Product comparison · 2 pcs/workstations

Haier V8 Intel® Core™ i5 i5-7400 vs Haier X3K Intel Pentium G G4560

106specifications compared
23differ
83identical
8known for one product only

Key differences

Processor family
- V8 Intel® Core™ i5 i5-7400:Intel® Core™ i5
- X3K Intel Pentium G G4560:Intel Pentium G
Processor model
- V8 Intel® Core™ i5 i5-7400:i5-7400
- X3K Intel Pentium G G4560:G4560
Processor cores
- V8 Intel® Core™ i5 i5-7400:4
- X3K Intel Pentium G G4560:2
Processor frequency
- V8 Intel® Core™ i5 i5-7400:3 GHz
- X3K Intel Pentium G G4560:3.5 GHz
Processor cache
- V8 Intel® Core™ i5 i5-7400:6 MB
- X3K Intel Pentium G G4560:3 MB
Processor operating modes
- V8 Intel® Core™ i5 i5-7400:64-bit
- X3K Intel Pentium G G4560:32-bit, 64-bit
Thermal Design Power (TDP)
- V8 Intel® Core™ i5 i5-7400:65 W
- X3K Intel Pentium G G4560:54 W
Internal memory
- V8 Intel® Core™ i5 i5-7400:8 GB
- X3K Intel Pentium G G4560:4 GB

Side by side

Differences highlightedShow differences only

Comparison of V8, X3K
114 specifications	A Haier V8 Intel® Core™ i5 i5-7400 Model V8 View product	B Haier X3K Intel Pentium G G4560 Model X3K View product
Processor8 differ
Processor manufacturer	Intel	Intel
Processor familyDiffers	Intel® Core™ i5	Intel Pentium G
Processor generationKnown for one	7th gen Intel® Core™ i5	Unknown — not stated by the source
Processor modelDiffers	i5-7400	G4560
Processor coresDiffers	4	2
Processor threads	4	4
Processor boost frequencyKnown for one	3.5 GHz	Unknown — not stated by the source
Processor frequencyDiffers	3 GHz	3.5 GHz
Processor cacheDiffers	6 MB	3 MB
Processor cache typeKnown for one	Smart Cache	Unknown — not stated by the source
Bus type	DMI3	DMI3
System bus rate	8 GT/s	8 GT/s
Processor lithography	14 nm	14 nm
Processor operating modesDiffers	64-bit	32-bit, 64-bit
Processor seriesDiffers	Intel Core i5-7400 Desktop Series	Intel Pentium G4500 Series For Desktop
Processor codename	Kaby Lake	Kaby Lake
Thermal Design Power (TDP)Differs	65 W	54 W
Tjunction	100 °C	100 °C
Maximum number of PCI Express lanes	16	16
PCI Express configurations	1x16, 1x8+2x4, 2x8	1x16, 1x8+2x4, 2x8
PCI Express slots version	3.0	3.0
Number of QPI links	0	0
Number of processors installed	1	1
Processor socket	LGA 1151 (Socket H4)	LGA 1151 (Socket H4)
Stepping	B0	B0
Maximum internal memory supported by processor	64 GB	64 GB
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM	DDR3L-SDRAM, DDR4-SDRAM
Memory clock speeds supported by processor	1333,1600,2133,2400 MHz	1333,1600,2133,2400 MHz
ECC supported by processor	No	No
Memory voltage supported by processor	1.35 V	1.35 V
Memory1 differ
Internal memoryDiffers	8 GB	4 GB
Maximum internal memory	16 GB	16 GB
Internal memory type	DDR4-SDRAM	DDR4-SDRAM
Memory channels	Dual-channel	Dual-channel
Storageidentical
Total storage capacity	1 TB	1 TB
Optical drive type	No	No
Storage media	HDD	HDD
Graphics5 differ
Discrete graphics cardDiffers	Yes	No
On-board graphics card	Yes	Yes
Discrete graphics card modelDiffers	NVIDIA® GeForce® GT 720	Not available
Discrete graphics card memoryKnown for one	2 GB	Unknown — not stated by the source
On-board graphics card modelDiffers	Intel® HD Graphics 630	Intel® HD Graphics 610
Maximum on-board graphics card memory	64 GB	64 GB
Number of displays supported (on-board graphics)	3	3
On-board graphics card base frequency	350 MHz	350 MHz
On-board graphics card dynamic frequency (max)Differs	1000 MHz	1050 MHz
On-board graphics card DirectX version	12.0	12.0
On-board graphics card IDDiffers	5912	0x5902
On-board graphics card OpenGL version	4.4	4.4
Performanceidentical
Product type	PC	PC
Motherboard chipset	Intel® H110	Intel® H110
Networkidentical
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Ports & interfaces1 differ
Thunderbolt 3 ports quantity	0	0
HDMI ports quantity	1	1
Ethernet LAN (RJ-45) ports	1	1
Headphone outputs	1	1
Microphone in	Yes	Yes
VGA (D-Sub) ports quantity	1	1
DVI portDiffers	Yes	No
PS/2 ports quantity	2	2
Expansion slotsidentical
PCI Express x1 slots	2	2
PCI Express x16 slots	1	1
Poweridentical
Power supply	180 W	180 W
Design1 differ
Product colourDiffers	Black	Black, Gold
Softwareidentical
Operating system installed	Windows 10 Home	Windows 10 Home
Display1 differ
Display includedDiffers	No	Yes
Display diagonalKnown for one	Unknown — not stated by the source	52.6 cm (20.7")
Full HDKnown for one	Unknown — not stated by the source	Yes
Display resolutionKnown for one	Unknown — not stated by the source	1920 x 1080 pixels
Processor special features5 differ
CPU configuration (max)	1	1
Embedded options available	No	No
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	Yes	Yes
Intel Enhanced Halt State	Yes	Yes
Intel Identity Protection Technology version	1.00	1.00
Intel Secure Key Technology version	1.00	1.00
Intel Software Guard Extensions (Intel SGX)	Yes	Yes
Intel Stable Image Platform Program (SIPP)	No	No
Intel Stable Image Platform Program (SIPP) version	0.00	0.00
Intel TSX-NI	No	No
Intel TSX-NI version	0.00	0.00
Intel Trusted Execution Technology	No	No
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes	Yes
Intel® InTru™ 3D Technology	Yes	Yes
Intel® OS Guard	Yes	Yes
Intel® Secure Key	Yes	Yes
Processor ARK IDDiffers	97147	97143
Processor codeDiffers	SR32W	SR32Y
Processor package size	37.5 x 37.5 mm	37.5 x 37.5 mm
Scalability	1S	1S
Supported instruction setsDiffers	AVX 2.0, SSE4.1, SSE4.2	SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes	Yes
Thermal solution specification	PCG 2015C	PCG 2015C
Intel® Turbo Boost TechnologyDiffers	2.0	No
Intel® Hyper Threading Technology (Intel® HT Technology)Differs	No	Yes
Intel® Quick Sync Video Technology	Yes	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes	Yes
Conflict-Free processor	Yes	Yes
Graphics & IMC lithographyKnown for one	Unknown — not stated by the source	14 nm
Weight & dimensions1 differ
Width	175 mm	175 mm
Depth	387.4 mm	387.4 mm
Height	443.5 mm	443.5 mm
WeightDiffers	9.5 kg	9 kg
Packaging contentidentical
Mouse included	Yes	Yes
Keyboard included	Yes	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
