Product comparison · 2 pcs/workstations

Samsung DM500S7A-A34S PC Intel® Core™ i3 i3-7100 vs Samsung DM500T7A-A59 PC Intel® Core™ i5 i5-7400

111specifications compared
28differ
83identical
17known for one product only

Key differences

Processor family
- DM500S7A-A34S PC Intel® Core™ i3 i3-7100:Intel® Core™ i3
- DM500T7A-A59 PC Intel® Core™ i5 i5-7400:Intel® Core™ i5
Processor generation
- DM500S7A-A34S PC Intel® Core™ i3 i3-7100:7th gen Intel® Core™ i3
- DM500T7A-A59 PC Intel® Core™ i5 i5-7400:7th gen Intel® Core™ i5
Processor model
- DM500S7A-A34S PC Intel® Core™ i3 i3-7100:i3-7100
- DM500T7A-A59 PC Intel® Core™ i5 i5-7400:i5-7400
Processor cores
- DM500S7A-A34S PC Intel® Core™ i3 i3-7100:2
- DM500T7A-A59 PC Intel® Core™ i5 i5-7400:4
Processor frequency
- DM500S7A-A34S PC Intel® Core™ i3 i3-7100:3.9 GHz
- DM500T7A-A59 PC Intel® Core™ i5 i5-7400:3 GHz
Processor cache
- DM500S7A-A34S PC Intel® Core™ i3 i3-7100:3 MB
- DM500T7A-A59 PC Intel® Core™ i5 i5-7400:6 MB
Thermal Design Power (TDP)
- DM500S7A-A34S PC Intel® Core™ i3 i3-7100:51 W
- DM500T7A-A59 PC Intel® Core™ i5 i5-7400:65 W
Stepping
- DM500S7A-A34S PC Intel® Core™ i3 i3-7100:S0
- DM500T7A-A59 PC Intel® Core™ i5 i5-7400:B0

