Product comparison · 2 pcs/workstations

Lenovo ThinkCentre M630e Tiny vs Lenovo ThinkCentre M80q

63specifications compared
21differ
42identical
14known for one product only

Key differences

Processor family
- ThinkCentre M630e Tiny:Intel® Core™ i3
- ThinkCentre M80q:Intel® Core™ i5
Processor model
- ThinkCentre M630e Tiny:i3-8145U
- ThinkCentre M80q:i5-10500T
Processor cores
- ThinkCentre M630e Tiny:2
- ThinkCentre M80q:6
Processor boost frequency
- ThinkCentre M630e Tiny:3.9 GHz
- ThinkCentre M80q:3.8 GHz
Processor frequency
- ThinkCentre M630e Tiny:2.1 GHz
- ThinkCentre M80q:2.3 GHz
Maximum internal memory
- ThinkCentre M630e Tiny:16 GB
- ThinkCentre M80q:64 GB
Memory slots
- ThinkCentre M630e Tiny:1x SO-DIMM
- ThinkCentre M80q:2x SO-DIMM
Total storage capacity
- ThinkCentre M630e Tiny:1 TB
- ThinkCentre M80q:256 GB

Side by side

Differences highlightedShow differences only

Comparison of ThinkCentre M630e Tiny, ThinkCentre M80q
77 specifications	A Lenovo ThinkCentre M630e Tiny View product	B Lenovo ThinkCentre M80q View product
Processor5 differ
Processor manufacturer	Intel	Intel
Processor familyDiffers	Intel® Core™ i3	Intel® Core™ i5
Processor modelDiffers	i3-8145U	i5-10500T
Processor coresDiffers	2	6
Processor threadsKnown for one	4	Unknown — not stated by the source
Processor boost frequencyDiffers	3.9 GHz	3.8 GHz
Processor frequencyDiffers	2.1 GHz	2.3 GHz
Memory2 differ
Internal memory	8 GB	8 GB
Maximum internal memoryDiffers	16 GB	64 GB
Internal memory type	DDR4-SDRAM	DDR4-SDRAM
Memory layout (slots x size)	1 x 8 GB	1 x 8 GB
Memory slotsDiffers	1x SO-DIMM	2x SO-DIMM
Memory clock speed	2666 MHz	2666 MHz
Storage2 differ
Total storage capacityDiffers	1 TB	256 GB
Optical drive type	No	No
Storage mediaDiffers	HDD	SSD
Total HDDs capacityKnown for one	1 TB	Unknown — not stated by the source
Number of HDDs installedKnown for one	1	Unknown — not stated by the source
HDD capacityKnown for one	1 TB	Unknown — not stated by the source
HDD speedKnown for one	5400 RPM	Unknown — not stated by the source
HDD sizeKnown for one	2.5"	Unknown — not stated by the source
Card reader integrated	No	No
Total SSDs capacityKnown for one	Unknown — not stated by the source	256 GB
Number of SSDs installedKnown for one	Unknown — not stated by the source	1
SSD capacityKnown for one	Unknown — not stated by the source	256 GB
NVMeKnown for one	Unknown — not stated by the source	Yes
SSD interfaceKnown for one	Unknown — not stated by the source	PCI Express
SSD form factorKnown for one	Unknown — not stated by the source	M.2
Graphics1 differ
Discrete graphics card	No	No
On-board graphics card	Yes	Yes
Discrete graphics card model	Not available	Not available
On-board GPU manufacturer	Intel	Intel
On-board graphics card family	Intel® UHD Graphics	Intel® UHD Graphics
On-board graphics card modelDiffers	Intel® UHD Graphics 620	Intel® UHD Graphics 630
Performance1 differ
Product type	Mini PC	Mini PC
Motherboard chipsetDiffers	Intel SoC	Intel Q470
Trusted Platform Module (TPM)	Yes	Yes
Network5 differ
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	100,1000 Mbit/s	100,1000 Mbit/s
Wi-Fi	Yes	Yes
Top Wi-Fi standardDiffers	Wi-Fi 5 (802.11ac)	Wi-Fi 6 (802.11ax)
WLAN controller manufacturer	Intel	Intel
Wi-Fi standardsDiffers	Wi-Fi 5 (802.11ac)	Wi-Fi 6 (802.11ax)
WLAN controller modelDiffers	Intel Dual Band Wireless-AC 3165	Intel Wi-Fi 6 AX201
Antenna typeDiffers	1x1	2x2
Bluetooth	Yes	Yes
Bluetooth versionDiffers	4.2	5.1
Ports & interfaces3 differ
USB 2.0 ports quantityDiffers	2	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantityDiffers	3	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantityDiffers	0	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0	0
Thunderbolt 3 ports quantity	0	0
DisplayPorts quantity	1	1
HDMI ports quantity	1	1
Ethernet LAN (RJ-45) ports	1	1
Combo headphone/mic port	Yes	Yes
Microphone inKnown for one	Yes	Unknown — not stated by the source
Poweridentical
Power supply	65 W	65 W
Designidentical
Chassis type	Mini PC	Mini PC
Volume	1 L	1 L
Cable lock slot	Yes	Yes
Cable lock slot type	Kensington	Kensington
Product colour	Black	Black
Software1 differ
Operating system installedDiffers	No	Windows 11 Pro
Operating system languageKnown for one	Unknown — not stated by the source	English
Audioidentical
Audio chip	Realtek ALC233VB	Realtek ALC233VB
Audio system	High Definition Audio	High Definition Audio
Number of speakers	1	1
Weight & dimensions1 differ
Width	179 mm	179 mm
Depth	183 mm	183 mm
WeightDiffers	1.32 kg	1.25 kg
Packaging contentidentical
Mouse connectivity	Wired	Wired
Mouse included	Yes	Yes
Keyboard included	Yes	Yes
Certificatesidentical
Certification	ENERGY STAR,TCO,EPEAT Silver,RoHS	ENERGY STAR,TCO,EPEAT Silver,RoHS
Keyboardidentical
Keyboard connectivity	Wired	Wired

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
