| Processor11 differ |
|---|
| Processor manufacturer | Intel | Intel |
|---|
| Processor familyDiffers | Intel® Celeron® | Intel Pentium Mobile |
|---|
| Processor modelDiffers | N3060 | N270 |
|---|
| Processor coresDiffers | 2 | 1 |
|---|
| Processor threads | 2 | 2 |
|---|
| Processor boost frequencyKnown for one | 2.48 GHz | —Unknown — not stated by the source |
|---|
| Processor frequency | 1.6 GHz | 1.6 GHz |
|---|
| Processor cacheDiffers | 2 MB | 0.512 MB |
|---|
| Processor cache type | L2 | L2 |
|---|
| System bus rateKnown for one | 5 GT/s | —Unknown — not stated by the source |
|---|
| Processor lithographyDiffers | 14 nm | 45 nm |
|---|
| Processor operating modesDiffers | 64-bit | 32-bit |
|---|
| Processor seriesDiffers | Intel Celeron N3000 series | Intel Atom N200 Series |
|---|
| Processor codenameDiffers | Braswell | Diamondville |
|---|
| Thermal Design Power (TDP)Differs | 6 W | 2.5 W |
|---|
| Scenario Design Power (SDP)Known for one | 4 W | —Unknown — not stated by the source |
|---|
| Tjunction | 90 °C | 90 °C |
|---|
| Maximum number of PCI Express lanesKnown for one | 4 | —Unknown — not stated by the source |
|---|
| PCI Express configurationsKnown for one | 1x2+2x1, 1x4, 2x2, 4x1 | —Unknown — not stated by the source |
|---|
| PCI Express slots versionKnown for one | 2.0 | —Unknown — not stated by the source |
|---|
| Number of processors installed | 1 | 1 |
|---|
| Processor socketDiffers | BGA 1170 | Socket F (1207) |
|---|
| SteppingDiffers | D1 | C0 |
|---|
| Maximum internal memory supported by processorKnown for one | 8 GB | —Unknown — not stated by the source |
|---|
| Memory types supported by processorKnown for one | DDR3L-SDRAM | —Unknown — not stated by the source |
|---|
| Memory clock speeds supported by processorKnown for one | 1600 MHz | —Unknown — not stated by the source |
|---|
| ECC supported by processor | No | No |
|---|
| Processor front side busKnown for one | —Unknown — not stated by the source | 533 MHz |
|---|
| Bus typeKnown for one | —Unknown — not stated by the source | FSB |
|---|
| FSB ParityKnown for one | —Unknown — not stated by the source | No |
|---|
| Number of Processing Die TransistorsKnown for one | —Unknown — not stated by the source | 47 M |
|---|
| Processing Die sizeKnown for one | —Unknown — not stated by the source | 26 mm² |
|---|
| CPU multiplier (bus/core ratio)Known for one | —Unknown — not stated by the source | 12 |
|---|
| Maximum number of SMP processorsKnown for one | —Unknown — not stated by the source | 1 |
|---|
| Graphicsidentical |
|---|
| Discrete graphics cardKnown for one | No | —Unknown — not stated by the source |
|---|
| On-board graphics card | Yes | Yes |
|---|
| Discrete graphics card modelKnown for one | Not available | —Unknown — not stated by the source |
|---|
| On-board graphics card modelKnown for one | Intel® HD Graphics 400 | —Unknown — not stated by the source |
|---|
| Maximum on-board graphics card memoryKnown for one | 8 GB | —Unknown — not stated by the source |
|---|
| Number of displays supported (on-board graphics)Known for one | 3 | —Unknown — not stated by the source |
|---|
| On-board graphics card base frequencyKnown for one | 320 MHz | —Unknown — not stated by the source |
|---|
| On-board graphics card burst frequencyKnown for one | 600 MHz | —Unknown — not stated by the source |
|---|
| On-board graphics card DirectX versionKnown for one | 12.0 | —Unknown — not stated by the source |
|---|
| Number of execution unitsKnown for one | 12 | —Unknown — not stated by the source |
|---|
| Graphics card familyKnown for one | —Unknown — not stated by the source | Intel |
|---|
| Ports & interfaces3 differ |
|---|
| USB 2.0 ports quantityDiffers | 2 | 4 |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 | 0 |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantityKnown for one | 0 | —Unknown — not stated by the source |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantityKnown for one | 0 | —Unknown — not stated by the source |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantityKnown for one | 0 | —Unknown — not stated by the source |
|---|
| Thunderbolt 3 ports quantityKnown for one | 0 | —Unknown — not stated by the source |
|---|
| HDMI ports quantityDiffers | 1 | 0 |
|---|
| HDMI versionKnown for one | 1.4 | —Unknown — not stated by the source |
|---|
| Ethernet LAN (RJ-45) ports | 1 | 1 |
|---|
| Headphone outputs | 1 | 1 |
|---|
| Microphone in | Yes | Yes |
|---|
| VGA (D-Sub) ports quantity | 1 | 1 |
|---|
| DVI portDiffers | No | Yes |
|---|
| PS/2 ports quantityKnown for one | —Unknown — not stated by the source | 0 |
