Product comparison · 2 pcs/workstations

Samsung DM500T9A Intel® Core™ i5 i5-9400 vs Samsung DM500T9Z Intel® Pentium® Gold G5420

99specifications compared
24differ
75identical
15known for one product only

Key differences

Processor family
- DM500T9A Intel® Core™ i5 i5-9400:Intel® Core™ i5
- DM500T9Z Intel® Pentium® Gold G5420:Intel® Pentium® Gold
Processor model
- DM500T9A Intel® Core™ i5 i5-9400:i5-9400
- DM500T9Z Intel® Pentium® Gold G5420:G5420
Processor cores
- DM500T9A Intel® Core™ i5 i5-9400:6
- DM500T9Z Intel® Pentium® Gold G5420:2
Processor threads
- DM500T9A Intel® Core™ i5 i5-9400:6
- DM500T9Z Intel® Pentium® Gold G5420:4
Processor frequency
- DM500T9A Intel® Core™ i5 i5-9400:2.9 GHz
- DM500T9Z Intel® Pentium® Gold G5420:3.8 GHz
Processor cache
- DM500T9A Intel® Core™ i5 i5-9400:9 MB
- DM500T9Z Intel® Pentium® Gold G5420:4 MB
Thermal Design Power (TDP)
- DM500T9A Intel® Core™ i5 i5-9400:65 W
- DM500T9Z Intel® Pentium® Gold G5420:54 W
PCI Express configurations
- DM500T9A Intel® Core™ i5 i5-9400:1x8+2x4, 1x16, 2x8
- DM500T9Z Intel® Pentium® Gold G5420:1x16, 2x8, 1x8+2x4

