Product comparison · 2 pcs/workstations

Haier H5 Intel® Core™ i3 i3-7100 vs Haier V9A Intel® Core™ i7 i7-7700

95specifications compared
30differ
65identical
24known for one product only

Key differences

Processor family
- H5 Intel® Core™ i3 i3-7100:Intel® Core™ i3
- V9A Intel® Core™ i7 i7-7700:Intel® Core™ i7
Processor generation
- H5 Intel® Core™ i3 i3-7100:7th gen Intel® Core™ i3
- V9A Intel® Core™ i7 i7-7700:7th gen Intel® Core™ i7
Processor model
- H5 Intel® Core™ i3 i3-7100:i3-7100
- V9A Intel® Core™ i7 i7-7700:i7-7700
Processor cores
- H5 Intel® Core™ i3 i3-7100:2
- V9A Intel® Core™ i7 i7-7700:4
Processor threads
- H5 Intel® Core™ i3 i3-7100:4
- V9A Intel® Core™ i7 i7-7700:8
Processor frequency
- H5 Intel® Core™ i3 i3-7100:3.9 GHz
- V9A Intel® Core™ i7 i7-7700:3.6 GHz
Processor cache
- H5 Intel® Core™ i3 i3-7100:3 MB
- V9A Intel® Core™ i7 i7-7700:8 MB
Thermal Design Power (TDP)
- H5 Intel® Core™ i3 i3-7100:51 W
- V9A Intel® Core™ i7 i7-7700:65 W