Side by side

Differences highlightedShow differences only

Comparison of DM500S7A-A34S, DM500T7A-A59
128 specifications	A Samsung DM500S7A-A34S PC Intel® Core™ i3 i3-7100 Model DM500S7A-A34S View product	B Samsung DM500T7A-A59 PC Intel® Core™ i5 i5-7400 Model DM500T7A-A59 View product
Processor8 differ
Processor manufacturer	Intel	Intel
Processor familyDiffers	Intel® Core™ i3	Intel® Core™ i5
Processor generationDiffers	7th gen Intel® Core™ i3	7th gen Intel® Core™ i5
Processor modelDiffers	i3-7100	i5-7400
Processor coresDiffers	2	4
Processor threads	4	4
Processor boost frequencyKnown for one	Unknown — not stated by the source	3.5 GHz
Processor frequencyDiffers	3.9 GHz	3 GHz
Processor cacheDiffers	3 MB	6 MB
Processor cache type	Smart Cache	Smart Cache
Bus type	DMI3	DMI3
System bus rate	8 GT/s	8 GT/s
Processor lithography	14 nm	14 nm
Processor operating modes	64-bit	64-bit
Processor seriesKnown for one	Unknown — not stated by the source	Intel Core i5-7400 Desktop Series
Processor codename	Kaby Lake	Kaby Lake
Thermal Design Power (TDP)Differs	51 W	65 W
Tjunction	100 °C	100 °C
Maximum number of PCI Express lanes	16	16
PCI Express configurations	1x16, 1x8+2x4, 2x8	1x16, 1x8+2x4, 2x8
PCI Express slots version	3.0	3.0
Number of QPI linksKnown for one	Unknown — not stated by the source	0
Number of processors installed	1	1
Processor socket	LGA 1151 (Socket H4)	LGA 1151 (Socket H4)
SteppingDiffers	S0	B0
Maximum internal memory supported by processor	64 GB	64 GB
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM	DDR3L-SDRAM, DDR4-SDRAM
Memory clock speeds supported by processor	1333,1600,2133,2400 MHz	1333,1600,2133,2400 MHz
ECC supported by processor	No	No
Memory voltage supported by processorKnown for one	Unknown — not stated by the source	1.35 V
Memory2 differ
Internal memoryDiffers	4 GB	8 GB
Internal memory type	DDR4-SDRAM	DDR4-SDRAM
Memory layout (slots x size)Differs	1 x 4 GB	2 x 4 GB
Memory slots	2x DIMM	2x DIMM
Memory channels	Dual-channel	Dual-channel
Storage4 differ
Total storage capacityDiffers	500 GB	1.12 TB
Optical drive type	DVD Super Multi DL	DVD Super Multi DL
Storage mediaDiffers	HDD	HDD+SSD
Number of HDDs installed	1	1
HDD capacityDiffers	500 GB	1 TB
HDD interface	SATA III	SATA III
HDD speed	7200 RPM	7200 RPM
Number of SSDs installedKnown for one	Unknown — not stated by the source	1
SSD capacityKnown for one	Unknown — not stated by the source	128 GB
Card reader integrated	Yes	Yes
Compatible memory cardsDiffers	SD, SDHC, SDXC	MMC, SD, SDHC, SDXC
Graphics4 differ
Discrete graphics cardDiffers	No	Yes
On-board graphics card	Yes	Yes
Discrete graphics card modelDiffers	Not available	NVIDIA® GeForce® GT 730
Discrete graphics card memoryKnown for one	Unknown — not stated by the source	2 GB
Discrete graphics memory typeKnown for one	Unknown — not stated by the source	GDDR3
On-board graphics card model	Intel® HD Graphics 630	Intel® HD Graphics 630
Maximum on-board graphics card memory	64 GB	64 GB
Number of displays supported (on-board graphics)	3	3
On-board graphics card base frequency	350 MHz	350 MHz
On-board graphics card dynamic frequency (max)Differs	1100 MHz	1000 MHz
On-board graphics card DirectX version	12.0	12.0
On-board graphics card IDDiffers	0x5912	5912
On-board graphics card OpenGL version	4.4	4.4
Performanceidentical
Product type	PC	PC
Password protectionKnown for one	Unknown — not stated by the source	Yes
Password protection typeKnown for one	Unknown — not stated by the source	BIOS, HDD
Motherboard chipsetKnown for one	Intel® H110	Unknown — not stated by the source
Networkidentical
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Wi-Fi	Yes	Yes
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)	Wi-Fi 5 (802.11ac)
Wi-Fi standards	Wi-Fi 5 (802.11ac)	Wi-Fi 5 (802.11ac)
Bluetooth	Yes	Yes
Bluetooth version	4.1	4.1
Ports & interfacesidentical
USB 2.0 ports quantity	5	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1	1
HDMI ports quantity	1	1
Ethernet LAN (RJ-45) ports	1	1
Headphone outputs	1	1
Microphone in	Yes	Yes
VGA (D-Sub) ports quantityKnown for one	Unknown — not stated by the source	0
DVI portKnown for one	Unknown — not stated by the source	No
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantityKnown for one	0	Unknown — not stated by the source
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantityKnown for one	0	Unknown — not stated by the source
Thunderbolt 3 ports quantityKnown for one	0	Unknown — not stated by the source
Power1 differ
Power supplyDiffers	270 W	350 W
Design1 differ
Chassis type	Desktop	Desktop
Product colourDiffers	White	Black
Softwareidentical
Operating system installed	Windows 10 Home	Windows 10 Home
Operating system architectureKnown for one	Unknown — not stated by the source	64-bit
Processor special features4 differ
CPU configuration (max)	1	1
Embedded options available	No	No
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	Yes	Yes
Intel Enhanced Halt State	Yes	Yes
Intel Identity Protection Technology version	1.00	1.00
Intel Secure Key Technology version	1.00	1.00
Intel Software Guard Extensions (Intel SGX)	Yes	Yes
Intel Stable Image Platform Program (SIPP)	No	No
Intel Stable Image Platform Program (SIPP) version	0.00	0.00
Intel TSX-NI	No	No
Intel TSX-NI version	0.00	0.00
Intel Trusted Execution Technology	No	No
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes	Yes
Intel® InTru™ 3D Technology	Yes	Yes
Intel® OS Guard	Yes	Yes
Intel® Secure Key	Yes	Yes
Processor ARK IDDiffers	97455	97147
Processor codeDiffers	SR35C	SR32W
Processor package size	37.5 x 37.5 mm	37.5 x 37.5 mm
Scalability	1S	1S
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes	Yes
Thermal solution specification	PCG 2015C	PCG 2015C
Intel® Turbo Boost TechnologyDiffers	No	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)Differs	Yes	No
Intel® Quick Sync Video Technology	Yes	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes	Yes
Conflict-Free processor	Yes	Yes
Weight & dimensions4 differ
WidthDiffers	98 mm	173 mm
DepthDiffers	420 mm	406 mm
HeightDiffers	338 mm	356 mm
WeightDiffers	7.55 kg	8.82 kg

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
