Product comparison · 2 pcs/workstations

Acer Veriton VS6660G Intel® Core™ i5 i5-8500 vs ASUS VivoMini VC65-C1G5091ZN Intel® Core™ i5 i5-8400T

108specifications compared
32differ
76identical
28known for one product only

Key differences

Processor model
- Veriton VS6660G Intel® Core™ i5 i5-8500:i5-8500
- VivoMini VC65-C1G5091ZN Intel® Core™ i5 i5-8400T:i5-8400T
Processor boost frequency
- Veriton VS6660G Intel® Core™ i5 i5-8500:4.1 GHz
- VivoMini VC65-C1G5091ZN Intel® Core™ i5 i5-8400T:3.3 GHz
Processor frequency
- Veriton VS6660G Intel® Core™ i5 i5-8500:3 GHz
- VivoMini VC65-C1G5091ZN Intel® Core™ i5 i5-8400T:1.7 GHz
Thermal Design Power (TDP)
- Veriton VS6660G Intel® Core™ i5 i5-8500:65 W
- VivoMini VC65-C1G5091ZN Intel® Core™ i5 i5-8400T:35 W
Maximum internal memory
- Veriton VS6660G Intel® Core™ i5 i5-8500:64 GB
- VivoMini VC65-C1G5091ZN Intel® Core™ i5 i5-8400T:16 GB
Internal memory type
- Veriton VS6660G Intel® Core™ i5 i5-8500:DDR4-SDRAM
- VivoMini VC65-C1G5091ZN Intel® Core™ i5 i5-8400T:DDR3L-SDRAM
Total storage capacity
- Veriton VS6660G Intel® Core™ i5 i5-8500:256 GB
- VivoMini VC65-C1G5091ZN Intel® Core™ i5 i5-8400T:128 GB
Total SSDs capacity
- Veriton VS6660G Intel® Core™ i5 i5-8500:256 GB
- VivoMini VC65-C1G5091ZN Intel® Core™ i5 i5-8400T:128 GB

