Product comparison · 2 network switch modules

LogiLink NS0058 network switch module Fast Ethernet vs LogiLink NS0059 network switch module Gigabit Ethernet

Key differences

Ethernet interface type
- NS0058 network switch module Fast Ethernet:Fast Ethernet
- NS0059 network switch module Gigabit Ethernet:Gigabit Ethernet
Ethernet LAN data rates
- NS0058 network switch module Fast Ethernet:10,100 Mbit/s
- NS0059 network switch module Gigabit Ethernet:10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports
- NS0058 network switch module Fast Ethernet:32
- NS0059 network switch module Gigabit Ethernet:8
Power consumption (typical)
- NS0058 network switch module Fast Ethernet:260 W
- NS0059 network switch module Gigabit Ethernet:130 W

Differences highlightedShow differences only

Comparison of NS0058, NS0059
15 specifications	A LogiLink NS0058 network switch module Fast Ethernet Model NS0058 View product	B LogiLink NS0059 network switch module Gigabit Ethernet Model NS0059 View product
Network4 differ
Ethernet interface typeDiffers	Fast Ethernet	Gigabit Ethernet
Ethernet LAN data ratesDiffers	10,100 Mbit/s	10,100,1000 Mbit/s
Copper ethernet cabling technologyDiffers	100BASE-T, 100BASE-TX, 10BASE-T	1000BASE-T, 1000BASE-TX, 100BASE-T, 100BASE-TX, 10BASE-T
Networking standardsDiffers	IEEE 802.3, IEEE 802.3af, IEEE 802.3u	IEEE 802.3, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u
Ports & interfaces1 differ
Ethernet LAN (RJ-45) portsDiffers	32	8
Power1 differ
Power consumption (typical)Differs	260 W	130 W
Power over Ethernet (PoE)	Yes	Yes
Operational conditionsidentical
Operating relative humidity (H-H)	10 - 90%	10 - 90%
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage temperature (T-T)	-20 - 90 °C	-20 - 90 °C
Certificatesidentical
Certification	CE, RoHS	CE, RoHS
Weight & dimensionsidentical
Dimensions (WxDxH)	220 x 440 x 44 mm	220 x 440 x 44 mm
Weight	3.75 kg	3.75 kg
Size (imperial)	48.3 cm (19")	48.3 cm (19")
Ergonomicsidentical
Connectivity LEDs	Yes	Yes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
