Product comparison · 2 network switches

Brainboxes Pure Embedded 5 & 8 Port Ethernet Switch Eval Kit vs Brainboxes Embedded Industrial 4 Port Gigabit Ethernet Switch

28specifications compared
14differ
14identical
7known for one product only

Key differences

Ethernet LAN data rates
- Pure Embedded 5 & 8 Port Ethernet Switch Eval Kit:10,100 Mbit/s
- Embedded Industrial 4 Port Gigabit Ethernet Switch:10,100,1000 Mbit/s
Product colour
- Pure Embedded 5 & 8 Port Ethernet Switch Eval Kit:Multicolour
- Embedded Industrial 4 Port Gigabit Ethernet Switch:Green
DC input voltage
- Pure Embedded 5 & 8 Port Ethernet Switch Eval Kit:3.3 V
- Embedded Industrial 4 Port Gigabit Ethernet Switch:5 - 30 V
Power consumption (max)
- Pure Embedded 5 & 8 Port Ethernet Switch Eval Kit:2.5 W
- Embedded Industrial 4 Port Gigabit Ethernet Switch:3.6 W
Operating temperature (T-T)
- Pure Embedded 5 & 8 Port Ethernet Switch Eval Kit:-40 - 85 °C
- Embedded Industrial 4 Port Gigabit Ethernet Switch:-40 - 80 °C
Width
- Pure Embedded 5 & 8 Port Ethernet Switch Eval Kit:117 mm
- Embedded Industrial 4 Port Gigabit Ethernet Switch:95 mm
Depth
- Pure Embedded 5 & 8 Port Ethernet Switch Eval Kit:98 mm
- Embedded Industrial 4 Port Gigabit Ethernet Switch:82 mm
Height
- Pure Embedded 5 & 8 Port Ethernet Switch Eval Kit:22 mm
- Embedded Industrial 4 Port Gigabit Ethernet Switch:15 mm

Side by side

Differences highlightedShow differences only

Comparison of PE-405, SW-114
35 specifications	A Brainboxes Pure Embedded 5 & 8 Port Ethernet Switch Eval Kit Model PE-405 View product	B Brainboxes Embedded Industrial 4 Port Gigabit Ethernet Switch Model SW-114 View product
Management featuresidentical
Switch type	Unmanaged	Unmanaged
Switch layer	L2	L2
Ports & interfaces1 differ
Basic switching RJ-45 Ethernet ports quantity	4	4
Basic switching RJ-45 Ethernet ports typeDiffers	Fast Ethernet (10/100)	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0	0
Installed SFP+ modules quantity	0	0
Power connectorKnown for one	Unknown — not stated by the source	DC-in jack
Network1 differ
10G support	No	No
Auto MDI/MDI-XKnown for one	Unknown — not stated by the source	Yes
Ethernet LAN data ratesDiffers	10,100 Mbit/s	10,100,1000 Mbit/s
Networking standardsKnown for one	IEEE 802.3, IEEE 802.3u, IEEE 802.3x	Unknown — not stated by the source
Data transmissionidentical
MAC address tableKnown for one	Unknown — not stated by the source	1000 entries
Design1 differ
Rack mountingKnown for one	Unknown — not stated by the source	No
Form factor	Embedded	Embedded
Product colourDiffers	Multicolour	Green
International Protection (IP) codeKnown for one	Unknown — not stated by the source	IP20
Performanceidentical
Export Control Classification Number (ECCN)	5A991.b	5A991.b
Power2 differ
Power source	DC	DC
DC input voltageDiffers	3.3 V	5 - 30 V
Power consumption (max)Differs	2.5 W	3.6 W
Power over Ethernet (PoE)identical
Power over Ethernet (PoE)	No	No
Operational conditions1 differ
Operating temperature (T-T)Differs	-40 - 85 °C	-40 - 80 °C
Storage temperature (T-T)	-40 - 85 °C	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95%	5 - 95%
Weight & dimensions4 differ
WidthDiffers	117 mm	95 mm
DepthDiffers	98 mm	82 mm
HeightDiffers	22 mm	15 mm
WeightDiffers	118 g	59 g
Packaging data3 differ
Package widthDiffers	160 mm	135 mm
Package depthDiffers	135 mm	160 mm
Package height	49 mm	49 mm
Package weightDiffers	251 g	144 g
Certificates1 differ
Compliance certificatesDiffers	RoHS, CE, Federal Communications Commission (FCC), National Defense Authorization Act (NDAA), Trade Agreements Act (TAA), UKCA	CE, Federal Communications Commission (FCC), National Defense Authorization Act (NDAA), Trade Agreements Act (TAA), UKCA, cMETus
CertificationKnown for one	CE, UKCA, RoHS, REACH, WEEE	Unknown — not stated by the source
Logistics dataidentical
Harmonized System (HS) code	851762	851762

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