Side by side

Differences highlightedShow differences only

Comparison of H5, V9A
119 specifications	A Haier H5 Intel® Core™ i3 i3-7100 Model H5 View product	B Haier V9A Intel® Core™ i7 i7-7700 Model V9A View product
Processor10 differ
Processor manufacturer	Intel	Intel
Processor familyDiffers	Intel® Core™ i3	Intel® Core™ i7
Processor generationDiffers	7th gen Intel® Core™ i3	7th gen Intel® Core™ i7
Processor modelDiffers	i3-7100	i7-7700
Processor coresDiffers	2	4
Processor threadsDiffers	4	8
Processor frequencyDiffers	3.9 GHz	3.6 GHz
Processor cacheDiffers	3 MB	8 MB
Processor cache type	Smart Cache	Smart Cache
Bus type	DMI3	DMI3
System bus rate	8 GT/s	8 GT/s
Processor lithography	14 nm	14 nm
Processor operating modes	64-bit	64-bit
Processor codename	Kaby Lake	Kaby Lake
Thermal Design Power (TDP)Differs	51 W	65 W
Tjunction	100 °C	100 °C
Maximum number of PCI Express lanes	16	16
PCI Express configurations	1x16, 1x8+2x4, 2x8	1x16, 1x8+2x4, 2x8
PCI Express slots version	3.0	3.0
Number of processors installed	1	1
Processor socket	LGA 1151 (Socket H4)	LGA 1151 (Socket H4)
SteppingDiffers	S0	B0
Maximum internal memory supported by processor	64 GB	64 GB
Memory types supported by processorDiffers	DDR3L-SDRAM, DDR4-SDRAM	DDR3L, DDR4-SDRAM
Memory clock speeds supported by processor	1333,1600,2133,2400 MHz	1333,1600,2133,2400 MHz
ECC supported by processor	No	No
Processor boost frequencyKnown for one	Unknown — not stated by the source	4.2 GHz
Memory voltage supported by processorKnown for one	Unknown — not stated by the source	1.35 V
Memory2 differ
Internal memoryDiffers	4 GB	8 GB
Maximum internal memoryDiffers	16 GB	32 GB
Internal memory type	DDR4-SDRAM	DDR4-SDRAM
Memory channels	Dual-channel	Dual-channel
Memory clock speedKnown for one	Unknown — not stated by the source	2133 MHz
Storage2 differ
Total storage capacityDiffers	500 GB	1.12 TB
Optical drive type	No	No
Storage mediaDiffers	HDD	HDD+SSD
Card reader integratedKnown for one	Unknown — not stated by the source	Yes
Graphics3 differ
Discrete graphics cardDiffers	No	Yes
On-board graphics card	Yes	Yes
Discrete graphics card modelDiffers	Not available	NVIDIA® GeForce® GTX 1050 Ti
On-board graphics card model	Intel® HD Graphics 630	Intel® HD Graphics 630
Maximum on-board graphics card memory	64 GB	64 GB
Number of displays supported (on-board graphics)	3	3
On-board graphics card base frequency	350 MHz	350 MHz
On-board graphics card dynamic frequency (max)Differs	1100 MHz	1150 MHz
On-board graphics card DirectX version	12.0	12.0
On-board graphics card ID	0x5912	0x5912
On-board graphics card OpenGL version	4.4	4.4
Discrete graphics card memoryKnown for one	Unknown — not stated by the source	4 GB
Performanceidentical
Product type	PC	PC
Motherboard chipset	Intel® H110	Intel® H110
Networkidentical
Ethernet LAN	Yes	Yes
Ethernet LAN data ratesKnown for one	Unknown — not stated by the source	10,100,1000 Mbit/s
Ports & interfaces2 differ
USB 2.0 ports quantityKnown for one	2	Unknown — not stated by the source
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantityKnown for one	4	Unknown — not stated by the source
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantityKnown for one	0	Unknown — not stated by the source
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantityKnown for one	0	Unknown — not stated by the source
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantityKnown for one	0	Unknown — not stated by the source
Thunderbolt 3 ports quantity	0	0
HDMI ports quantity	1	1
Ethernet LAN (RJ-45) ports	1	1
Headphone outputs	1	1
Microphone in	Yes	Yes
VGA (D-Sub) ports quantityDiffers	1	0
DVI portDiffers	No	Yes
DisplayPorts quantityKnown for one	Unknown — not stated by the source	1
PS/2 ports quantityKnown for one	Unknown — not stated by the source	2
Expansion slotsidentical
PCI slotsKnown for one	1	Unknown — not stated by the source
PCI Express x1 slotsKnown for one	Unknown — not stated by the source	2
PCI Express x16 slotsKnown for one	Unknown — not stated by the source	1
Power1 differ
Power supplyDiffers	90 W	300 W
Designidentical
Product colour	Black	Black
Softwareidentical
Operating system installed	Windows 10 Home	Windows 10 Home
Display1 differ
Display includedDiffers	Yes	No
Display diagonalKnown for one	49.5 cm (19.5")	Unknown — not stated by the source
Display resolutionKnown for one	1440 x 900 pixels	Unknown — not stated by the source
Processor special features9 differ
CPU configuration (max)	1	1
Embedded options availableDiffers	No	Yes
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	Yes	Yes
Intel Enhanced Halt State	Yes	Yes
Intel Identity Protection Technology version	1.00	1.00
Intel Secure Key Technology version	1.00	1.00
Intel Software Guard Extensions (Intel SGX)	Yes	Yes
Intel Stable Image Platform Program (SIPP)Differs	No	Yes
Intel Stable Image Platform Program (SIPP) versionDiffers	0.00	1.00
Intel TSX-NIDiffers	No	Yes
Intel TSX-NI versionDiffers	0.00	1.00
Intel Trusted Execution TechnologyDiffers	No	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes	Yes
Intel® InTru™ 3D Technology	Yes	Yes
Intel® OS Guard	Yes	Yes
Intel® Secure Key	Yes	Yes
Processor ARK IDDiffers	97455	97128
Processor codeDiffers	SR35C	SR338
Processor package size	37.5 x 37.5 mm	37.5 x 37.5 mm
Scalability	1S	1S
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes	Yes
Thermal solution specification	PCG 2015C	PCG 2015C
Intel® Turbo Boost TechnologyDiffers	No	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes	Yes
Intel® Quick Sync Video Technology	Yes	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes	Yes
Conflict-Free processor	Yes	Yes
Weight & dimensionsidentical
WidthKnown for one	105 mm	Unknown — not stated by the source
DepthKnown for one	281 mm	Unknown — not stated by the source
HeightKnown for one	360 mm	Unknown — not stated by the source
WeightKnown for one	5 kg	Unknown — not stated by the source
Packaging contentidentical
Mouse includedKnown for one	Unknown — not stated by the source	Yes
Keyboard includedKnown for one	Unknown — not stated by the source	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
