Product comparison · 2 network switches

ACT 6 port, network switch, 10/100Mbps. 4x PoE+ (30W) port vs ACT AC4434 24 port, network switch, 10/100Mbps. 24x PoE+ (30W) port, 2 Gigabit combo/uplink ports for 2 uncoded SFP modules

18specifications compared
8differ
10identical
23known for one product only

Key differences

Basic switching RJ-45 Ethernet ports quantity
- 6 port, network switch, 10/100Mbps. 4x PoE+ (30W) port:6
- AC4434 24 port, network switch, 10/100Mbps. 24x PoE+ (30W) port, 2 Gigabit combo/uplink ports for 2 uncoded SFP modules:24
LED indicators
- 6 port, network switch, 10/100Mbps. 4x PoE+ (30W) port:Yes
- AC4434 24 port, network switch, 10/100Mbps. 24x PoE+ (30W) port, 2 Gigabit combo/uplink ports for 2 uncoded SFP modules:Activity, Link, PoE, Power
Total Power over Ethernet (PoE) budget
- 6 port, network switch, 10/100Mbps. 4x PoE+ (30W) port:60 W
- AC4434 24 port, network switch, 10/100Mbps. 24x PoE+ (30W) port, 2 Gigabit combo/uplink ports for 2 uncoded SFP modules:390 W
Width
- 6 port, network switch, 10/100Mbps. 4x PoE+ (30W) port:197 mm
- AC4434 24 port, network switch, 10/100Mbps. 24x PoE+ (30W) port, 2 Gigabit combo/uplink ports for 2 uncoded SFP modules:498 mm
Depth
- 6 port, network switch, 10/100Mbps. 4x PoE+ (30W) port:168 mm
- AC4434 24 port, network switch, 10/100Mbps. 24x PoE+ (30W) port, 2 Gigabit combo/uplink ports for 2 uncoded SFP modules:321 mm
Height
- 6 port, network switch, 10/100Mbps. 4x PoE+ (30W) port:62 mm
- AC4434 24 port, network switch, 10/100Mbps. 24x PoE+ (30W) port, 2 Gigabit combo/uplink ports for 2 uncoded SFP modules:72 mm
Weight
- 6 port, network switch, 10/100Mbps. 4x PoE+ (30W) port:760 g
- AC4434 24 port, network switch, 10/100Mbps. 24x PoE+ (30W) port, 2 Gigabit combo/uplink ports for 2 uncoded SFP modules:3.98 kg

Side by side

Differences highlightedShow differences only

Comparison of AC4430, AC4434
41 specifications	A ACT 6 port, network switch, 10/100Mbps. 4x PoE+ (30W) port Model AC4430 View product	B ACT AC4434 24 port, network switch, 10/100Mbps. 24x PoE+ (30W) port, 2 Gigabit combo/uplink ports for 2 uncoded SFP modules Model AC4434 View product
Management featuresidentical
Switch type	Unmanaged	Unmanaged
Switch layerKnown for one	Unknown — not stated by the source	L2
Ports & interfaces1 differ
Basic switching RJ-45 Ethernet ports quantityDiffers	6	24
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)	Fast Ethernet (10/100)
Installed SFP modules quantityKnown for one	Unknown — not stated by the source	0
Installed SFP+ modules quantityKnown for one	Unknown — not stated by the source	0
SFP module slots quantityKnown for one	Unknown — not stated by the source	2
Power connectorKnown for one	Unknown — not stated by the source	AC-in jack
Network1 differ
Networking standardsDiffers	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x	IEEE 802.3af, IEEE 802.3at
10G supportKnown for one	Yes	Unknown — not stated by the source
Full duplexKnown for one	Yes	Unknown — not stated by the source
Auto MDI/MDI-XKnown for one	Yes	Unknown — not stated by the source
Broadcast storm controlKnown for one	Yes	Unknown — not stated by the source
Link aggregationKnown for one	Yes	Unknown — not stated by the source
Rate limitingKnown for one	Yes	Unknown — not stated by the source
Spanning tree protocolKnown for one	Yes	Unknown — not stated by the source
Design1 differ
Rack mounting	Yes	Yes
StackableKnown for one	Yes	Unknown — not stated by the source
Product colour	Black	Black
LED indicatorsDiffers	Yes	Activity, Link, PoE, Power
Poweridentical
Redundant power supply (RPS) supportKnown for one	Yes	Unknown — not stated by the source
Number of power supply unitsKnown for one	1	Unknown — not stated by the source
AC input voltage	100 - 240 V	100 - 240 V
AC input frequency	50 - 60 Hz	50 - 60 Hz
Power consumption (typical)Known for one	60 W	Unknown — not stated by the source
Power supply includedKnown for one	Unknown — not stated by the source	Yes
Power over Ethernet (PoE)1 differ
Power over Ethernet (PoE)	Yes	Yes
Power over Ethernet (PoE) type supported	PoE+	PoE+
Power over Ethernet (PoE) pass throughKnown for one	Yes	Unknown — not stated by the source
Power over Ethernet (PoE) ports quantityKnown for one	4	Unknown — not stated by the source
Power over Ethernet (PoE) power per port	30 W	30 W
Total Power over Ethernet (PoE) budgetDiffers	60 W	390 W
Power over Ethernet plus (PoE+) ports quantityKnown for one	Unknown — not stated by the source	24
Weight & dimensions4 differ
WidthDiffers	197 mm	498 mm
DepthDiffers	168 mm	321 mm
HeightDiffers	62 mm	72 mm
WeightDiffers	760 g	3.98 kg
Packaging contentidentical
ManualKnown for one	Yes	Unknown — not stated by the source
Cables includedKnown for one	Unknown — not stated by the source	AC
Rack mount kitKnown for one	Unknown — not stated by the source	Yes
Logistics dataidentical
Harmonized System (HS) code	85176990	85176990

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
