4
DC-in jackKnown for one	Yes	Unknown — not stated by the source
Power1 differ
Power over Ethernet (PoE) voltageDiffers	48 V	50 V
Output powerKnown for one	30 W	Unknown — not stated by the source
Input voltageKnown for one	100 - 240 V	Unknown — not stated by the source
Input currentKnown for one	0.75 A	Unknown — not stated by the source
Output currentKnown for one	0.64 A	Unknown — not stated by the source
Power requirementsKnown for one	Unknown — not stated by the source	50 - 57 DC
Power consumption (typical)Known for one	Unknown — not stated by the source	30 W
Certificates1 differ
CertificationDiffers	RoHS, CE, FCC	CE, FCC, RoHS
Compliance industry standardsKnown for one	Unknown — not stated by the source	IEEE 802.3at PoE, IEEE 802.3af PoE
Operational conditions2 differ
Operating temperature (T-T)Differs	0 - 45 °C	-40 - 70 °C
Operating relative humidity (H-H)Known for one	10 - 90%	Unknown — not stated by the source
Storage temperature (T-T)Differs	-40 - 85 °C	-40 - 80 °C
Storage relative humidity (H-H)Known for one	Unknown — not stated by the source	5 - 95%
Weight & dimensions2 differ
WeightDiffers	52 g	212 g
Dimensions (WxDxH)Differs	63 x 70 x 25 mm	70 x 95 x 26 mm
Packaging contentidentical
Power cord includedKnown for one	Yes	Unknown — not stated by the source
ManualKnown for one	Yes	Unknown — not stated by the source
Packaging data2 differ
Package widthDiffers	230 mm	155 mm
Package heightDiffers	76 mm	48 mm
Package weightKnown for one	995 g	Unknown — not stated by the source
Logistics dataidentical
Harmonized System (HS) codeKnown for one	85044095	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