Side by side

Differences highlightedShow differences only

Comparison of VS6660G, VC65-C1G5091ZN
136 specifications	A Acer Veriton VS6660G Intel® Core™ i5 i5-8500 Model VS6660G View product	B ASUS VivoMini VC65-C1G5091ZN Intel® Core™ i5 i5-8400T Model VC65-C1G5091ZN View product
Processor4 differ
Processor manufacturer	Intel	Intel
Processor family	Intel® Core™ i5	Intel® Core™ i5
Processor generation	8th gen Intel® Core™ i5	8th gen Intel® Core™ i5
Processor modelDiffers	i5-8500	i5-8400T
Processor cores	6	6
Processor threads	6	6
Processor boost frequencyDiffers	4.1 GHz	3.3 GHz
Processor frequencyDiffers	3 GHz	1.7 GHz
Processor cache	9 MB	9 MB
Processor cache type	Smart Cache	Smart Cache
Bus type	DMI3	DMI3
System bus rate	8 GT/s	8 GT/s
Processor lithography	14 nm	14 nm
Processor operating modes	64-bit	64-bit
Processor codename	Coffee Lake	Coffee Lake
Thermal Design Power (TDP)Differs	65 W	35 W
Configurable TDP-downKnown for one	Unknown — not stated by the source	25 W
Configurable TDP-down frequencyKnown for one	Unknown — not stated by the source	1.2 GHz
Tjunction	100 °C	100 °C
Maximum number of PCI Express lanes	16	16
PCI Express configurations	1x16, 1x8+2x4, 2x8	1x16, 1x8+2x4, 2x8
PCI Express slots version	3.0	3.0
Number of processors installed	1	1
Processor socket	LGA 1151 (Socket H4)	LGA 1151 (Socket H4)
SteppingKnown for one	Unknown — not stated by the source	U0
Maximum internal memory supported by processor	64 GB	64 GB
Memory types supported by processor	DDR4-SDRAM	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s	41.6 GB/s
Memory2 differ
Internal memory	8 GB	8 GB
Maximum internal memoryDiffers	64 GB	16 GB
Internal memory typeDiffers	DDR4-SDRAM	DDR3L-SDRAM
Memory slotsKnown for one	Unknown — not stated by the source	2x SO-DIMM
Memory clock speedKnown for one	Unknown — not stated by the source	1600 MHz
Storage4 differ
Total storage capacityDiffers	256 GB	128 GB
Storage media	SSD	SSD
Total SSDs capacityDiffers	256 GB	128 GB
Number of SSDs installed	1	1
SSD capacityDiffers	256 GB	128 GB
Card reader integratedDiffers	No	Yes
Compatible memory cardsKnown for one	Unknown — not stated by the source	MMC, SD, SDHC, SDXC
Optical drive typeKnown for one	No	Unknown — not stated by the source
Number of storage drives installedKnown for one	1	Unknown — not stated by the source
Graphics1 differ
Discrete graphics card	No	No
On-board graphics card	Yes	Yes
Discrete graphics card model	Not available	Not available
On-board graphics card model	Intel® UHD Graphics 630	Intel® UHD Graphics 630
Maximum on-board graphics card memory	64 GB	64 GB
Number of displays supported (on-board graphics)	3	3
On-board graphics card base frequency	350 MHz	350 MHz
On-board graphics card dynamic frequency (max)Differs	1100 MHz	1050 MHz
On-board graphics card DirectX version	12.0	12.0
On-board graphics card ID	0x3E92	0x3E92
On-board graphics card OpenGL version	4.5	4.5
On-board graphics card familyKnown for one	Intel® UHD Graphics	Unknown — not stated by the source
Performance1 differ
Product typeDiffers	PC	Mini PC
Motherboard chipsetKnown for one	Unknown — not stated by the source	Intel® H110
Network1 differ
Ethernet LAN	Yes	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Wi-FiDiffers	No	Yes
Top Wi-Fi standardKnown for one	Unknown — not stated by the source	Wi-Fi 4 (802.11n)
Wi-Fi standardsKnown for one	Unknown — not stated by the source	802.11b, 802.11g, Wi-Fi 4 (802.11n)
BluetoothKnown for one	Unknown — not stated by the source	Yes
Bluetooth versionKnown for one	Unknown — not stated by the source	4.0
Cabling technologyKnown for one	10/100/1000Base-T(X)	Unknown — not stated by the source
Ports & interfaces3 differ
USB 2.0 ports quantity	2	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantityDiffers	4	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantityDiffers	2	0
Thunderbolt 3 ports quantity	0	0
DisplayPorts quantityDiffers	2	1
HDMI ports quantity	1	1
Ethernet LAN (RJ-45) ports	1	1
Headphone outputs	1	1
Microphone in	Yes	Yes
VGA (D-Sub) ports quantity	1	1
DVI port	No	No
Serial ports quantityKnown for one	Unknown — not stated by the source	1
Line-outKnown for one	Yes	Unknown — not stated by the source
Line-inKnown for one	Yes	Unknown — not stated by the source
Power1 differ
Power supplyDiffers	180 W	90 W
Design2 differ
Chassis typeDiffers	Desktop	Mini PC
Cable lock slotKnown for one	Unknown — not stated by the source	Yes
Cable lock slot typeKnown for one	Unknown — not stated by the source	Kensington
Product colourDiffers	Black	Grey
Placement supportedKnown for one	Vertical	Unknown — not stated by the source
Software1 differ
Operating system installedDiffers	Windows 10 Pro	Windows 10 Home
Operating system architectureKnown for one	64-bit	Unknown — not stated by the source
Displayidentical
Display included	No	No
Processor special features8 differ
CPU configuration (max)	1	1
Embedded options availableDiffers	Yes	No
Enhanced Intel SpeedStep Technology	Yes	Yes
Execute Disable Bit	Yes	Yes
Idle States	Yes	Yes
Intel 64	Yes	Yes
Intel Clear Video Technology	Yes	Yes
Intel Enhanced Halt State	Yes	Yes
Intel Identity Protection Technology version	1.00	1.00
Intel Secure Key Technology version	1.00	1.00
Intel Software Guard Extensions (Intel SGX)	Yes	Yes
Intel Stable Image Platform Program (SIPP)Differs	Yes	No
Intel Stable Image Platform Program (SIPP) versionDiffers	1.00	0.00
Intel TSX-NIDiffers	Yes	No
Intel TSX-NI versionDiffers	1.00	0.00
Intel Trusted Execution TechnologyDiffers	Yes	No
Intel VT-x with Extended Page Tables (EPT)	Yes	Yes
Intel Virtualization Technology (VT-x)	Yes	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	Yes	Yes
Intel® InTru™ 3D Technology	Yes	Yes
Intel® OS Guard	Yes	Yes
Intel® Secure Key	Yes	Yes
Processor ARK IDDiffers	129939	129940
Processor codeKnown for one	Unknown — not stated by the source	SR3X6
Processor package size	37.5 x 37.5 mm	37.5 x 37.5 mm
Scalability	1S	1S
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes	Yes
Thermal solution specificationDiffers	PCG 2015C	PCG 2015A
Intel® Turbo Boost Technology	2.0	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	No	No
Intel® Quick Sync Video Technology	Yes	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes	Yes
Conflict-Free processor	Yes	Yes
Weight & dimensions4 differ
WidthDiffers	160 mm	197.5 mm
DepthDiffers	309.3 mm	196.3 mm
HeightDiffers	350 mm	61.9 mm
WeightDiffers	7 kg	2.2 kg
Expansion slotsidentical
PCI Express x1 slotsKnown for one	1	Unknown — not stated by the source
PCI Express x16 slotsKnown for one	2	Unknown — not stated by the source
Packaging contentidentical
Mouse includedKnown for one	Yes	Unknown — not stated by the source
Keyboard includedKnown for one	Yes	Unknown — not stated by the source
Certificatesidentical
Compliance certificatesKnown for one	RoHS	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