|---|
| Firewire (IEEE 1394) portsKnown for one | —Unknown — not stated by the source | 0 |
|---|
| eSATA ports quantityKnown for one | —Unknown — not stated by the source | 1 |
|---|
| DC-in jackKnown for one | —Unknown — not stated by the source | Yes |
|---|
| Serial ports quantityKnown for one | —Unknown — not stated by the source | 0 |
|---|
| Parallel ports quantityKnown for one | —Unknown — not stated by the source | 0 |
|---|
| Processor special features16 differ |
|---|
| CPU configuration (max)Known for one | 1 | —Unknown — not stated by the source |
|---|
| Embedded options available | Yes | Yes |
|---|
| Enhanced Intel SpeedStep Technology | Yes | Yes |
|---|
| Execute Disable Bit | Yes | Yes |
|---|
| Idle StatesDiffers | Yes | No |
|---|
| Intel 64Differs | Yes | No |
|---|
| Intel Clear Video TechnologyDiffers | Yes | No |
|---|
| Intel Enhanced Halt StateDiffers | Yes | No |
|---|
| Intel Identity Protection Technology versionKnown for one | 1.00 | —Unknown — not stated by the source |
|---|
| Intel Rapid Storage Technology | No | No |
|---|
| Intel Secure BootKnown for one | Yes | —Unknown — not stated by the source |
|---|
| Intel Secure Boot Technology versionKnown for one | 1.00 | —Unknown — not stated by the source |
|---|
| Intel Secure Key Technology versionKnown for one | 1.00 | —Unknown — not stated by the source |
|---|
| Intel Small Business Advantage (SBA) versionKnown for one | 0.00 | —Unknown — not stated by the source |
|---|
| Intel Smart Connect Technology versionKnown for one | 0.00 | —Unknown — not stated by the source |
|---|
| Intel Smart Response Technology versionKnown for one | 0.00 | —Unknown — not stated by the source |
|---|
| Intel Stable Image Platform Program (SIPP)Known for one | No | —Unknown — not stated by the source |
|---|
| Intel Stable Image Platform Program (SIPP) versionKnown for one | 0.00 | —Unknown — not stated by the source |
|---|
| Intel Trusted Execution Technology | No | No |
|---|
| Intel VT-x with Extended Page Tables (EPT)Differs | Yes | No |
|---|
| Intel Virtualization Technology (VT-x)Differs | Yes | No |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | No | No |
|---|
| Intel® AES New Instructions (Intel® AES-NI)Differs | Yes | No |
|---|
| Intel® Clear Video HD Technology (Intel® CVT HD)Differs | Yes | No |
|---|
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Differs | Yes | No |
|---|
| Intel® High Definition Audio (Intel® HD Audio)Known for one | Yes | —Unknown — not stated by the source |
|---|
| Intel® InTru™ 3D Technology | No | No |
|---|
| Intel® Insider™ | No | No |
|---|
| Intel® OS GuardKnown for one | No | —Unknown — not stated by the source |
|---|
| Intel® Secure KeyKnown for one | Yes | —Unknown — not stated by the source |
|---|
| Intel® Small Business Advantage (Intel® SBA)Known for one | No | —Unknown — not stated by the source |
|---|
| Intel® Wireless Display (Intel® WiDi)Differs | Yes | No |
|---|
| Processor ARK IDDiffers | 91832 | 36331 |
|---|
| Processor codeDiffers | SR2KN | SLB73 |
|---|
| Processor package sizeDiffers | 25 x 27 mm | 22 x 22 mm |
|---|
| Thermal Monitoring Technologies | Yes | Yes |
|---|
| UARTKnown for one | Yes | —Unknown — not stated by the source |
|---|
| Intel® Smart Response TechnologyKnown for one | No | —Unknown — not stated by the source |
|---|
| Intel® Turbo Boost Technology | No | No |
|---|
| Intel Smart Connect TechnologyKnown for one | No | —Unknown — not stated by the source |
|---|
| Intel® Hyper Threading Technology (Intel® HT Technology)Differs | No | Yes |
|---|
| Intel® Quick Sync Video TechnologyDiffers | Yes | No |
|---|
| Intel® Identity Protection Technology (Intel® IPT)Known for one | Yes | —Unknown — not stated by the source |
|---|
| Intel® Anti-Theft Technology (Intel® AT) | No | No |
|---|
| Conflict-Free processorDiffers | Yes | No |
|---|
| Integrated 4G WiMAXKnown for one | No | —Unknown — not stated by the source |
|---|
| Intel Demand Based SwitchingKnown for one | —Unknown — not stated by the source | No |
|---|
| Intel Dual Display Capable TechnologyKnown for one | —Unknown — not stated by the source | No |
|---|
| Intel FDI TechnologyKnown for one | —Unknown — not stated by the source | No |
|---|
| Intel Fast Memory AccessKnown for one | —Unknown — not stated by the source | No |
|---|
| Intel Flex Memory AccessKnown for one | —Unknown — not stated by the source | No |
|---|
| Supported instruction setsKnown for one | —Unknown — not stated by the source | SSE2, SSE3 |
|---|
| Intel® My WiFi Technology (Intel® MWT)Known for one | —Unknown — not stated by the source | No |
|---|
