Product comparison · 2 pcs/workstations

LG Z series Z71PS-ADG206 PC Intel Pentium G G2020 vs LG Z series Z71PS-ADG226 PC Intel Pentium G G2030

101specifications compared
5differ
96identical
3known for one product only

Key differences

Processor model
- Z series Z71PS-ADG206 PC Intel Pentium G G2020:G2020
- Z series Z71PS-ADG226 PC Intel Pentium G G2030:G2030
Processor frequency
- Z series Z71PS-ADG206 PC Intel Pentium G G2020:2.9 GHz
- Z series Z71PS-ADG226 PC Intel Pentium G G2030:3 GHz
Internal memory
- Z series Z71PS-ADG206 PC Intel Pentium G G2020:2 GB
- Z series Z71PS-ADG226 PC Intel Pentium G G2030:4 GB
Processor ARK ID
- Z series Z71PS-ADG206 PC Intel Pentium G G2020:71070
- Z series Z71PS-ADG226 PC Intel Pentium G G2030:74749
Processor code
- Z series Z71PS-ADG206 PC Intel Pentium G G2020:SR10H
- Z series Z71PS-ADG226 PC Intel Pentium G G2030:SR163

Side by side

Differences highlightedShow differences only

Comparison of Z71PS-ADG206, Z71PS-ADG226
104 specifications	A LG Z series Z71PS-ADG206 PC Intel Pentium G G2020 Model Z71PS-ADG206 View product	B LG Z series Z71PS-ADG226 PC Intel Pentium G G2030 Model Z71PS-ADG226 View product
Processor2 differ
Processor manufacturer	Intel	Intel
Processor family	Intel Pentium G	Intel Pentium G
Processor modelDiffers	G2020	G2030
Processor cores	2	2
Processor threads	2	2
Processor frequencyDiffers	2.9 GHz	3 GHz
Processor cache	3 MB	3 MB
Processor cache type	Smart Cache	Smart Cache
Bus type	DMI	DMI
FSB Parity	No	No
System bus rate	5 GT/s	5 GT/s
Processor lithography	22 nm	22 nm
Processor operating modes	64-bit	64-bit
Processor series	Intel Pentium G2000 Series for Desktop	Intel Pentium G2000 Series for Desktop
Processor codename	Ivy Bridge	Ivy Bridge
Thermal Design Power (TDP)	55 W	55 W
PCI Express configurations	1x16, 2x8, 1x8+2x4	1x16, 2x8, 1x8+2x4
PCI Express slots version	2.0	2.0
Number of processors installed	1	1
Processor socket	LGA 1155 (Socket H2)	LGA 1155 (Socket H2)
CPU multiplier (bus/core ratio)Known for one	29	Unknown — not stated by the source
Stepping	P0	P0
Maximum internal memory supported by processor	32 GB	32 GB
Memory types supported by processor	DDR3-SDRAM	DDR3-SDRAM
Memory clock speeds supported by processor	1333 MHz	1333 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s	25.6 GB/s
ECC supported by processor	Yes	Yes
Memory1 differ
Internal memoryDiffers	2 GB	4 GB
Internal memory type	DDR3-SDRAM	DDR3-SDRAM
Memory channels	Dual-channel	Dual-channel
Storageidentical
Total storage capacity	500 GB	500 GB
Optical drive type	DVD Super Multi	DVD Super Multi
Storage media	HDD	HDD
Number of storage drives installed	1	1
Number of HDDs installed	1	1
HDD capacity	500 GB	500 GB
Card reader integratedKnown for one	Yes	Unknown — not stated by the source
Graphicsidentical
On-board graphics card	Yes	Yes
Discrete graphics card model	Not available	Not available
On-board graphics card family	Intel® HD Graphics	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics	Intel® HD Graphics
Number of displays supported (on-board graphics)	3	3
On-board graphics card base frequency	650 MHz	650 MHz
On-board graphics card dynamic frequency (max)	1050 MHz	1050 MHz
Performanceidentical
Product type	PC	PC
Optical driveidentical
Optical drives quantity	1	1
Networkidentical
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Wi-Fi	No	No
Ports & interfacesidentical
USB 2.0 ports quantity	8	8
Ethernet LAN (RJ-45) ports	1	1
Headphone outputs	1	1
Microphone in	Yes	Yes
VGA (D-Sub) ports quantity	1	1
DVI port	Yes	Yes
PS/2 ports quantity	2	2
Designidentical
Liquid cooling system	No	No
Product colour	Black	Black
Softwareidentical
Operating system installed	No	No
Displayidentical
Display included	No	No
Processor special features2 differ
CPU configuration (max)	1	1
Embedded options available	No	No
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	No	No
Intel Demand Based Switching	No	No
Intel Dual Display Capable Technology	No	No
Intel Enhanced Halt State	Yes	Yes
Intel FDI Technology	No	No
Intel Fast Memory Access	No	No
Intel Flex Memory Access	No	No
Intel HD Graphics	Yes	Yes
Intel Rapid Storage Technology	No	No
Intel Secure Key Technology version	0.00	0.00
Intel Trusted Execution Technology	No	No
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No	No
Intel® AES New Instructions (Intel® AES-NI)	No	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No	No
Intel® InTru™ 3D Technology	No	No
Intel® Insider™	No	No
Intel® Secure Key	No	No
Intel® Smart Cache	Yes	Yes
Intel® Virtualization Technology (Intel® VT)	VT-x	VT-x
Intel® Wireless Display (Intel® WiDi)	No	No
Processor ARK IDDiffers	71070	74749
Processor codeDiffers	SR10H	SR163
Processor package size	37.5 x 37.5 mm	37.5 x 37.5 mm
Supported instruction sets	SSE4.1, SSE4.2	SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes	Yes
Thermal solution specification	PCG 2011C	PCG 2011C
Intel® Turbo Boost Technology	No	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No	No
Intel® Quick Sync Video Technology	No	No
Intel® My WiFi Technology (Intel® MWT)	No	No
Intel® Anti-Theft Technology (Intel® AT)	No	No
Conflict-Free processor	Yes	Yes
Packaging contentidentical
Mouse included	No	No
Keyboard included	No	No
Poweridentical
Power supplyKnown for one	Unknown — not stated by the source	270 W

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
