Product comparison · 2 network switches

Allied Telesis 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT) vs Allied Telesis 16Port 10/100/1GBit Unmanaged Switch

18specifications compared
10differ
8identical
11known for one product only

Key differences

The Allied Telesis 16Port 10/100/1GBit Unmanaged Switch has 96 entries more MAC address table than the Allied Telesis 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT) (4096 entries vs 4000 entries). The Allied Telesis 16Port 10/100/1GBit Unmanaged Switch has 0.9 Gbit/s more maximum data transfer rate than the Allied Telesis 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT) (1 Gbit/s vs 0.1 Gbit/s). The Allied Telesis 16Port 10/100/1GBit Unmanaged Switch has 990 Mbit/s more data transfer rate than the Allied Telesis 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT) (1000 Mbit/s vs 10 Mbit/s). Dimensions (WxDxH): 295 x 115 x 40 mm on the Allied Telesis 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT), 440 x 330 x 44 mm on the Allied Telesis 16Port 10/100/1GBit Unmanaged Switch. Storage temperature (T-T): -20 - 60 °C on the Allied Telesis 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT), -25 - 70 °C on the Allied Telesis 16Port 10/100/1GBit Unmanaged Switch.

MAC address table
- 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT):4000 entries
- 16Port 10/100/1GBit Unmanaged Switch:4096 entries
Maximum data transfer rate
- 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT):0.1 Gbit/s
- 16Port 10/100/1GBit Unmanaged Switch:1 Gbit/s
Data transfer rate
- 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT):10 Mbit/s
- 16Port 10/100/1GBit Unmanaged Switch:1000 Mbit/s
Dimensions (WxDxH)
- 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT):295 x 115 x 40 mm
- 16Port 10/100/1GBit Unmanaged Switch:440 x 330 x 44 mm
Storage temperature (T-T)
- 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT):-20 - 60 °C
- 16Port 10/100/1GBit Unmanaged Switch:-25 - 70 °C
Operating relative humidity (H-H)
- 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT):0 - 80%
- 16Port 10/100/1GBit Unmanaged Switch:5 - 90%
Storage relative humidity (H-H)
- 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT):0 - 95%
- 16Port 10/100/1GBit Unmanaged Switch:5 - 95%
Weight
- 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT):931 g
- 16Port 10/100/1GBit Unmanaged Switch:2.38 kg

Side by side

Differences highlightedShow differences only

Comparison of 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT), 16Port 10/100/1GBit Unmanaged Switch
29 specifications	A Allied Telesis 10/100TX x 16 ports unmanaged FE Switch +1x 100FX (MT)View product	B Allied Telesis 16Port 10/100/1GBit Unmanaged Switch View product
Management featuresidentical
Switch type	Unmanaged	Unmanaged
Ports & interfacesidentical
Basic switching RJ-45 Ethernet ports quantity	16	16
Network1 differ
Networking standardsDiffers	IEEE 802.1W, IEEE 802.3, IEEE 802.3u, IEEE 802.3x	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technologyKnown for one	Unknown — not stated by the source	1000Base-T, 100Base-TX, 10Base-T
Full duplex	Yes	Yes
Flow control supportKnown for one	Unknown — not stated by the source	No
Data transmission2 differ
MAC address tableDiffers	4000 entries	4096 entries
Maximum data transfer rateDiffers	0.1 Gbit/s	1 Gbit/s
Packet buffer memory	0.256 MB	0.256 MB
Poweridentical
Power consumption (typical)Known for one	Unknown — not stated by the source	28 W
Power over Ethernet (PoE)identical
Power over Ethernet (PoE)	No	No
Other features2 differ
Data transfer rateDiffers	10 Mbit/s	1000 Mbit/s
Dimensions (WxDxH)Differs	295 x 115 x 40 mm	440 x 330 x 44 mm
Connectivity technology	Wired	Wired
Networking featuresKnown for one	Unknown — not stated by the source	Ethernet, Fast Ethernet, Gigabit Ethernet
Packet transfer speedKnown for one	Unknown — not stated by the source	1 488 000 pps
Power requirementsKnown for one	Unknown — not stated by the source	100 - 240V; 50/60Hz
Connectivity LEDs	Yes	Yes
Size (imperial)Known for one	48.3 cm (19")	Unknown — not stated by the source
Operational conditions3 differ
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage temperature (T-T)Differs	-20 - 60 °C	-25 - 70 °C
Operating relative humidity (H-H)Differs	0 - 80%	5 - 90%
Storage relative humidity (H-H)Differs	0 - 95%	5 - 95%
Weight & dimensions1 differ
WeightDiffers	931 g	2.38 kg
Certificates1 differ
CertificationDiffers	FCC A, EN55022, CE Mark, UL, CSA, VCCI A, EN60950 (TUV), EN55024	UL 1950, FCC/EN55022 A, VCCI A, C-Tick, EN60950 (TUV), EN55024, CE
Securityidentical
MAC address filteringKnown for one	Yes	Unknown — not stated by the source
Designidentical
Rack mountingKnown for one	Yes	Unknown — not stated by the source
Product colourKnown for one	White	Unknown — not stated by the source
LED indicatorsKnown for one	Yes	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
