Product comparison · 2 pcs/workstations

Zoostorm 7260-2048 PC Intel Pentium G G3260 vs Zoostorm 7260-5102 PC Intel® Core™ i3 i3-4170

136specifications compared
36differ
100identical
16known for one product only

Key differences

Processor family
- 7260-2048 PC Intel Pentium G G3260:Intel Pentium G
- 7260-5102 PC Intel® Core™ i3 i3-4170:Intel® Core™ i3
Processor model
- 7260-2048 PC Intel Pentium G G3260:G3260
- 7260-5102 PC Intel® Core™ i3 i3-4170:i3-4170
Processor threads
- 7260-2048 PC Intel Pentium G G3260:2
- 7260-5102 PC Intel® Core™ i3 i3-4170:4
Processor frequency
- 7260-2048 PC Intel Pentium G G3260:3.3 GHz
- 7260-5102 PC Intel® Core™ i3 i3-4170:3.7 GHz
Processor cache type
- 7260-2048 PC Intel Pentium G G3260:Smart Cache
- 7260-5102 PC Intel® Core™ i3 i3-4170:L3
Thermal Design Power (TDP)
- 7260-2048 PC Intel Pentium G G3260:53 W
- 7260-5102 PC Intel® Core™ i3 i3-4170:54 W
PCI Express configurations
- 7260-2048 PC Intel Pentium G G3260:1x8, 1x16, 2x4, 2x8
- 7260-5102 PC Intel® Core™ i3 i3-4170:1x16, 2x8, 1x8+2x4
Memory clock speeds supported by processor
- 7260-2048 PC Intel Pentium G G3260:1333 MHz
- 7260-5102 PC Intel® Core™ i3 i3-4170:1333,1600 MHz

