Product comparison · 2 network transceiver modules

Lanview MO-GLC-BX10-U network transceiver module Fiber optic 1000 Mbit/s SFP vs Lanview MO-GLC-EX-SMD network transceiver module Fiber optic 1000 Mbit/s SFP 1310 nm

25specifications compared
2differ
23identical
5known for one product only

Key differences

Maximum transfer distance
- MO-GLC-BX10-U network transceiver module Fiber optic 1000 Mbit/s SFP:20000 m
- MO-GLC-EX-SMD network transceiver module Fiber optic 1000 Mbit/s SFP 1310 nm:40000 m
Compatible products
- MO-GLC-BX10-U network transceiver module Fiber optic 1000 Mbit/s SFP:Cisco GLC-BX10-U
- MO-GLC-EX-SMD network transceiver module Fiber optic 1000 Mbit/s SFP 1310 nm:Cisco GLC-EX-SMD

Side by side

Differences highlightedShow differences only

Comparison of MO-GLC-BX10-U, MO-GLC-EX-SMD
30 specifications	A Lanview MO-GLC-BX10-U network transceiver module Fiber optic 1000 Mbit/s SFP Model MO-GLC-BX10-U View product	B Lanview MO-GLC-EX-SMD network transceiver module Fiber optic 1000 Mbit/s SFP 1310 nm Model MO-GLC-EX-SMD View product
Performance1 differ
SFP transceiver type	Fiber optic	Fiber optic
Maximum data transfer rate	1000 Mbit/s	1000 Mbit/s
Interface type	SFP	SFP
Single-mode fiber (SMF) supported	Yes	Yes
Multi-mode fiber (MMF) supported	No	No
Fiber optic connector	LC	LC
Maximum transfer distanceDiffers	20000 m	40000 m
WavelengthKnown for one	Unknown — not stated by the source	1310 nm
Cabling technologyKnown for one	Unknown — not stated by the source	10/100/1000
Duplex system	Full	Full
Digital Diagnostics Monitoring (DDM)	Yes	Yes
Fiber ports quantity	1	1
Tx wavelength (min)Known for one	1310 nm	Unknown — not stated by the source
Rx wavelength (min)Known for one	1550 nm	Unknown — not stated by the source
Features1 differ
Form factorKnown for one	Unknown — not stated by the source	SFP
Plug and Play	Yes	Yes
Easy to install	Yes	Yes
Brand compatibility	Cisco	Cisco
Compatible productsDiffers	Cisco GLC-BX10-U	Cisco GLC-EX-SMD
Certificatesidentical
Certification	MSA	MSA
Operational conditionsidentical
Operating temperature (T-T)	-45 - 75 °C	-45 - 75 °C
Storage temperature (T-T)	-40 - 85 °C	-40 - 85 °C
Storage relative humidity (H-H)	10 - 85%	10 - 85%
Weight & dimensionsidentical
Width	12 mm	12 mm
Depth	56 mm	56 mm
Height	8.5 mm	8.5 mm
Weight	10 g	10 g
Packaging contentidentical
Quantity per pack	1 pc(s)	1 pc(s)
Packaging dataidentical
Package weight	20 g	20 g
Package type	Window box	Window box

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
