Product comparison · 2 network switch modules

HP 447047-B21 network switch module 10 Gigabit vs HP Virtual Connect Flex-10/10D Module for c-Class BladeSystem

5specifications compared
4differ
1identical
11known for one product only

Key differences

Dimensions (WxDxH)
- 447047-B21 network switch module 10 Gigabit:267.7 x 92.79 x 27.94 mm
- Virtual Connect Flex-10/10D Module for c-Class BladeSystem:270 x 352.6 x 120.7 mm
Weight
- 447047-B21 network switch module 10 Gigabit:1.27 kg
- Virtual Connect Flex-10/10D Module for c-Class BladeSystem:2 kg
SFP/SFP+ slots quantity
- 447047-B21 network switch module 10 Gigabit:2
- Virtual Connect Flex-10/10D Module for c-Class BladeSystem:10

Side by side

Differences highlightedShow differences only

Comparison of 447047-B21, Virtual Connect Flex-10/10D Module for c-Class BladeSystem
16 specifications	A HP 447047-B21 network switch module 10 Gigabit Model 447047-B21 View product	B HP Virtual Connect Flex-10/10D Module for c-Class BladeSystem View product
Network1 differ
Ethernet interface type	10 Gigabit	10 Gigabit
Full duplexKnown for one	Unknown — not stated by the source	Yes
Networking standardsDiffers	IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ak, IEEE 802.3u, IEEE 802.3z	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.2, IEEE 802.3ad
Ethernet LAN data ratesKnown for one	10,100,1000,10000 Mbit/s	Unknown — not stated by the source
Copper ethernet cabling technologyKnown for one	1000BASE-T, 100BASE-TX, 10BASE-T, 10GBASE-CX4	Unknown — not stated by the source
Ports & interfacesidentical
SFP+ module slots quantityKnown for one	Unknown — not stated by the source	10
Ethernet LAN (RJ-45) portsKnown for one	4	Unknown — not stated by the source
SFP module slots quantityKnown for one	2	Unknown — not stated by the source
CX4 ports quantityKnown for one	1	Unknown — not stated by the source
Performanceidentical
Management platformKnown for one	Unknown — not stated by the source	SNMP 1, SNMP 2, CLI
CompatibilityKnown for one	Unknown — not stated by the source	BladeSystem c3000, BladeSystem c7000
Poweridentical
Power consumption (typical)Known for one	Unknown — not stated by the source	70 W
Weight & dimensions2 differ
Dimensions (WxDxH)Differs	267.7 x 92.79 x 27.94 mm	270 x 352.6 x 120.7 mm
WeightDiffers	1.27 kg	2 kg
Ergonomicsidentical
Connectivity LEDsKnown for one	Unknown — not stated by the source	Yes
Other features1 differ
SFP/SFP+ slots quantityDiffers	2	10

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
