Product comparison · 2 pcs/workstations

ISY NUC SIGNaGE 5H vs ISY Signage 5H

118specifications compared
22differ
96identical
56known for one product only

Key differences

Processor family
- NUC SIGNaGE 5H:Intel® Core™ i5
- Signage 5H:Intel® Core™ i3
Processor generation
- NUC SIGNaGE 5H:5th gen Intel® Core™ i5
- Signage 5H:5th gen Intel® Core™ i3
Processor model
- NUC SIGNaGE 5H:i5-5250U
- Signage 5H:i3-5010U
Processor frequency
- NUC SIGNaGE 5H:1.6 GHz
- Signage 5H:2.1 GHz
Configurable TDP-down
- NUC SIGNaGE 5H:9.5 W
- Signage 5H:10 W
PCI Express configurations
- NUC SIGNaGE 5H:4x1, 2x4
- Signage 5H:2x4, 4x1
On-board graphics card model
- NUC SIGNaGE 5H:Intel® HD Graphics 6000
- Signage 5H:Intel® HD Graphics 5500
On-board graphics card dynamic frequency (max)
- NUC SIGNaGE 5H:950 MHz
- Signage 5H:900 MHz

Side by side

Differences highlightedShow differences only

Comparison of NUC SIGNaGE 5H, Signage 5H
174 specifications	A ISY NUC SIGNaGE 5H View product	B ISY Signage 5H View product
Processor7 differ
Processor manufacturer	Intel	Intel
Processor familyDiffers	Intel® Core™ i5	Intel® Core™ i3
Processor generationDiffers	5th gen Intel® Core™ i5	5th gen Intel® Core™ i3
Processor modelDiffers	i5-5250U	i3-5010U
Processor cores	2	2
Processor threads	4	4
Processor frequencyDiffers	1.6 GHz	2.1 GHz
Processor cache	3 MB	3 MB
Processor cache type	L3	L3
Bus type	DMI2	DMI2
FSB ParityKnown for one	Unknown — not stated by the source	No
System bus rate	5 GT/s	5 GT/s
Processor lithography	14 nm	14 nm
Processor operating modes	32-bit, 64-bit	32-bit, 64-bit
Processor seriesDiffers	Intel® Core™ i5-5200 Mobile Series	Intel Core i3-5000 Mobile series
Processor codename	Broadwell	Broadwell
Thermal Design Power (TDP)	15 W	15 W
Configurable TDP-downDiffers	9.5 W	10 W
Configurable TDP-down frequency	0.6 GHz	0.6 GHz
Tjunction	105 °C	105 °C
Maximum number of PCI Express lanes	12	12
PCI Express configurationsDiffers	4x1, 2x4	2x4, 4x1
PCI Express slots version	2.0	2.0
Number of processors installedKnown for one	Unknown — not stated by the source	1
Processor socket	BGA 1168	BGA 1168
Stepping	F0	F0
Maximum internal memory supported by processor	16 GB	16 GB
Memory types supported by processor	DDR3L-SDRAM, LPDDR3-SDRAM	DDR3L-SDRAM, LPDDR3-SDRAM
Memory clock speeds supported by processor	1333,1600 MHz	1333,1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s	25.6 GB/s
ECC supported by processorKnown for one	Unknown — not stated by the source	No
Processor boost frequencyKnown for one	2.7 GHz	Unknown — not stated by the source
L3 cacheKnown for one	3 MB	Unknown — not stated by the source
Memoryidentical
Internal memory	4 GB	4 GB
Maximum internal memory	16 GB	16 GB
Internal memory type	DDR3L-SDRAM	DDR3L-SDRAM
Memory layout (slots x size)Known for one	Unknown — not stated by the source	1 x 4 GB
Memory slotsKnown for one	Unknown — not stated by the source	2x SO-DIMM
Memory clock speedKnown for one	Unknown — not stated by the source	1600 MHz
Memory channels	Dual-channel	Dual-channel
Storageidentical
Total storage capacity	120 GB	120 GB
Optical drive type	No	No
Storage media	SSD	SSD
Number of SSDs installed	1	1
SSD capacity	120 GB	120 GB
SSD interfaceKnown for one	Unknown — not stated by the source	M.2, SATA III
Number of storage drives supportedKnown for one	2	Unknown — not stated by the source
Card reader integratedKnown for one	No	Unknown — not stated by the source
RAID levelsKnown for one	0, 1	Unknown — not stated by the source
