Product comparison · 2 network transceiver modules

Intellinet Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 120 km (75 mi.), BiDi WDM (RX1490/TX1550), MSA-c vs Intellinet Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 10 km (6.2 mi.), BiDi WDM (RX1550/TX1310), HPE-c

39specifications compared
7differ
32identical
1known for one product only

Key differences

Maximum transfer distance
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 120 km (75 mi.), BiDi WDM (RX1490/TX1550), MSA-c:120000 m
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 10 km (6.2 mi.), BiDi WDM (RX1550/TX1310), HPE-c:10000 m
Tx wavelength (max)
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 120 km (75 mi.), BiDi WDM (RX1490/TX1550), MSA-c:1550 nm
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 10 km (6.2 mi.), BiDi WDM (RX1550/TX1310), HPE-c:1310 nm
Rx wavelength (max)
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 120 km (75 mi.), BiDi WDM (RX1490/TX1550), MSA-c:1490 nm
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 10 km (6.2 mi.), BiDi WDM (RX1550/TX1310), HPE-c:1550 nm
Tx power (min)
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 120 km (75 mi.), BiDi WDM (RX1490/TX1550), MSA-c:0 dBmW
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 10 km (6.2 mi.), BiDi WDM (RX1550/TX1310), HPE-c:-3 dBmW
Tx power (max)
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 120 km (75 mi.), BiDi WDM (RX1490/TX1550), MSA-c:5 dBmW
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 10 km (6.2 mi.), BiDi WDM (RX1550/TX1310), HPE-c:-8 dBmW
Brand compatibility
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 120 km (75 mi.), BiDi WDM (RX1490/TX1550), MSA-c:MSA Compliant
- Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 10 km (6.2 mi.), BiDi WDM (RX1550/TX1310), HPE-c:HPE

Side by side

Differences highlightedShow differences only

Comparison of 508650, 508780
40 specifications	A Intellinet Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 120 km (75 mi.), BiDi WDM (RX1490/TX1550), MSA-c Model 508650 View product	B Intellinet Gigabit Fiber WDM Bi-Directional SFP Optical Transceiver Module 1000Base-BX-D (LC) Single-Mode Port, 10 km (6.2 mi.), BiDi WDM (RX1550/TX1310), HPE-c Model 508780 View product
Performance5 differ
SFP transceiver type	Fiber optic	Fiber optic
Maximum data transfer rate	1000 Mbit/s	1000 Mbit/s
Interface type	mini-GBIC/SFP	mini-GBIC/SFP
Single-mode fiber (SMF) supported	Yes	Yes
Fiber optic connector	LC	LC
Fiber cable diameters supported (core/cladding)	9/125 µm	9/125 µm
SFP transceiver standard	BX-D	BX-D
Maximum transfer distanceDiffers	120000 m	10000 m
Tx wavelength (max)Differs	1550 nm	1310 nm
Rx wavelength (max)Differs	1490 nm	1550 nm
Tx power (min)Differs	0 dBmW	-3 dBmW
Tx power (max)Differs	5 dBmW	-8 dBmW
Link budgetKnown for one	Unknown — not stated by the source	16 dB
Networking standards	IEEE 802.3z	IEEE 802.3z
Fiber ethernet cabling technology	1000BASE	1000BASE
Digital Diagnostics Monitoring (DDM)	Yes	Yes
Wavelength-division multiplexing (WDM)	Yes	Yes
Features1 differ
Product colour	Silver	Silver
Housing material	Metal	Metal
Hot-Plug support	Yes	Yes
Brand compatibilityDiffers	MSA Compliant	HPE
Poweridentical
Maximum voltage	3.3 V	3.3 V
Power consumption (typical)	1 W	1 W
Certificates1 differ
Compliance certificatesDiffers	CE, RoHS, Federal Communications Commission (FCC)	RoHS, Federal Communications Commission (FCC), National Defense Authorization Act (NDAA), UKCA, CE
Sustainabilityidentical
Sustainability compliance	Yes	Yes
Operational conditionsidentical
Operating temperature (T-T)	0 - 70 °C	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C	-40 - 85 °C
Operating relative humidity (H-H)	10 - 85%	10 - 85%
Weight & dimensionsidentical
Width	14 mm	14 mm
Depth	57 mm	57 mm
Height	12 mm	12 mm
Weight	20 g	20 g
Packaging contentidentical
Quantity per pack	1 pc(s)	1 pc(s)
Packaging dataidentical
Package weight	30 g	30 g
Package type	Box	Box
Logistics dataidentical
Master (outer) case width	200 mm	200 mm
Master (outer) case length	310 mm	310 mm
Master (outer) case height	250 mm	250 mm
Master (outer) case gross weight	2.6 kg	2.6 kg
Products per master (outer) case	48 pc(s)	48 pc(s)

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