Side by side

Differences highlightedShow differences only

Comparison of 7260-2048, 7260-5102
152 specifications	A Zoostorm 7260-2048 PC Intel Pentium G G3260 Model 7260-2048 View product	B Zoostorm 7260-5102 PC Intel® Core™ i3 i3-4170 Model 7260-5102 View product
Processor9 differ
Processor manufacturer	Intel	Intel
Processor familyDiffers	Intel Pentium G	Intel® Core™ i3
Processor modelDiffers	G3260	i3-4170
Processor cores	2	2
Processor threadsDiffers	2	4
Processor frequencyDiffers	3.3 GHz	3.7 GHz
Processor cache	3 MB	3 MB
Processor cache typeDiffers	Smart Cache	L3
Bus type	DMI2	DMI2
FSB Parity	No	No
System bus rate	5 GT/s	5 GT/s
Processor lithography	22 nm	22 nm
Processor operating modes	32-bit, 64-bit	32-bit, 64-bit
Processor seriesDiffers	Intel Pentium G3000 series for Desktop	Intel Core i3-4100 Desktop series
Processor codename	Haswell	Haswell
Thermal Design Power (TDP)Differs	53 W	54 W
Tcase	72 °C	72 °C
Maximum number of PCI Express lanes	16	16
PCI Express configurationsDiffers	1x8, 1x16, 2x4, 2x8	1x16, 2x8, 1x8+2x4
PCI Express slots version	3.0	3.0
Number of processors installed	1	1
Processor socket	LGA 1150 (Socket H3)	LGA 1150 (Socket H3)
Stepping	C0	C0
Maximum internal memory supported by processor	32 GB	32 GB
Memory types supported by processor	DDR3-SDRAM, DDR3L-SDRAM	DDR3-SDRAM, DDR3L-SDRAM
Memory clock speeds supported by processorDiffers	1333 MHz	1333,1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s	25.6 GB/s
ECC supported by processor	Yes	Yes
Memory voltage supported by processor	1.5 V	1.5 V
Processor generationKnown for one	Unknown — not stated by the source	4th gen Intel® Core™ i3
Number of QPI linksKnown for one	Unknown — not stated by the source	0
Memory2 differ
Internal memoryDiffers	6 GB	8 GB
Maximum internal memoryDiffers	16 GB	32 GB
Internal memory type	DDR3-SDRAM	DDR3-SDRAM
Memory layout (slots x size)Known for one	1 x 2 + 1 x 4 GB	Unknown — not stated by the source
Memory slots	2x DIMM	2x DIMM
Memory clock speed	1600 MHz	1600 MHz
Memory channels	Dual-channel	Dual-channel
Storage2 differ
Total storage capacityDiffers	500 GB	1 TB
Optical drive type	DVD±RW	DVD±RW
Storage media	HDD	HDD
Number of storage drives installed	1	1
Number of HDDs installed	1	1
HDD capacityDiffers	500 GB	1 TB
HDD interface	SATA	SATA
HDD speed	5400 RPM	5400 RPM
Graphics4 differ
On-board graphics card	Yes	Yes
Discrete graphics card modelDiffers	Not available	NVIDIA® GeForce® GTX 750
On-board graphics card family	Intel® HD Graphics	Intel® HD Graphics
On-board graphics card modelDiffers	Intel® HD Graphics	Intel® HD Graphics 4400
Maximum on-board graphics card memoryDiffers	16 GB	1.74 GB
Number of displays supported (on-board graphics)	3	3
On-board graphics card base frequency	350 MHz	350 MHz
On-board graphics card dynamic frequency (max)Differs	1100 MHz	1150 MHz
On-board graphics card DirectX version	11.1	11.1
Discrete graphics card memoryKnown for one	Unknown — not stated by the source	1 GB
On-board graphics card IDKnown for one	Unknown — not stated by the source	41
On-board graphics card OpenGL versionKnown for one	Unknown — not stated by the source	4.3
Performance1 differ
Product type	PC	PC
Motherboard chipsetDiffers	Intel® H81	Intel® B85
Motherboard form factorKnown for one	micro ATX	Unknown — not stated by the source
Audio output channels	7.1 channels	7.1 channels
Optical driveidentical
Optical drives quantity	1	1
Networkidentical
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	10,1000,100 Mbit/s	10,1000,100 Mbit/s
Cabling technologyKnown for one	10/100/1000Base-T(X)	Unknown — not stated by the source
Wi-FiKnown for one	No	Unknown — not stated by the source
Ports & interfaces3 differ
USB 2.0 ports quantityDiffers	4	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantityDiffers	2	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantityKnown for one	0	Unknown — not stated by the source
HDMI ports quantityDiffers	0	1
Ethernet LAN (RJ-45) ports	1	1
Headphone outputs	1	1
Line-out	Yes	Yes
Line-in	Yes	Yes
Microphone in	Yes	Yes
VGA (D-Sub) ports quantity	1	1
DVI port	Yes	Yes
PS/2 ports quantity	1	1
Expansion slots1 differ
PCI Express x1 slotsDiffers	1	2
PCI Express x16 slots	1	1
PCI slotsKnown for one	Unknown — not stated by the source	1
Power1 differ
Power supplyDiffers	250 W	350 W
Power supply input voltage	100 - 240 V	100 - 240 V
Power supply input frequency	50 - 60 Hz	50 - 60 Hz
Designidentical
Chassis type	Mini Tower	Mini Tower
Placement supported	Vertical	Vertical
Product colour	Black	Black
Software1 differ
Operating system installedDiffers	Windows 10 Pro	Windows 10 Home
Recovery operating systemKnown for one	Windows 7 Professional	Unknown — not stated by the source
Displayidentical
Display included	No	No
Processor special features9 differ
CPU configuration (max)	1	1
Embedded options available	No	No
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Graphics & IMC lithography	22 nm	22 nm
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	No	No
Intel Demand Based Switching	No	No
Intel Dual Display Capable Technology	No	No
Intel Enhanced Halt State	Yes	Yes
Intel FDI Technology	No	No
Intel Fast Memory Access	No	No
Intel Flex Memory Access	No	No
Intel Rapid Storage Technology	No	No
Intel Secure Key Technology version	1.00	1.00
Intel Stable Image Platform Program (SIPP)	No	No
Intel Stable Image Platform Program (SIPP) version	0.00	0.00
Intel TSX-NI	No	No
Intel TSX-NI version	0.00	0.00
Intel Trusted Execution Technology	No	No
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No	No
Intel® AES New Instructions (Intel® AES-NI)Differs	No	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Differs	No	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No	No
Intel® InTru™ 3D TechnologyDiffers	No	Yes
Intel® Insider™	No	No
Intel® Secure Key	Yes	Yes
Intel® Small Business Advantage (Intel® SBA)Differs	No	Yes
Intel® Virtualization Technology (Intel® VT)	VT-x	VT-x
Intel® Wireless Display (Intel® WiDi)Differs	No	Yes
Processor ARK IDDiffers	87356	77490
Processor codeDiffers	SR1K8	SR1PL
Processor package size	37.5 x 37.5 mm	37.5 x 37.5 mm
Scalability	1S	1S
Supported instruction setsDiffers	SSE4.1, SSE4.2	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes	Yes
Thermal solution specification	PCG 2013C	PCG 2013C
Intel® Smart Response Technology	No	No
Intel® Rapid Start Technology	No	No
Intel® Turbo Boost Technology	No	No
Intel Smart Connect Technology	No	No
Intel® Hyper Threading Technology (Intel® HT Technology)Differs	No	Yes
Intel® Quick Sync Video Technology	Yes	Yes
Intel® My WiFi Technology (Intel® MWT)	No	No
Intel® Identity Protection Technology (Intel® IPT)	No	No
Intel® Anti-Theft Technology (Intel® AT)	No	No
Conflict-Free processor	Yes	Yes
Intel Small Business Advantage (SBA) versionKnown for one	Unknown — not stated by the source	1.00
Intel® Smart CacheKnown for one	Unknown — not stated by the source	Yes
Audioidentical
Audio system	HD	HD
Weight & dimensions3 differ
WidthDiffers	180 mm	195 mm
DepthDiffers	375 mm	450 mm
HeightDiffers	360 mm	370 mm
Packaging contentidentical
Mouse includedKnown for one	No	Unknown — not stated by the source
Keyboard includedKnown for one	No	Unknown — not stated by the source
Cables included	AC	AC
AC adapter included	Yes	Yes
Manual	Yes	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