Graphics4 differ
On-board graphics card	Yes	Yes
Discrete graphics card modelKnown for one	Unknown — not stated by the source	Not available
On-board graphics card family	Intel® HD Graphics	Intel® HD Graphics
On-board graphics card modelDiffers	Intel® HD Graphics 6000	Intel® HD Graphics 5500
Maximum on-board graphics card memory	16 GB	16 GB
Number of displays supported (on-board graphics)	3	3
On-board graphics card base frequency	300 MHz	300 MHz
On-board graphics card dynamic frequency (max)Differs	950 MHz	900 MHz
On-board graphics card DirectX versionDiffers	11.3	11.2
On-board graphics card IDDiffers	0x1626	0x1616
On-board graphics card OpenGL version	4.3	4.3
Graphics cardKnown for one	HD Graphics 6000	Unknown — not stated by the source
Graphics card familyKnown for one	Intel	Unknown — not stated by the source
Performance1 differ
Product typeDiffers	Mini PC barebone	Mini PC
Audio output channels	7.1 channels	7.1 channels
Motherboard form factorKnown for one	UCFF	Unknown — not stated by the source
Compatible processor seriesKnown for one	Intel® Core™ i5	Unknown — not stated by the source
BIOS typeKnown for one	EEPROM	Unknown — not stated by the source
Networkidentical
Ethernet LAN	Yes	Yes
Ethernet LAN data ratesKnown for one	Unknown — not stated by the source	10,100,1000 Mbit/s
Cabling technologyKnown for one	Unknown — not stated by the source	10/100/1000Base-T(X)
Wi-Fi	Yes	Yes
Top Wi-Fi standardKnown for one	Unknown — not stated by the source	Wi-Fi 5 (802.11ac)
Wi-Fi standardsKnown for one	Unknown — not stated by the source	Wi-Fi 5 (802.11ac)
Bluetooth	Yes	Yes
Bluetooth version	4.0	4.0
Networking featuresKnown for one	802.11b/g/n/ac	Unknown — not stated by the source
Ports & interfaces2 differ
USB 2.0 ports quantityDiffers	0	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantityKnown for one	Unknown — not stated by the source	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantityKnown for one	Unknown — not stated by the source	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantityKnown for one	Unknown — not stated by the source	0
Thunderbolt 3 ports quantityKnown for one	Unknown — not stated by the source	0
HDMI ports quantity	0	0
HDMI versionDiffers	1.4a	1.4
Ethernet LAN (RJ-45) ports	1	1
Combo headphone/mic port	Yes	Yes
Headphone outputsKnown for one	Unknown — not stated by the source	1
Line-inKnown for one	Unknown — not stated by the source	Yes
Microphone inKnown for one	Unknown — not stated by the source	Yes
VGA (D-Sub) ports quantity	0	0
DVI portKnown for one	Unknown — not stated by the source	No
Mini HDMI ports quantity	1	1
Mini DisplayPorts quantity	1	1
S/PDIF out portKnown for one	Unknown — not stated by the source	No
DC-in jack	Yes	Yes
Number of SATA III connectorsKnown for one	2	Unknown — not stated by the source
Expansion slotsidentical
PCI Express x4 slots	1	1
PCI Express x4 (Gen 2.x) slotsKnown for one	1	Unknown — not stated by the source
Poweridentical
Power supply	65 W	65 W
Power supply typeKnown for one	External AC adapter	Unknown — not stated by the source
Design2 differ
Chassis typeDiffers	UCFF	Mini PC
VolumeKnown for one	Unknown — not stated by the source	0.6 L
Placement supportedKnown for one	Unknown — not stated by the source	Horizontal
VESA mounting	Yes	Yes
Product colourDiffers	Black, Silver	Black, Stainless steel
Cable lock slotKnown for one	Yes	Unknown — not stated by the source
Cable lock slot typeKnown for one	Kensington	Unknown — not stated by the source
