Product comparison · 2 network switches

TP-Link TL-SF1016 Unmanaged Fast Ethernet (10/100) 1U Black vs TP-Link 24-Port Gigabit Desktop/Rackmount Network Switch

38specifications compared
13differ
25identical
24known for one product only

Key differences

Basic switching RJ-45 Ethernet ports quantity
- TL-SF1016 Unmanaged Fast Ethernet (10/100) 1U Black:16
- 24-Port Gigabit Desktop/Rackmount Network Switch:24
Switching capacity
- TL-SF1016 Unmanaged Fast Ethernet (10/100) 1U Black:3.2 Gbit/s
- 24-Port Gigabit Desktop/Rackmount Network Switch:48 Gbit/s
Jumbo frames
- TL-SF1016 Unmanaged Fast Ethernet (10/100) 1U Black:2000
- 24-Port Gigabit Desktop/Rackmount Network Switch:10000
Stackable
- TL-SF1016 Unmanaged Fast Ethernet (10/100) 1U Black:No
- 24-Port Gigabit Desktop/Rackmount Network Switch:Yes
Product colour
- TL-SF1016 Unmanaged Fast Ethernet (10/100) 1U Black:Black
- 24-Port Gigabit Desktop/Rackmount Network Switch:Grey
Operating temperature (T-T)
- TL-SF1016 Unmanaged Fast Ethernet (10/100) 1U Black:0 - 40 °C
- 24-Port Gigabit Desktop/Rackmount Network Switch:32 - 104 °F
Heat dissipation
- TL-SF1016 Unmanaged Fast Ethernet (10/100) 1U Black:7.03 BTU/h
- 24-Port Gigabit Desktop/Rackmount Network Switch:46.44 BTU/h
Width
- TL-SF1016 Unmanaged Fast Ethernet (10/100) 1U Black:440 mm
- 24-Port Gigabit Desktop/Rackmount Network Switch:294 mm

Side by side

Differences highlightedShow differences only

Comparison of TL-SF1016, TL-SG1024D
62 specifications	A TP-Link TL-SF1016 Unmanaged Fast Ethernet (10/100) 1U Black Model TL-SF1016 View product	B TP-Link 24-Port Gigabit Desktop/Rackmount Network Switch Model TL-SG1024D View product
Management featuresidentical
Switch type	Unmanaged	Unmanaged
Quality of Service (QoS) supportKnown for one	Unknown — not stated by the source	Yes
Ports & interfaces2 differ
Basic switching RJ-45 Ethernet ports quantityDiffers	16	24
Basic switching RJ-45 Ethernet ports typeDiffers	Fast Ethernet (10/100)	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantityKnown for one	Unknown — not stated by the source	24
Installed SFP modules quantity	0	0
Installed SFP+ modules quantity	0	0
Power connectorKnown for one	Unknown — not stated by the source	DC-in jack
Network1 differ
Networking standardsDiffers	IEEE 802.3i, IEEE 802.3u, IEEE 802.3x	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G support	No	No
Cable types supportedKnown for one	Unknown — not stated by the source	Cat3, Cat4, Cat5, Cat5e
Full duplex	Yes	Yes
Auto MDI/MDI-XKnown for one	Unknown — not stated by the source	Yes
Auto-negotiation	Yes	Yes
Flow control support	Yes	Yes
Copper ethernet cabling technologyKnown for one	10BASE-T, 1000BASE-TX	Unknown — not stated by the source
Half duplexKnown for one	Yes	Unknown — not stated by the source
Data transmission2 differ
MAC address table	8000 entries	8000 entries
Supported data transfer ratesKnown for one	Unknown — not stated by the source	10/100/100 Mbps
Switching capacityDiffers	3.2 Gbit/s	48 Gbit/s
Forwarding rateKnown for one	Unknown — not stated by the source	35.7 Mpps
Store-and-forward	Yes	Yes
Maximum data transfer rateKnown for one	Unknown — not stated by the source	1 Gbit/s
Jumbo frames support	Yes	Yes
Jumbo framesDiffers	2000	10000
Packet buffer memoryKnown for one	2 MB	Unknown — not stated by the source
Protocolsidentical
Supported network protocolsKnown for one	Unknown — not stated by the source	CSMA/CD, TCP/IP
Design2 differ
Rack mounting	Yes	Yes
StackableDiffers	No	Yes
Product colourDiffers	Black	Grey
LED indicators	Yes	Yes
Form factorKnown for one	1U	Unknown — not stated by the source
Poweridentical
Power source	AC	AC
Power supply included	Yes	Yes
AC input voltage	100 - 240 V	100 - 240 V
AC input frequency	50 - 60 Hz	50 - 60 Hz
Power consumption (max)Known for one	Unknown — not stated by the source	13.62 W
Power over Ethernet (PoE)identical
Power over Ethernet (PoE)	No	No
Other featuresidentical
Dimensions (WxDxH)Known for one	Unknown — not stated by the source	294 x 180 x 44 mm
Connectivity technologyKnown for one	Unknown — not stated by the source	Wired
BandwidthKnown for one	Unknown — not stated by the source	48 Gbit/s
Networking featuresKnown for one	Unknown — not stated by the source	Gigabit Ethernet
Power requirementsKnown for one	Unknown — not stated by the source	100 - 240V, 50/60Hz
Connectivity LEDsKnown for one	Unknown — not stated by the source	Yes
Operational conditions2 differ
Operating temperature (T-T)Differs	0 - 40 °C	32 - 104 °F
Storage temperature (T-T)	-40 - 70 °C	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%	10 - 90%
Storage relative humidity (H-H)	5 - 90%	5 - 90%
Heat dissipationDiffers	7.03 BTU/h	46.44 BTU/h
Weight & dimensions1 differ
WidthDiffers	440 mm	294 mm
Depth	180 mm	180 mm
Height	44 mm	44 mm
Packaging contentidentical
Cables includedKnown for one	Unknown — not stated by the source	AC
Rack mount kitKnown for one	Unknown — not stated by the source	Yes
User guideKnown for one	Unknown — not stated by the source	Yes
Packaging data3 differ
Package typeKnown for one	Unknown — not stated by the source	Box
Package widthDiffers	528 mm	250 mm
Package depthDiffers	250 mm	400 mm
Package height	80 mm	80 mm
Package weightDiffers	2.28 kg	1.95 kg
Certificatesidentical
Certification	FCC, CE, RoHS	FCC, CE, RoHS
Logistics dataidentical
Harmonized System (HS) code	85176990	85176990

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