Side by side

Differences highlightedShow differences only

Comparison of DM500T9A, DM500T9Z
114 specifications	A Samsung DM500T9A Intel® Core™ i5 i5-9400 Model DM500T9A View product	B Samsung DM500T9Z Intel® Pentium® Gold G5420 Model DM500T9Z View product
Processor11 differ
Processor manufacturer	Intel	Intel
Processor familyDiffers	Intel® Core™ i5	Intel® Pentium® Gold
Processor generationKnown for one	9th gen Intel® Core™ i5	Unknown — not stated by the source
Processor modelDiffers	i5-9400	G5420
Processor coresDiffers	6	2
Processor threadsDiffers	6	4
Processor boost frequencyKnown for one	4.1 GHz	Unknown — not stated by the source
Processor frequencyDiffers	2.9 GHz	3.8 GHz
Processor cacheDiffers	9 MB	4 MB
Processor cache type	Smart Cache	Smart Cache
Bus typeKnown for one	DMI3	Unknown — not stated by the source
System bus rate	8 GT/s	8 GT/s
Processor lithography	14 nm	14 nm
Processor operating modes	64-bit	64-bit
Processor codename	Coffee Lake	Coffee Lake
Thermal Design Power (TDP)Differs	65 W	54 W
Tjunction	100 °C	100 °C
Maximum number of PCI Express lanes	16	16
PCI Express configurationsDiffers	1x8+2x4, 1x16, 2x8	1x16, 2x8, 1x8+2x4
PCI Express slots version	3.0	3.0
Number of processors installed	1	1
Processor socket	LGA 1151 (Socket H4)	LGA 1151 (Socket H4)
Maximum internal memory supported by processorDiffers	128 GB	64 GB
Memory types supported by processor	DDR4-SDRAM	DDR4-SDRAM
Memory clock speeds supported by processorDiffers	2666 MHz	2400 MHz
Memory bandwidth supported by processor (max)Differs	41.6 GB/s	37.5 GB/s
Memory1 differ
Internal memoryDiffers	8 GB	4 GB
Internal memory type	DDR4-SDRAM	DDR4-SDRAM
Memory slots	2x DIMM	2x DIMM
Memory layout (slots x size)Known for one	Unknown — not stated by the source	1 x 4 GB
Storage2 differ
Total storage capacityDiffers	1.25 TB	1 TB
Optical drive type	DVD Super Multi	DVD Super Multi
Storage mediaDiffers	HDD+SSD	HDD
Total HDDs capacity	1 TB	1 TB
Number of HDDs installed	1	1
Total SSDs capacityKnown for one	256 GB	Unknown — not stated by the source
Number of SSDs installedKnown for one	1	Unknown — not stated by the source
Card reader integrated	Yes	Yes
Graphics4 differ
Discrete graphics cardDiffers	Yes	No
On-board graphics card	Yes	Yes
Discrete graphics card modelDiffers	NVIDIA® GeForce® GTX 1650	Not available
Discrete graphics card memoryKnown for one	4 GB	Unknown — not stated by the source
Discrete graphics memory typeKnown for one	GDDR5	Unknown — not stated by the source
On-board graphics card modelDiffers	Intel® UHD Graphics 630	Intel® UHD Graphics 610
Maximum on-board graphics card memory	64 GB	64 GB
Number of displays supported (on-board graphics)	3	3
On-board graphics card base frequency	350 MHz	350 MHz
On-board graphics card dynamic frequency (max)	1050 MHz	1050 MHz
On-board graphics card DirectX version	12.0	12.0
On-board graphics card IDDiffers	0X3E98/x92	0x3E90/x93
On-board graphics card OpenGL version	4.5	4.5
Performanceidentical
Product type	PC	PC
Networkidentical
Ethernet LAN	Yes	Yes
Wi-Fi	Yes	Yes
Wi-Fi standards	Wi-Fi 5 (802.11ac)	Wi-Fi 5 (802.11ac)
Bluetooth	Yes	Yes
Bluetooth version	5.0	5.0
Ports & interfacesidentical
USB 2.0 ports quantity	4	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0	0
Thunderbolt 3 ports quantity	0	0
HDMI ports quantity	1	1
Ethernet LAN (RJ-45) ports	1	1
Headphone outputs	1	1
Microphone in	Yes	Yes
VGA (D-Sub) ports quantity	1	1
DVI port	No	No
Power1 differ
Power supplyDiffers	450 W	350 W
Designidentical
Chassis type	Tower	Tower
Product colour	Black	Black
Software1 differ
Operating system installedDiffers	Windows 10 Home	Linux
Operating system architectureKnown for one	64-bit	Unknown — not stated by the source
Displayidentical
Display included	No	No
Processor special features4 differ
CPU configuration (max)	1	1
Embedded options available	No	No
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	Yes	Yes
Intel Enhanced Halt StateKnown for one	Yes	Unknown — not stated by the source
Intel Identity Protection Technology versionKnown for one	1.00	Unknown — not stated by the source
Intel Secure Key Technology versionKnown for one	1.00	Unknown — not stated by the source
Intel Software Guard Extensions (Intel SGX)	Yes	Yes
Intel Stable Image Platform Program (SIPP)	No	No
Intel Stable Image Platform Program (SIPP) versionKnown for one	0.00	Unknown — not stated by the source
Intel TSX-NI	No	No
Intel TSX-NI versionKnown for one	0.00	Unknown — not stated by the source
Intel Trusted Execution Technology	No	No
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)Known for one	Yes	Unknown — not stated by the source
Intel® InTru™ 3D Technology	Yes	Yes
Intel® OS Guard	Yes	Yes
Intel® Secure Key	Yes	Yes
Processor ARK IDDiffers	134898	135456
Processor package size	37.5 x 37.5 mm	37.5 x 37.5 mm
Scalability	1S	1S
Supported instruction setsDiffers	AVX 2.0, SSE4.1, SSE4.2	SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes	Yes
Thermal solution specification	PCG 2015C	PCG 2015C
Intel® Turbo Boost TechnologyDiffers	2.0	No
Intel® Hyper Threading Technology (Intel® HT Technology)Differs	No	Yes
Intel® Quick Sync Video Technology	Yes	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes	Yes
Weight & dimensionsidentical
Width	173 mm	173 mm
Depth	406 mm	406 mm
Height	356 mm	356 mm
Weight	8.82 kg	8.82 kg

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