Cooling typeKnown for one	Active	Unknown — not stated by the source
Housing materialKnown for one	Aluminium, Plastic	Unknown — not stated by the source
Softwareidentical
Operating system installed	No	No
Displayidentical
Display included	No	No
Number of displays supportedKnown for one	3	Unknown — not stated by the source
Processor special features5 differ
CPU configuration (max)	1	1
Embedded options availableDiffers	No	Yes
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Graphics & IMC lithography	14 nm	14 nm
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	Yes	Yes
Intel Demand Based SwitchingKnown for one	Unknown — not stated by the source	No
Intel Dual Display Capable TechnologyKnown for one	Unknown — not stated by the source	No
Intel Enhanced Halt State	Yes	Yes
Intel FDI Technology	Yes	Yes
Intel Fast Memory Access	Yes	Yes
Intel Flex Memory Access	Yes	Yes
Intel Identity Protection Technology version	1.00	1.00
Intel Rapid Storage TechnologyKnown for one	Unknown — not stated by the source	No
Intel Secure Key Technology version	1.00	1.00
Intel Small Business Advantage (SBA) version	1.00	1.00
Intel Smart Response Technology version	1.00	1.00
Intel Stable Image Platform Program (SIPP)	No	No
Intel Stable Image Platform Program (SIPP) version	0.00	0.00
Intel TSX-NI	No	No
Intel TSX-NI version	0.00	0.00
Intel Trusted Execution Technology	No	No
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes	Yes
Intel® InTru™ 3D Technology	Yes	Yes
Intel® Insider™	Yes	Yes
Intel® OS Guard	Yes	Yes
Intel® Secure Key	Yes	Yes
Intel® Small Business Advantage (Intel® SBA)	Yes	Yes
Intel® Wireless Display (Intel® WiDi)	Yes	Yes
Processor ARK IDDiffers	84984	84697
Processor codeDiffers	SR26C	SR23Z
Processor package sizeDiffers	40 x24 x 1.3 mm	40 x 24x 1.3 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes	Yes
Intel® Smart Response Technology	Yes	Yes
Intel® Turbo Boost TechnologyDiffers	2.0	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes	Yes
Intel® Quick Sync Video Technology	Yes	Yes
Intel® My WiFi Technology (Intel® MWT)Known for one	Unknown — not stated by the source	No
Intel® Identity Protection Technology (Intel® IPT)	Yes	Yes
Intel® Anti-Theft Technology (Intel® AT)Known for one	Unknown — not stated by the source	No
Conflict-Free processor	Yes	Yes
Intel® Smart CacheKnown for one	Yes	Unknown — not stated by the source
Intel® Virtualization Technology (Intel® VT)Known for one	VT-d, VT-x	Unknown — not stated by the source
Weight & dimensionsidentical
Width	115 mm	115 mm
Depth	111 mm	111 mm
Height	48.7 mm	48.7 mm
Packaging dataidentical
Package widthKnown for one	Unknown — not stated by the source	220 mm
Package depthKnown for one	Unknown — not stated by the source	250 mm
Package heightKnown for one	Unknown — not stated by the source	120 mm
Package weightKnown for one	Unknown — not stated by the source	2.5 kg
Certificates1 differ
CertificationDiffers	IEC 60950-1, UL 60950-1, EN 60950-1, CAN/CSA-C22.2 No. 60950-1, CISPR 22, FCC CFR Title 47, Chapter I, Part 15,\nSubparts A, B, ICES-003, EN 55022, EN 55024, VCCI V-3, V-4, KN-22, KN-24, CNS 13438, RoHS, WEEE	CE
Operational conditionsidentical
Operating temperature (T-T)Known for one	0 - 50 °C	Unknown — not stated by the source
Storage temperature (T-T)Known for one	-20 - 70 °C	Unknown — not stated by the source
Packaging contentidentical
AC adapter includedKnown for one	Yes	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
